SPXFLOW CombiFlexBloc Series Instruction Manual

Vertical centrifugal pump in monobloc execution
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CombiFlexBloc
Vertical centrifugal pump in monobloc execution
CFB/EN (1808) 2.4
Orginal instructions
Read and understand this manual prior to operating or servicing this product
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CombiFlexBloc Series and is the answer not in the manual?

Questions and answers

Related Manuals for SPXFLOW CombiFlexBloc Series

Summary of Contents for SPXFLOW CombiFlexBloc Series

  • Page 1 INSTRUCTION MANUAL CombiFlexBloc Vertical centrifugal pump in monobloc execution Orginal instructions CFB/EN (1808) 2.4 Read and understand this manual prior to operating or servicing this product...
  • Page 3 EC Declaration of conformity (Directive 2006/42/EC, appendix II-A) Manufacturer SPX Flow Technology Assen B.V. Dr. A.F. Philipsweg 51 9403 AD Assen The Netherlands hereby declares that all pumps member of productfamilies CombiBloc, CombiBlocHorti, CombiChem, CombiDirt, CombiFlex(U)(B), CombiPrime H, CombiLine, CombiLineBloc, CombiMag, CombiMagBloc, CombiNorm, CombiPro(L)(M)(V), CombiPrime V, CombiSump, CombiTherm, CombiWell, FRE, FRES, FREF, FREM, KGE(L), KGEF, HCR, MCH(W)(S), whether delivered without drive (last position of serial...
  • Page 4 EC/EN (1712) 6.0...
  • Page 5 SPXFLOW is a global multi-industry manufacturing leader. The company's highly- specialized, engineered products and innovative technologies are helping to meet rising global demand for electricity and processed foods and beverages, particularly in emerging markets.
  • Page 6 INT/EN (1512) 1.2...

  • Page 7: Table Of Contents

    CombiFlexBloc Table of Contents Introduction Preface Safety Guarantee Inspection of delivered items Instructions for transport and storage 1.5.1 Weight 1.5.2 Use of pallets 1.5.3 Hoisting 1.5.4 Storage Ordering parts General Pump description Type code Serial number Applications Construction 2.5.1 Design 2.5.2 Pump casing/impeller/suction bend 2.5.3...
  • Page 8 Checking the sense of rotation Start-up Adjustment of shaft sealing 4.6.1 Stuffing box packing 4.6.2 Mechanical seal Pump in operation Noise Maintenance Regular maintenance Shaft sealing 5.2.1 Stuffing box packing 5.2.2 Mechanical seal Lubrication of the bearings Environmental influences Noise Motor Faults Problem solving...
  • Page 9 CombiFlexBloc Dimensions foot pads K1 Dimensions foot pads K3 Dimensions foot pads 200-200 / 250B-315 K3 Pump dimensions K1, with suction bend 8.6.1 Pump dimensions M0 8.6.2 Pump dimensions S2/S3/S4/M1/M2/M3 Pump dimensions K3, with suction bend 8.7.1 Pump dimensions M0 8.7.2 Pump dimensions S2/S3/S4/M1/M2/M3 Pump dimensions 200-200 / 250B-315 K3, with suction bend...
  • Page 10 10.6 Pressure near the impeller hub for shaft sealing groups S2-S3-S4 10.7 Hydraulic performance 10.8 Noise data 10.8.1 Pump noise as a function of pump power 10.8.2 Noise level of entire pump unit Index Order form for spare parts CFB/EN (1808) 2.4...

  • Page 11: Introduction

    The data published here comply with the most recent information at the time of going to press. However they may be subject to later modifications. SPXFLOW reserves the right to change the construction and design of the products at any time without being obliged to change earlier deliveries accordingly.

  • Page 12: Guarantee

    Guarantee SPXFLOW shall not be bound to any guarantee other than the guarantee accepted by SPXFLOW. In particular, SPXFLOW will not assume any liability for explicit and/or implicit guarantees such as but not limited to the marketability and/or suitability of the products supplied.

  • Page 13: Hoisting

    CombiFlexBloc 1.5.3 Hoisting When hoisting a pump or complete pump units the straps must be fixed in accordance with figure 1. When lifting a pump or a complete pump unit always use a proper and sound lifting device, approved to bear the total weight of the load! Never go underneath a load that is being lifted! If the electric motor is provided with a lifting eye, this lifting eye is intended only for the purpose of carrying out service activities to the electric motor!

  • Page 14: Ordering Parts

    Ordering parts This manual contains a survey of the spare parts recommended by SPXFLOW as well as the instructions for ordering them. A fax-order form is included in this manual. You should always state all data stamped on the type plate when ordering parts and in any other correspondence regarding the pump.

  • Page 15: General

    CombiFlexBloc 2 General Pump description The CombiFlexBloc is a range of vertical non-self-priming centrifugal pumps. The discharge and suction connection can be mounted in different positions in relation to each other. The pump is driven by e vertical flange motor with extended motor shaft. There is also a version with a IEC-standard flange motor and a stub shaft.

  • Page 16: Serial Number

    Serial number Serial number of the pump or pump unit are shown on the name plate off the pump and on the label on the cover of this manual. Example: 01-1000675A year of manufacture 100067 unique number number of pumps pump with motor pump with free shaft end Applications...

  • Page 17: Foot Pads

    10 "Technical data". Re-use The pump may only be used for other applications after prior consultation with SPXFLOW or your supplier. Since the lastly pumped medium is not always known, the following instructions should be observed: 1 Flush the pump properly.
  • Page 18 General CFB/EN (1808) 2.4...

  • Page 19: Installation

    CombiFlexBloc 3 Installation Safety • Read this manual carefully prior to installation and commissioning. Non-observance of these instructions can result in serious damage to the pump and this will not be covered under the terms of our guarantee. Follow the instructions given step by step. •...

  • Page 20: Piping

    Piping • The piping to the suction and delivery connections must fit exactly and must not be subject to stress during operation. • The passage of the suction pipe must be amply dimensioned. This pipe should be as short as possible and run towards the pump in such a way that no air pockets can arise.

  • Page 21: Commissioning

    CombiFlexBloc 4 Commissioning Inspection of the pump • Construction with stuffing box packing: Remove the guards (0270). Check whether the nuts (1810) have not been over tightened. If necessary, loosen these nuts and tighten them again by hand. Fit the guards (0270). •...

  • Page 22: Adjustment Of Shaft Sealing

    Adjustment of shaft sealing 4.6.1 Stuffing box packing After the pump is started, the stuffing box packing will show a certain amount of leakage. Because of the expansion of the packing fibres, this leakage will gradually decrease. Make sure that the stuffing box packing never runs dry. To prevent this, loosen the nuts (1810) to the extent that the stuffing box packing leaks by drops.

  • Page 23: Maintenance

    CombiFlexBloc 5 Maintenance Regular maintenance Regularly check the outlet pressure. No water should get into the terminal box of the electric motor when the pump room is sprayed clean! Never spray water on hot pump parts! The sudden cooling down may cause them to burst and hot water may flow out! Flawed maintenance will result in shorter lifespan, possible break down and in any event loss of warranty.

  • Page 24: Noise

    Noise If a pump starts making noise, this may point to certain problems with the pump unit. A crackling noise can indicate cavitation or excessive motor noise can indicate deterioration of the bearings. Motor Check motor specifications for start-stop frequency. Faults The pump, of which you want to determine the fault, may be hot or under pressure.

  • Page 25: Problem Solving

    CombiFlexBloc 6 Problem solving Faults in a pump installation can have various causes. The fault may not be in the pump, it may also be caused by the pipe system or the operating conditions. Firstly, always check that installation has been executed in accordance with the instructions in this manual and that the operating conditions still correspond with the specifications for which the pump was purchased.
  • Page 26 Table 3: Possible causes of pump failures. Possible causes Pump or suction pipe is not sufficiently filled or de-aerated Gas or air coming from the liquid Air lock in the suction pipe Air leak in the suction pipe The pump takes in air through the stuffing box packing The flush or quench water line to the stuffing box packing is not connected or obstructed The lantern ring in the stuffing box packing has been mounted wrongly The manometric suction head is too high...

  • Page 27: Disassembly And Assembly

    CombiFlexBloc 7 Disassembly and assembly Precautionary measures Take adequate measures to avoid that the motor is started while you are working on the pump. This is especially important for electric motors with remote control: • Switch the operating switch near the pump (if available) to "OFF". •...

  • Page 28: Disassembly And Assembly Top Pull Out Unit

    Disassembly and assembly Top Pull Out unit ➢ The Top Pull Out unit and the electric motor of large pumps are too heavy to be lifted by hand. Use appropriate hoisting equipment. CombiFlexBloc pumps use a Top Pull Out system. The electric motor with the lantern piece, the stuffing box cover/pump cover and the impeller can be dismantled as a whole.

  • Page 29: Replacing The Impeller And The Wear Ring

    CombiFlexBloc Replacing the impeller and the wear ring The play between the impeller and the wear ring is 0,3 mm to the diameter at delivery. In case the play has increased to 0,5-0,7 mm due to wear, the impeller and the wear ring should be replaced.

  • Page 30: Disassembling The Wear Ring

    7.5.3 Disassembling the wear ring After removing the Top Pull Out unit the wear ring can be removed. In most cases the ring has been fixed so tightly that it cannot be removed undamaged. Figure 5: Removal of wear ring. 1 Measure the thickness (d) and the width (b) of the ring, see figure 5 A.

  • Page 31: Stuffing Box Packing

    CombiFlexBloc Stuffing box packing S2, S3, S4 7.6.1 Instruction for assembling and disassembling stuffing box packing ➢ First read the following instructions regarding stuffing box packing. Follow these instruc- tions closely when removing and mounting stuffing box packing. • For removing old packing rings your supplier can supply a special packing puller. See figure 6.

  • Page 32: Replacing The Stuffing Box Packing S2, S3, S4

    7.6.2 Replacing the stuffing box packing S2, S3, S4 To replace the stuffing box packing it is not necessary to disassemble the pump. The pump should however be drained, see paragraph 7.3 "Liquid draining". Figure 8: Stuffing box packing S2, S3 and S4. The item numbers used are referring to figure 8.

  • Page 33: Disassembling The Shaft Sleeve

    CombiFlexBloc 7.6.4 Disassembling the shaft sleeve 1 Disassemble the impeller, see paragraph 7.5.1 "Disassembling of the impeller". 2 Pull the shaft sleeve (1100) from the pump shaft. 7.6.5 Mounting the shaft sleeve 1 Slide the shaft sleeve over the pump shaft. Watch the position of the key ways in the shaft sleeve in respect of those in the pump shaft.

  • Page 34: Mechanical Seal

    Mechanical seal 7.7.1 Instructions for mounting a mechanical seal ➢ First read the following instructions regarding the mounting of a mechanical seal. Follow these instructions closely when mounting a mechanical seal. • Leave the assembly of a mechanical seal with PTFE (Teflon) covered O- rings to a specialist.

  • Page 35: Disassembling A Mechanical Seal M0

    CombiFlexBloc 7.7.2 Disassembling a mechanical seal M0 Figure 10: Mechanical seal M0. The item numbers used are referring to figure 10. 1 Remove the impeller, see paragraph 7.5.1 "Disassembling of the impeller". 2 Pull the distance sleeve (1100) and the rotating part of the mechanical seal (1220) off the shaft.

  • Page 36: Disassembling A Mechanical Seal M1

    7.7.4 Disassembling a mechanical seal M1 Figure 11: Mechanical seal M1. The item numbers used are referring to figure 11. 1 Remove the impeller, see paragraph 7.5.1 "Disassembling of the impeller". 2 Remove the nuts (1810) and push the mechanical seal cover (1230) backward. 3 Mark the position of the stuffing box cover (0110) in relation to the bearing bracket (2100).

  • Page 37: Disassembling A Mechanical Seal M2-M3

    CombiFlexBloc 5 Push the rotating part of the seal onto the pump shaft. The bellows should slide smoothly over the shaft. Put some glycerine or silicon spray on it. 6 Fit the stuffing box cover in the right position in the fitting edge of the bearing bracket. Check whether the stuffing box cover is at right angles to the pump shaft.

  • Page 38: Assembling A Mechanical Seal M2-M3

    7.7.7 Assembling a mechanical seal M2-M3 1 Ensure the shaft sleeve (1200), the throttling bush (1210) and the splash ring (2220) are undamaged. The splash ring should also clasp the pump shaft properly. If necessary, replace these parts. In that case, secure the throttling bush (1210) with Loctite 641.

  • Page 39: Replacing The Stub Shaft And The Motor For M0

    CombiFlexBloc Replacing the stub shaft and the motor for M0 7.8.1 Disassembling the stub shaft and the motor 1100 1220 0110 2200 4194_A 1820 0120 1860 0250 0270 0850 0900 2280 132S/M 90S/L 160M/L 100L 180M/L 112M 200L 225S/M 250M 280S/M 2200 2200...

  • Page 40: Assembling The Stub Shaft And The Motor

    7.8.2 Assembling the stub shaft and the motor 1 For electric motors with IEC-size 80 upto and including 112M: Remove the key from the motor shaft. 2 Put the motor in vertical position, shaft end up. Fit the stub shaft (2200) on the motor shaft.

  • Page 41: Dimensions

    CombiFlexBloc 8 Dimensions Dimensions delivery flange Figure 14: Dimensions delivery flange. ISO 7005 PN16 aj x al 4 x 18 4 x 18 4 x 18 4 x 18 8 x 18 8 x 18 8 x 18 8 x 23 8 x 23 12 x 23 ISO 7005 PN10...

  • Page 42: Dimensions Suction Flange

    Dimensions suction flange Figure 15: Dimensions suction flange. ISO 7005 PN16 ai x ak 4 x 18 8 x 18 8 x 18 8 x 18 8 x 22 8 x 22 Dimensions foot pads K1 Figure 16: Dimensions foot pads (Top view)..-160 ...-200 ...-250...

  • Page 43: Dimensions Foot Pads K3

    CombiFlexBloc Dimensions foot pads K3 Figure 17: Dimensions foot pads (Top view)..-160 ...-200 ...-250 ...-315 ...-400 Dimensions foot pads 200-200 / 250B-315 K3 Figure 18: Dimensions foot pads (Top view). 200-200 250B-315 Dimensions CFB/EN (1808) 2.4...

  • Page 44: Pump Dimensions K1, With Suction Bend

    Pump dimensions K1, with suction bend Figure 19: Pump dimensions K1, with suction bend. Standard: • suction bend: pos I • junction box electric motor: pos 1 Dimensions CFB/EN (1808) 2.4...

  • Page 45: Pump Dimensions M0

    CombiFlexBloc 8.6.1 Pump dimensions M0 aa ab zb 100L 160M/L 250M 132S/M 200L 225S/M 90S/L 112M 180M/L 280S/M 32-160 32 167 330 220 250 145,5 155,5 175,5 32-200 32 177 350 220 280 145,5 155,5 175,5 205,5 205,5 40-160 40 177 330 220 250 145,5 155,5 175,5 205,5 205,5...

  • Page 46: Pump Dimensions S2/S3/S4/M1/M2/M3

    8.6.2 Pump dimensions S2/S3/S4/M1/M2/M3 aa ab zb 100L 160M/L 250M 132S/M 200L 225S/M 90S/L 112M 180M/L 280S/M 32-160 32 167 330 220 250 145,5 155,5 175,5 32-200 32 177 350 220 280 145,5 155,5 175,5 205,5 205,5 40-160 40 177 330 220 250 145,5 155,5 175,5 205,5 205,5...

  • Page 47: Pump Dimensions K3, With Suction Bend

    CombiFlexBloc Pump dimensions K3, with suction bend Figure 20: Pump dimensions K3, with suction bend. Standard: • suction bend: pos I • junction box electric motor: pos 1 Dimensions CFB/EN (1808) 2.4...

  • Page 48: Pump Dimensions M0

    8.7.1 Pump dimensions M0 aa ab zb 100L 160M/L 250M 132S/M 200L 225S/M 90S/L 112M 180M/L 280S/M 32-160 32 167 400 220 250 145,5 155,5 175,5 32-200 32 177 400 220 280 145,5 155,5 175,5 205,5 205,5 40-160 40 177 400 220 250 145,5 155,5 175,5 205,5 205,5...

  • Page 49: Pump Dimensions S2/S3/S4/M1/M2/M3

    CombiFlexBloc 8.7.2 Pump dimensions S2/S3/S4/M1/M2/M3 aa ab zb 100L 160M/L 250M 132S/M 200L 225S/M 90S/L 112M 180M/L 280S/M 32-160 32 167 400 220 250 145,5 155,5 175,5 32-200 32 177 400 220 280 145,5 155,5 175,5 205,5 205,5 40-160 40 177 400 220 250 145,5 155,5 175,5 205,5 205,5...

  • Page 50: Pump Dimensions 200-200 / 250B-315 K3, With Suction Bend

    Pump dimensions 200-200 / 250B-315 K3, with suction bend Figure 21: Pump dimensions 200-200 / 250B-315 K3, with suction bend. Standard: • suction bend: pos I • junction box electric motor: pos 1 Dimensions CFB/EN (1808) 2.4...

  • Page 51: Pump Dimensions M0

    CombiFlexBloc 8.8.1 Pump dimensions M0 aa ab zb 100L 160M/L 250M 132S/M 200L 225S/M 90S/L 112M 180M/L 280S/M 200-200 200 200 498 700 500 400 250B-315 250 250 533 800 600 500 241,5 241,5 283,5 283,5 IEC motor 80 286 308 332 366 392 450 488 548 592 626 662 754 768 792 1000 1160 (*) motor length based on DIN 42677, could be different due to applied motor make 8.8.2...
  • Page 52 Dimensions CFB/EN (1808) 2.4...

  • Page 53: Parts

    CombiFlexBloc 9 Parts Ordering parts 9.1.1 Order form You can use the order form included in this manual for ordering parts. When ordering parts always quote the following data: 1 Your address. 2 The quantity, the item number and the description of the part. 3 The pump number.

  • Page 54: Pump Construction K1

    Pump construction K1 9.2.1 Sectional drawing M0 Figure 22: Sectional drawing M0. Parts CFB/EN (1808) 2.4...

  • Page 55: Parts List M0

    CombiFlexBloc 9.2.2 Parts list M0 Material Item Quantity Description 0100 pump casing cast iron bronze 0110 pump cover cast iron bronze 0120* impeller cast iron bronze alu.brz bronze alu.brz 0130* wear ring cast iron bronze 0250 lantern piece cast iron 0270 guard aluminium...

  • Page 56: Sectional Drawing M1/M2/M3/S2/S3/S4

    9.2.3 Sectional drawing M1/M2/M3/S2/S3/S4 Figure 23: Sectional drawing M1/M2/M3/S2/S3/S4. Parts CFB/EN (1808) 2.4...

  • Page 57: Parts List M1/M2/M3/S2/S3/S4

    CombiFlexBloc 9.2.4 Parts list M1/M2/M3/S2/S3/S4 Material Item Quantity Description 0100 pump casing cast iron bronze 0110 stuffing box cover cast iron bronze 0120* impeller cast iron bronze alu.brz bronze alu.brz 0130* wear ring cast iron bronze 0250 lantern piece cast iron 0270 guard aluminium...

  • Page 58: Pump Construction K3

    Pump construction K3 9.3.1 Sectional drawing M1/M2/M3/S2/S3/S4 Figure 24: Sectional drawing M1/M2/M3/S2/S3/S4. Parts CFB/EN (1808) 2.4...

  • Page 59: Parts List M1/M2/M3/S2/S3/S4

    CombiFlexBloc 9.3.2 Parts list M1/M2/M3/S2/S3/S4 Material Item Quantity Description 0100 pump casing cast iron bronze 0110 stuffing box cover cast iron bronze 0120* impeller cast iron bronze alu.brz bronze alu.brz 0130* wear ring cast iron bronze 0250 lantern piece cast iron 0270 guard aluminium...

  • Page 60: Stuffing Box Packing S2-S3

    Stuffing box packing S2-S3 9.4.1 Stuffing box packing S2-S3 Figure 25: Stuffing box packing S2-S3. 9.4.2 Parts list stuffing box packing S2-S3 Quantity Material Item Description cast iron bronze 1100* shaft sleeve stainless steel 1110* bottom ring bronze 1120* packing ring 1130* lantern ring bronze...

  • Page 61: Stuffing Box Packing S4

    CombiFlexBloc Stuffing box packing S4 9.5.1 Stuffing box packing S4 Figure 26: Stuffing box packing S4. 9.5.2 Parts list stuffing box packing S4 Item Quantity Description Material 1100* shaft sleeve stainless steel 1110* bottom ring bronze 1120* packing ring 1140 gland cast iron 1150...

  • Page 62: Shaft Sealing Group M1

    Shaft sealing group M1 9.6.1 Mechanical seal MG12-G60 Figure 27: Mechanical seal MG12-G60. 9.6.2 Parts list mechanical seal MG12-G60 Item Quantity Description Material 1200* shaft sleeve brass 1210* throttling bush bronze 1220* mechanical seal 1230 mechanical seal cover cast iron 1300* gasket 1340*...

  • Page 63: Shaft Sealing Group M2-M3

    CombiFlexBloc Shaft sealing group M2-M3 9.7.1 Mechanical seal M7N-H7N Figure 28: Mechanical seal M7N-H7N. 9.7.2 Parts list mechanical seal M7N-H7N Quantity Material Item Description cast iron bronze 1200* shaft sleeve bronze 1210* throttling bush bronze 1220* mechanical seal 1230 mechanical seal cover cast iron bronze 1270...

  • Page 64: Suction Bend

    Suction bend K1/K3 9.8.1 Sectional drawing suction bend, K1 Figure 29: Sectional drawing suction bend, K1. 9.8.2 Parts of suction bend, K1 See figure 29. Material Item Quantity Description cast iron bronze 0350 plug steel stainless steel 0360 gasket 0400 suction bend cast iron bronze...

  • Page 65: Sectional Drawing Suction Bend, K3

    CombiFlexBloc 9.8.3 Sectional drawing suction bend, K3 Figure 30: Sectional drawing suction bend, K3. 9.8.4 Parts of suction bend, K3 See figure 30. Material Item Quantity Description cast iron bronze 0350 plug steel stainless steel 0360 gasket 0400 suction bend cast iron bronze 0410...

  • Page 66: Sectional Drawing Suction Bend 200-200 / 250B-315

    9.8.5 Sectional drawing suction bend 200-200 / 250B-315 Figure 31: Sectional drawing suction bend 200-200 / 250B-315. 9.8.6 Parts of suction bend 200-200 / 250B-315 See figure 31. Materials Item Quantity Description cast iron bronze 0350 plug steel stainless steel 0360 gasket rubber...

  • Page 67: Technical Data

    CombiFlexBloc 10 Technical data 10.1 Bearing groups The pump range is divided in a number of bearing groups. Table 6: Bearing group division. Bearing groups 32-160 65-250 80-400 32-200 65-315 100-400 40-160 80-200 125-315 40-200 80(A)-250 125-400 40-250 80-315 150-315 50-160 100-200 150-400...

  • Page 68: Tightening Moments

    10.3 Tightening moments 10.3.1 Tightening moments for bolts and nuts Table 8: Tightening moments for bolts and nuts. Materials A2, A4 Thread Tightening moment [Nm] 10.3.2 Tightening moments for cap nut Table 9: Tightening moments for cap nut (1820). Size Tightening moment [Nm] M12 (bearing group 1) M16 (bearing group 2)

  • Page 69: Pressure In Shaft Sealing Space For Shaft Sealing Groups M1-M2-M3

    CombiFlexBloc 10.5 Pressure in shaft sealing space for shaft sealing groups M1-M2-M3 Pressure in shaft sealing space above the inlet pressure and with an external circulation of medium from the delivery side, calculated for a specific mass of 1000 kg/m Table 11: Pressure in shaft sealing space for shaft sealing groups M1-M2-M3.
  • Page 70 10.6 Pressure near the impeller hub for shaft sealing groups S2-S3-S4 Pressure near the impeller hub above the inlet pressure, calculated for a specific mass of 1000 kg/m Table 12: Pressure near the impeller hub for shaft sealing groups S2-S3-S4. n[min ]/[bar] 900 1200 1500 1800 2100 2400 2700 3000 3300 3600...
  • Page 71 CombiFlexBloc 10.7 Hydraulic performance Figure 32: Performance overview 3000 min Figure 33: Performance overview 1500 min Technical data CFB/EN (1808) 2.4...
  • Page 72 Figure 34: Performance overview 3600 min Figure 35: Performance overview 1800 min Technical data CFB/EN (1808) 2.4...
  • Page 73 CombiFlexBloc 10.8 Noise data 10.8.1 Pump noise as a function of pump power [dB(A)] P [kW] Figure 36: Noise level as function of pump power [kW] at 1450 min A = sound power level, B = sound pressure level. [dB(A)] P [kW] Figure 37: Noise level as function of pump power [kW] at 2900 min...
  • Page 74 10.8.2 Noise level of entire pump unit L [dB] 9 10 11 12 13 14 15 16 17 18 19 20 |L1 - L2| [dB] Figure 38: Noise level of entire pump unit. In order to determine the total noise level of the entire pump unit, the noise level of the motor must be added to that of the pump.
  • Page 75 CombiFlexBloc Index Application area .....15 Applications ......14 Lifting eye .
  • Page 76 Safety ......9, 17 symbols ......9 Scrapping .
  • Page 77 Order form for spare parts FAX Nr. ADDRESS Your order will only be dealt with if this order form has been correctly completed and signed. Order date: Your order number: Pump type: Execution: Quantity Item. No. Part Article number pump Delivery address: Invoicing address: Ordered by:...
  • Page 78 ORDFORM (1512) 3.3 EN...
  • Page 79 For more information about our worldwide locations, approvals, certifications, and local representatives, please visit www.spxflow.com/johnson-pump. SPXFLOW Corporation reserves the right to incorporate our latest design and material changes without notice or obligation. Design features, materials of construction and dimensional data, as described in this bulletin, are provided for your information only and should not be relied upon unless confirmed in writing.
