Mercado Medic REAL Series Instructions For Use And Care

BACKREST

The chair is equipped with a high Double Medic back recliner.
The depth of this can be adjusted by loosening the two
screws (1) using a 5 mm hex key, for example the Mercado
key. The entire mechanism can then be moved forwards
or backwards. Once adjusted, retighten the two screws.
NOTE! Ensure that the back recliner is not moved too far
out 'backwards', i.e. so that the spring button clips stop the
back recliner from being moved too far back.
The angle of the entire back recliner can be adjusted by
loosening the two knobs (2) and then adjusting the back
recliner by taking hold of the back, angling it as required,
and then retightening the knobs (2).
The height of the backrest can be adjusted by loosening the
screws (3) using the Mercado key and then adjusting the
back to the required height. Once adjusted, retighten the
screws (3).
The angle of the backrest can be adjusted by loosening the
handles (4), taking hold of the back, angling it as required,
and then retightening the handles (4).

SEAT HEIGHT

The seat height is adjusted by means of the lever (1), which
releases the gas fix lifting mechanism when pulled upwards.
You can then move the seat down by putting weight on the
seat or up by reducing the weight on the seat (stretch out
your legs).
Once the seat reaches the required height, release the
lever (1).
INSTRUCTIONS FOR USE AND CARE
The REAL chair has replaceable components, accessories and functions
with adjustment options for individual adaptation. The chair must only be
used by the person for whom it was prescribed and for the purpose for
which it is intended. The chair is intended for indoor use only. The chair
must not be equipped with any accessories or components other than
those approved by Mercado Medic AB. Repairs and other technical
measures may only be carried out by personnel authorised by Mercado
Medic AB. Read these instructions carefully before using the chair for
the first time.
1
December 2013
Item no.
4
3
2
1
