Adam Equipment NETS Short User Manual

Adam Equipment NETS Short User Manual

Price computing scale
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Adam Equipment
NETS Price
Computing Scale
RevA, May 2011
Specifications are subject to change without notice to improve
1 |
P a g e
© Adam Equipment Company 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NETS and is the answer not in the manual?

Questions and answers

Garth
February 8, 2025

How much is a Nets ME keypad?

0

Related Manuals for Adam Equipment NETS

Summary of Contents for Adam Equipment NETS

  • Page 1 Adam Equipment NETS Price Computing Scale RevA, May 2011 Specifications are subject to change without notice to improve P a g e © Adam Equipment Company 2010...

  • Page 2: Table Of Contents

    Thank you for the choosing our label printing scale NETS, we are always trying to serve you with better quality as a reliable weighing instrument and enhanced features supporting various kinds of applications 1. SPECIFICATIONS ------------------------------------------------------------------------------- 2 2. OPTIONS -------------------------------------------------------------------------------------------- 3.

  • Page 3: Precautions

    Do not spill the water to the scale Do not use cleaners which includes solvent or sinner Scale should be calibrated by authorized person prior to being to used Turn on the scale 10 minutes before using Cartridge P a g e © Adam Equipment Company 2010...
  • Page 4 Displays Key Board I/O Connections Power Switch Network Option RS-232C Cash Drawer Option AC Connect External Keyboard Fuse- Holder Option P a g e © Adam Equipment Company 2010...

  • Page 5: Installation

    Escape key, used to cancel of previous transaction(s), escape from each menu of the set mode Add up key, used to add up of commodities PLU key, used to call indirect PLU P a g e © Adam Equipment Company 2010...

  • Page 6: The Designators

    It indicates scale is under communication AUTO It indicates automatic printing mode SAVE It indicates PLU saving mode SALE It indicates sale mode FUNC It indicates scale is under function mode P a g e © Adam Equipment Company 2010...
  • Page 7 Selling mode consists of 4 subsidiary mode, refer to the listed page for the details See Page 8 See Page 9 See Page 10 See Page 11 Note : Scale dose not print out any label or ticket unless PLU has been programmed, P a g e © Adam Equipment Company 2010...
  • Page 8 While the designator AUTO is turned on, scale prints automatically FILLET Remove commodity on the platter While the designator SAVE is turned 0.000 0.00 0.00 on, scale saves current PLU Enter PLU P a g e © Adam Equipment Company 2010...
  • Page 9 PLU key(indirect) SWEET CANDY Press FOR key 0.25 0.25 SWEET CANDY Enter number of commodity(Candy) and PRINT key 0.25 12.50 SWEET CANDY Weighing mode 0.000 0.00 0.00 Enter PLU P a g e © Adam Equipment Company 2010...
  • Page 10 ADD key 1.000 7.99 7.99 ADD UP Remove the commodity(Tenderloin) and enter another PLU 0.000 5.90 0.00 FILLET Put the commodity(Fillet) on the platter 1.200 5.90 7.08 FILLET 10 | P a g e © Adam Equipment Company 2010...
  • Page 11 PLU number 0.100 1.99 1.99 and press PLU key(indirect) APPLE Put commodity(Apple) on the platter and press X key 0.100 1.99 1.99 Multiply : 0 X Price : 0.00 11 | P a g e © Adam Equipment Company 2010...
  • Page 12 9.95 Press PRINT key scale prints a label when each pressing 0.100 1.99 7.96 PRINT key Number of Labels : X Price : 9.95 0.000 0.00 0.00 Enter PLU 12 | P a g e © Adam Equipment Company 2010...
  • Page 13 See Page 14 ∇ See Page 16 ∇ See Page 16 ∇ See Page 21 ∇ See Page 21 ∇ See Page 26 ∇ See Page 28 ∇ See Page 37 13 | P a g e © Adam Equipment Company 2010...

  • Page 14: E D I T P Lu

    PLUs by categories of commodities – Enter UPC code and press Enter key numbers 0 ~ 999,999 are available UPC code is commodity code of P1- 4 12345 bar code – 14 | P a g e © Adam Equipment Company 2010...
  • Page 15 Repeat steps to enter another PLU or press ESC key to the next mode P1- 0 To return to the normal mode, press SET key – 15 | P a g e © Adam Equipment Company 2010...

  • Page 16: E D I T S P E E D K Ey

    PLU number which will be assigned Press SAVE key to store, repeat steps to enter other speed keys or press ESC key to exit(next mode) 3-1 Edit Store Name Press Enter key P3-1 16 | P a g e © Adam Equipment Company 2010...
  • Page 17 Press Enter key 3-3 Non PLU Group Code Non PLU Group Code is used to store Group Code not recorded in PLU. Press Enter key P3-3 17 | P a g e © Adam Equipment Company 2010...
  • Page 18 3-5 Edit Group Group is used to managing PLUs by categories of commodities, for examples, meet, fruit and vegetable Press Enter key P3-5 Enter group code and press Enter key P3-5 18 | P a g e © Adam Equipment Company 2010...
  • Page 19 Enter name of operator and press Enter key, P3-6 Max. 10 characters x 32 operators Repeat steps to enter another operator or press ESC key twice to the next P3-6 19 | P a g e © Adam Equipment Company 2010...
  • Page 20 Repeat steps to enter another sale message, or press ESC key twice P3-7 to the next mode Pressing SET key enables to return to the normal mode at here 20 | P a g e © Adam Equipment Company 2010...

  • Page 21: E D I T D A T E / T I Me

    MM-DD-YY are available in normal operation mode Press ESC key twice to the next P4- 1 123456 xxxxxx 5-1 Minimum Weight of Auto Printing Press Enter key P5-1 0.100 21 | P a g e © Adam Equipment Company 2010...
  • Page 22 Select group code and press Enter key codes 0 ~ 99 are available, P5-2 5-3 Select Operator Press Enter key P5-3 Select operator code and press Enter Key, codes 0 ~ 99 are available, P5-3 22 | P a g e © Adam Equipment Company 2010...
  • Page 23 0 ~ 99 are available, P5-4 5-5 Select Date Format Press Enter key P5-5 Select date format and press Enter key P5-5 5-6 Select Sale Message Press Enter key P5-6 23 | P a g e © Adam Equipment Company 2010...
  • Page 24 Select 1 or 2, default setting is 2 and press Enter key P5-7 5-8 Select Add Printing Press Enter key P5-8 Select 1 or 2, default setting is 2 and press Enter key P5-8 24 | P a g e © Adam Equipment Company 2010...
  • Page 25 5-10 Use Speed Key(120Ea) Press Enter key P5-10 Select 1 or 2, default setting is 1 and press Enter key P5-10 5-8 Select Bar Code Press Enter key P5-11 25 | P a g e © Adam Equipment Company 2010...

  • Page 26: A C C O U Nt

    Enter barcode format and press Enter P5-11 Press ESC key to exit 6-1 Account Group Press Enter key P6-1 Enter group number and press Enter key, group total is printed P6-1 26 | P a g e © Adam Equipment Company 2010...
  • Page 27 Enter PLU number and press Enter key, PLU total is printed P6-2 P6-2 Repeat steps to print another PLU or press ESC key to exit P6-2 6-3 Account Daily Press Enter key P6-3 27 | P a g e © Adam Equipment Company 2010...

  • Page 28: M O D I F Y L A B El

    2 for ticket printing and press P7-1 Enter key For the ticket printing, remove the label bobbin on the cartridge and fit the ticket paper roll 7-2 Setting Label Length Press Enter key P7-2 28 | P a g e © Adam Equipment Company 2010...
  • Page 29 Peel off sensor detects a label peeled or remained on the peel off bar, after enabling, scale dose not print label to prevent labels jammed Press Enter key P7-4 Select disable or enable and press Enter key P7-4 29 | P a g e © Adam Equipment Company 2010...
  • Page 30 Prior to setting, the min. & max. levels must be read in 2-6 Self Test / Sensor Test Press Enter key P7-6 Enter threshold level(middle level) and press Enter key P7-6 30 | P a g e © Adam Equipment Company 2010...
  • Page 31 P7-7 7-8 Select Label Format Press Enter key P7-8 Select label format and press Enter key, refer to the APPENDIX P7-8 7-9 Select Printing Item Press Enter key P7-9 31 | P a g e © Adam Equipment Company 2010...
  • Page 32 After group code is set to Y each group code of PLU is printed individually, group code is set to N a common group code is printed which has been set in 5-2 Select Function / Select group code Enter yes(Y) or no(N) P7-9-4 Enter yes(Y) or no(N) P7-9-5 32 | P a g e © Adam Equipment Company 2010...
  • Page 33 Enter yes(Y) or no(N) P7-9-9 Enter number 1 or 2, 1 ; Printing 1 line of store name 2 : Printing 2 lines of store name P7-9-10 0 : No store name 33 | P a g e © Adam Equipment Company 2010...
  • Page 34 Enter yes(Y) or no(N) Ingredients P7-9-12 Enter yes(Y) or no(N) P7-9-13 Enter yes(Y) or no(N) and press Enter key P7-9-14 Enter yes(Y) or no(N) and press Enter key P7-9-15 34 | P a g e © Adam Equipment Company 2010...
  • Page 35 Enter value between 0 ~ 400 and press Enter key, bigger? value has a higher contrast, a value 45 is fixed at high speed P7-11 Press ESC key to exit 7-12 Set Number of Label Press Enter key P7-12 35 | P a g e © Adam Equipment Company 2010...
  • Page 36 P7-13 Select 1. Low, 2. Medium 3.High and press Enter key P7-13 7-14 Select Subtotal Label Press Enter key P7-14 Select Subtotal Label P7-14 Press ESC key to exit 36 | P a g e © Adam Equipment Company 2010...

  • Page 37: U T I L I Ty

    And a stable A/D count is recommended + / − 2 count at an indicated value as a stable A/D reading, if count is unstable or fluctuated, replace the Analog board first and then load cell. 37 | P a g e © Adam Equipment Company 2010...
  • Page 38 NUMERIC KEY CODE Press “ESC” key to exit 8-1-3 Display All numeric displays are checked by counting “00000” ~ “99999” continuously, 000000 0000000 00000000 Press “ZERO” key to exit 38 | P a g e © Adam Equipment Company 2010...
  • Page 39 Peel off sensor ; No label -> more than 200 / With label -> less than 70 Gap sensor ; In gap -> less than 60 / Out of gap -> more than 120 P8-6 Press ESC key to exit 39 | P a g e © Adam Equipment Company 2010...
  • Page 40 PLUs which assigned in starting No to End No are printed Enter starting PLU No and press Enter key P8-2 Enter end PLU No and press Enter key P8-2 40 | P a g e © Adam Equipment Company 2010...
  • Page 41 Connect RS-232C cable between two scales and press Enter key to transfer P8-3 … Press ESC key to exit 8-4 Del Account Press Enter key, account data is deleted / display Press ESC key to exit 41 | P a g e © Adam Equipment Company 2010...

  • Page 42: The Others

    1) CHANGING LABEL ROLL 42 | P a g e © Adam Equipment Company 2010...
  • Page 43 2) CLEANING THERMAL PRINT HEAD 43 | P a g e © Adam Equipment Company 2010...

  • Page 44: Sample Label Format

    44 | P a g e © Adam Equipment Company 2010...
  • Page 45 WARRANTY INFORMATION Adam Equipment offers Limited Warranty (Parts and Labour) for the components failed due to def ects in materials or workmanship. Warranty starts from the date of delivery. During the warranty period, should any repairs be necessary, the purchaser must inform its s upplier or Adam Equipment Company.
  • Page 46 46 | P a g e © Adam Equipment Company 2010...
  • Page 47 Shielded interconnect cables must be employed with this equipment to insure compliance wit h the pertinent RF emission limits governing this device. Changes or modifications not expressly approved by Adam Equipment could void the user's authority to operate the equipment.
  • Page 48 For a complete listing of all Adam products visit our website at www.adamequipment.com © Copyright by Adam Equipment Co. Ltd. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior permission of Adam Equipment.
