- Page 1 AP31 MULTITESTER INSTRUCTION MANUAL Thank you for purchasing a SANWA tester Model AP31 You are kindly requested to thoroughly read this manual before use for safety.
-
Page 2: Safety Rules
1.0 SAFETY RULES ● This meter is designed and tested in accordance with IEC publication 1010, pollution degree Ⅱ and installation category (overvoltage category) Ⅱ. ● This meter has been tested according to the following EC Directives:- ● 89/336/EEC (EMC, Electromagnetic Compatibility) EN55022, EN50082-1 ●... - Page 3 Dimensions : 120 (H) ×85 (W) ×30 (D) mm. Weight : Approx. 150g (including battery and test leads) Packing : Complete with Operation Manual 3.2 Electrical Specifications Measuring range and Accuracy (23℃±5℃, max. 75％ RH, no condensation) DC Voltage Range 10/50/250/500V ±5％...
-
Page 4: Panel Description
4.0 PANEL DESCRIPTION 1 .Case with protective bumper 2 .Analog display 3 .Resistance zero adjustment knob 4 .Resistance range 5 .Battery test range 6 .DC current range 7 .Pin cover 8 .Attachable test leads with probes 9 .Power off 10.Range switch 11.DC voltage range 12.AC voltage range 5.0 FITTING AND REPLACING THE BATTERY AND FUSE... -
Page 5: Operation Warning
6.0 OPERATION WARNING 1 ) When measuring voltage ensure that the instrument is not connected or switched to a current or resistance range. Always ensure that the correct terminals are used for the type of measurement to be made. 2 ) Use extreme care when measuring voltage above 50V, especially from sources where high energy exists. - Page 6 6.1 DC Voltage Measurements Set the Range switch to desired "DC V" range and connect the test leads across the sources or load under measurement. If the voltage range is not known beforehand, set the range switch to the highest range and work down. Read the DC voltage reading on the "DC V" scale (Black color) 6.2 AC Voltage Measurements Set the Range switch to desired "AC V"...
- Page 7 6.5 Decibel Measurements Set the Range switch to the desired "AC V" range, connect the test leads across the sources or load under measurement. For "50V AC" Range read dB reading on the dB scale directly, but for other ranges, calculate the reading with the following table:- dB Range 4 to 36 18 to 50...
