Summary of Contents for APRILIA SR 150

  • Page 2 This manual will also provide the Preventive Maintenance Schedule and Warranty guidelines. We believe that all new APRILIA SR will serve you for a long time to come if you get familiarized with all the relevant elements of the product. This booklet is an integral part of the APRILIA SR. It must be transferred to the new owner whenever it is sold.
  • Page 3 Accessories shown in pictures may not be part of the standard fitment. In our endeavor to improve our products can lead to change in product specifications without notice. APRILIA SR complies with latest Auto Headlamp ON (AHO) Compliance and BS-IV emission norms.
  • Page 4 SAFETY INFORMATION Personal safety Failure to completely observe these instructions will result in serious risk of personal injury. Safeguarding the environment Sections marked with this symbol indicate the correct use of the vehicle to prevent damaging the environment. Vehicle intactness The incomplete or non-observance of these regulations leads to the risk of serious damage to the vehicle and sometimes even the invalidity of the warranty.

  • Page 6: Table Of Contents

    CONTENTS Know Your APRILIA SR Aprilia Connectivity Riding your APRILIA SR Safe Riding Tips Maintenance Spare Parts Troubleshooting Warranty Terms Form 22 (Certificate of Roadworthiness) Delivery Certificate Service Coupons Ownership Record and Data General Information...

  • Page 8: Know Your Aprilia Sr

    Indicates : Scooter Year Month Serial M911M For SR 150 XXXXXX two wheeler Numbers 1A:APRILIA SR 150 HE Code Code Number M912M For SR 125 XXXXXX 1B:APRILIA SR 125 HE Warning: Any type of altering with frame and engine number (VIN) can lead to serious legal issues and also claiming of warranty for any part will be difficult.
  • Page 9 Know Your APRILIA SR TECHNICAL SPECIFICATIONS ENGINE SR 150 SR 125 SR 150 SR 125 TRANSMISSION Type Single cylinder 4 stroke, Clutch Self ventilating dry - centrifugal air cooled, SOHC, 3 valves clutch Cylinder bore 58 mm 52 mm Transmission...
  • Page 10 CDI unit with variable advance and TYRE SIZE HT coil Front Tubeless Type 120 Spark plug Bosch UR4DC For SR 150 Bosch - 70/14 M/C 61H UR3DC For SR 125 Rear Tubeless Type 120 Battery type 12V, 5.0 Ah MF Battery...
  • Page 11 Fuse 12V 15A x 1, 12V 10A X 2, failure of the bulb 12V 5A X 1 for SR 150 12V 15A x 1, 12V 10A X 1, NOTE : Specifications are subject to change without prior for SR 125 notice.
  • Page 12 Know Your APRILIA SR FRONT VIEW: (If Applicable) A : Rear brake control : Starter button B : Turn indicator switch G : Right throttle grip C : Horn switch H : Front brake lever D : Head light beam selection and passing switch...
  • Page 13 Know Your APRILIA SR FRONT VIEW: (If Applicable) A : Rear brake control : Starter button B : Turn indicator switch G : Right throttle grip C : Horn switch H : Front brake lever D : Head light beam selection and passing switch...
  • Page 14 Know Your APRILIA SR LEFT SIDE VIEW: 1 - Head lamp 4 - Saddle handle bar 7 - Kick starter pedal 2 - Front turn indicator lamp 5 - Tail lamp 8. Disc brake 3 - Saddle lock 6 - Rear turn Indicator lamp...
  • Page 15 Know Your APRILIA SR RIGHT SIDE VIEW: 1 - Muffler 4 - Bag hook 2 - Dipstick 5 - Centre stand 3 - Ignition lock...
  • Page 16 Know Your APRILIA SR INSTRUMENT PANEL : (If Applicable) Sr No Description Function Instruments and Indicators : Speedometer Indicates driving speed The function of indicators on instrument panel are as Odometer Total Distance covered follows: by vehicle Fuel Gauge Indicates the approximate...
  • Page 17 Know Your APRILIA SR ELECTRONIC SPEEDOMETER WITH ANALOGUE DISPLAY : (If Applicable) The function of indicators on instrument panel are as follows: A = Digital display E = Low fuel warning light I = High-beam on warning light B = MODE button...
  • Page 18 Know Your APRILIA SR DIGITAL LCD DISPLAY SETTING THE HOUR / MINUTES FUNCTION Turn the ignition switch to «ON» and do the following. C = Clock 1 = «MODE» button 2 = «SET» button - Press and hold down button «1» to go into "AM" or "PM"...
  • Page 19 Know Your APRILIA SR IGNITION SWITCH cum STEERING LOCK: Caution Ignition switch has three Do not turn the key to «LOCK» or «KEY OFF» while riding positions: to avoid personal injury. Leaving the key in 'ON' position will drain the battery when vehicle is not in use. For safety, 0 : “Lock”...
  • Page 20 Know Your APRILIA SR 1.HEAD LIGHT BEAM SELECTION AND PASSING 4. REAR BRAKE LEVER : SWITCH : The rear brake is applied by pressing the rear brake lever Press the knob towards « » to operate high beam of the gently towards the handle grip.
  • Page 21 Know Your APRILIA SR 2.FRONT BRAKE LEVER NOTE Front brake is applied by pressing the front brake lever For cold starts, use kick starter instead of electric starter. gentle towards the throttle grip. The brake light will glow on This would reduce load on battery and prevents quick drain.
  • Page 22 Know Your APRILIA SR the vehicle retains the characteristics of a conventional WARNING braking system. • Any flashing or steady on condition of the ABS warning In case of ABS warning light, reduce speed and go to an light during driving (more than 5km/h) indicates a Authorised Service Centre for the appropriate checks.
  • Page 23 Know Your APRILIA SR When the rider operates the left hand brake lever it activates calipers and the respective drum to a minimum; in order to check this condition, and regulate it if necessary, contact an the rear brake mechanically, and the front brake hydraulically (via a distributor);...
  • Page 24 Know Your APRILIA SR BAG HOOK FUEL TANK The bag hook is mounted on front panel. Fuel Tank is located under the seat assembled open the seat assembly insert the key into saddle lock and rotate it in anti-clockwise direction and tip the saddle forward.
  • Page 25 Know Your APRILIA SR TYRE PRESSURE Caution Tyre pressure should be checked in cold condition. Incorrect tyre pressure causes abnormal tyre wear and makes riding unsafe. Tyres must be replaced when the tread reaches the wear limits set forth by law.
  • Page 26 Know Your APRILIA SR TYRE PUNCTURE KICK STARTER LEVER The vehicle is equipped with tubeless tyre. When there is puncture, tubeless tires go flat very slowly. This offers great riding safety, A tyre that goes flat very slowly can be repaired with and Inflate and repair spray.
  • Page 27 Place your foot firmly on center stand extension and press with adequate effort ensuring both the legs of center stand APRILIA SR is provided with effortless center stand . touching ground. before pressing the stand. The center stand has a rotating lever arm to increase the...
  • Page 28 Know Your APRILIA SR TOOL KIT AND FIRST AID KIT LOCATION: TOOL KIT - A : To assist you in performing certain aspects of periodic maintenance and emergency repairs, a tool kit is supplied along with the vehicle and it is located under the seat base.

  • Page 29: Aprilia Connectivity

    Connectivity means you can connect your vehicle through mobile app. Mobile app is available free in Play store and APP Store for both android and IOS. Please Search with “APRILIA CONNECTIVITY” in store, select the first result “APRILIA CONNECTIVITY” and install the APP.
  • Page 30 Aprilia Connectivity Disclaimer INSTALLATION OF APP IN MOBILE PHONE App Installation Process: Search for “APRILIA CONNECTIVITY” on Google Play / App Store. Install the App. Start the Application.
  • Page 31 Disclaimer Aprilia Connectivity User must read the Disclaimer and click on “I accept” tab. The User will be able to access the App only if he / she agrees the Disclaimer. Note: It is not mandatory to allow or accept...
  • Page 32 Aprilia Connectivity Registration INFO PAGES BEFORE REGISTRATION IN APP Welcome screens will help to understand the Features of the App.
  • Page 33 Registration Aprilia Connectivity INFO PAGES BEFORE REGISTRATION IN APP User should go through all the screens during initial registration. SKIP option is also provided, in case the User wants to skip the screens.
  • Page 34 Aprilia Connectivity Registration REGISTRATION IN APP Enter the Chassis Number of the Vehicle. Click Submit. Guest User option is provided in case the User wants to share the vehicle with family or friends. The Guest User login will give access to the User to use limited features of the App such as: Find Me, Follow Me, Navigate Me, Etc.
  • Page 35 Registration Aprilia Connectivity REGISTRATION OTP FOR AUTHENTICATION User will receive an OTP via SMS on the registered mobile number. User will have to insert the OTP in App & complete the Authentication. Note: If you are not receiving the OTP for User registration, your mobile number may not match with registered mobile number.
  • Page 36 Aprilia Connectivity Registration REGISTRATION IN APP User should verify the Details provided on the Registration screen. Once verified, User should click on “Confirm and Register” tab. Note: These details will be fetched from CDMS which was updated on the time of vehicle purchase. If details are not matching, please contact to nearest Dealer.
  • Page 37 Registration Aprilia Connectivity PERMISSIONS FOR ACCESSING INFORMATION User should allow all the Permissions, for appropriate functioning of the App. User must keep the GPS on with “High Accuracy” for correct information gathering for the Trip History.
  • Page 38 Aprilia Connectivity Registration PERMISSIONS FOR ACCESSING INFORMATION...
  • Page 39 Emergency Aprilia Connectivity ADDING EMERGENCY CONTACT DETAILS IN APP Click on ‘Settings’ icon, given in the bottom right corner of the homepage. You will receive a prompt showing ‘Please configure number first’. Enter the mobile numbers of your emergency contacts and click on ‘Save’.
  • Page 40 Aprilia Connectivity Home Screen HOME SCREEN This screen will be seen by the User, every time User opens the App, after successful Registration. User’s life will be at ease while using this App, as User can Book a Service, Raise Concern, Buy Accessories using this App.
  • Page 41 Vehicle Aprilia Connectivity SELECT VEHICLE If user has Digital Vehicle, then the default vehicle will be available and selected automatically. In case, if there are more than one vehicles, User should make sure that the default vehicle is selected. If the default vehicle is not connected, Connection to the desired vehicle will not be established.
  • Page 42 Aprilia Connectivity Find & Follow Me FIND ME This feature will help user to find his / her vehicle in parking areas where it is difficult to identify the Vehicle. When Find Me is used, Turn indicators blink twice along with blowing of the Horn.
  • Page 43 Find & Follow Me Aprilia Connectivity FOLLOW ME This feature can be used to illuminate a dark parking area, where there is no light. When Follow Me is used, Turn indicators of the vehicle remain ON for 10 seconds. This feature works only in Ignition OFF condition.
  • Page 44 Aprilia Connectivity Navigate Me NAVIGATE ME This feature navigates you to the last location of the vehicle. App stores the last location where the vehicle was used (Ignition OFF). Note: You can use Navigate Me feature without connecting to vehicle.
  • Page 45 Share Bike Aprilia Connectivity SHARE BIKE (FOR USERS / GUEST USERS) This feature can be used by the users to share their vehicle with family or friends. Pressing Share Bike will generate a QR code which can be shared by User to Guest User.
  • Page 46 Aprilia Connectivity Vehicle ADD VEHICLE (FOR GUEST USERS ONLY) To access features of the App, Guest User must add the vehicle’s either by manually entering the Chassis Number OR by scanning the QR Code generated on the Owner / User’s Mobile (as described in the previous page) All the features will be available to the user, only when the App is connected with the Vehicle.
  • Page 47 Vehicle Aprilia Connectivity PANIC ALERT This feature can be used for alerting your emergency contacts as well as the bystanders in the event of an emergency situation To activate the feature, press the left indicator button consecutively for four times (Vehicle should be in engine - ON condition) On doing so, the horn will start beeping.
  • Page 48 Aprilia Connectivity My Services MY SERVICES My Services drop down contains four features: 1. Locate service Centers: This feature will show all nearby service centers. 2. Locate Dealers: This will show all Dealers located nearby. 3. Locate Petrol Pumps: This will show all nearby petrol pumps.
  • Page 49 My Services Aprilia Connectivity MY SERVICES: LOCATE SERVICE CENTERS When the user needs to know the Service Centers near the user’s location, he /she can use this feature. When clicked on Locate Service Centers, App will ask the user to open google maps.
  • Page 50 Aprilia Connectivity My Services MY SERVICES: LOCATE DEALERS When the user needs to know the Dealers near the user’s location, he /she can use this feature. When clicked on Locate Dealers, App will ask the user to open google maps.
  • Page 51 My Services Aprilia Connectivity MY SERVICES: BOOK SERVICE To book a service, user can select the service type, service center, expected date for servicing. User can also give Comments for the servicing, for example, changing any spare part, oil change or any other requirement.
  • Page 52 Aprilia Connectivity My Services MY SERVICES: BOOK SERVICE...
  • Page 53 My Services Aprilia Connectivity MY SERVICES: BOOK SERVICE...
  • Page 54 3. Owner’s Manual: To give user more information about the vehicle. 4. Value Added Services: Information about Road Side Assistance & Extended Warranty. To purchase please contact nearest dealer. APRILIA APRILIA WORLD Aprilia World gives more information about the vehicle, its specifications, to the user.
  • Page 55 My Aprilia Aprilia Connectivity APRILIA : VEHICLE INFO Vehicle Info stores the Trip details of the user. App stores information of the last 5 trips performed by the User.
  • Page 56 Aprilia Connectivity My Aprilia MY APRILIA : VEHICLE INFO Information like Trip start and end time, Distance travelled in a trip, maximum and average speed of the vehicle in a trip are calculated. User can also check for fuel level and battery status of the vehicle.
  • Page 57 To ensure that all data is recorded, please connect the App with the Vehicle while travelling. If you force close Aprilia connectivity APP, App will get disconnected and Features like Max. Speed, Avg. Speed, Distance, Trip Duration will not be captured. So it is recommended to not force close the App.
  • Page 58 Aprilia Connectivity My Aprilia MY APRILIA : OWNER MANUAL Aprilia World gives more information about the vehicle, its specifications, to the user.
  • Page 59 My Aprilia Aprilia Connectivity MY APRILIA : VALUE ADDED SERVICES Value Added Services consist of Road Side Assistance (RSA) and Extended warranty (EW). User can raise request for RSA and EW through this feature...
  • Page 60 Aprilia Connectivity Customer Care CUSTOMER CARE : CALL DEALER Using Customer Care feature, User can call the Dealer for any inquiry or help.
  • Page 61 Customer Care Aprilia Connectivity CUSTOMER CARE : CALL CUSTOMER CARE Using Customer Care feature, User can call the customer Care for any inquiry or help...
  • Page 62 Aprilia Connectivity Customer Care CUSTOMER CARE : RAISE CONCERN If user wants to register any concern, then Raise Concern can be used. User should select the desired concern type and write the details in Concern Description, Once submitted, user will receive a Concern ID. This can be used to track the concern progress.
  • Page 63 Customer Care Aprilia Connectivity CUSTOMER CARE : E-CART User can buy Merchandise and Piaggio vehicle using this feature.
  • Page 64 Aprilia Connectivity Customer Care CUSTOMER CARE : SOCIAL MEDIA Using this feature, user will be able to share the pictures captured with the App on social networking sites like Facebook, Twitter, Instagram, etc.
  • Page 65 Offers & News Feed Aprilia Connectivity OFFERS OFFERS NEWS FEED Offers from Piaggio for Campaigns, Discount offers from Dealers, etc. can be seen in this feature. NEWS FEED News Feed will show the latest updates from Piaggio. Birthday wishes, Service reminders etc.
  • Page 66 For changing my profile picture, please Go to App Settings -> My Profile -> Click on Profile Picture Profile pictures are stored in APRILIA INDIA folder in your mobile storage. You can find your captured profile pictures in this folder.

  • Page 67: Riding Your Aprilia Sr

    Know Your APRILIA SR RIDING YOUR APRILIA SR PRE-RIDE INSPECTION Check the following items before riding ITEM WHAT TO CHECK FOR Engine oil Availability of the oil up to the level. Fuel Enough fuel for the planned distance of running.
  • Page 68 Know Your APRILIA SR STARTING UP THE ENGINE 3. Insert the key into the ignition switch, «D» and turn to the «ON» position. Cold start: 1. Pull the choke knob «H» outwards fully i.e ON position. 2. Electric starter switch: Push the self-starter switch «C» after pulling the rear brake control lever «F»...
  • Page 69 Know Your APRILIA SR When approaching a corner or turn - close the throttle, slow Performing the 1 free Service by the scheduled time / kms down the scooter by applying brakes and negotiate the turn. interval is essential to ensure optimum service life and After completion of turn and scooter is steady open the performance from the engine / vehicle.
  • Page 70 Know Your APRILIA SR Warning 2. Stand on left side and push the scooter forward by gripping below the seat. 1. Do not run engine in indoors or where there is no 3. Rest on foot on the ground to steady the scooter. It is ventilation as the exhaust gases are extremely poisonous.
  • Page 71 Know Your APRILIA SR AUTOMATIC TRANSMISSION To ensure simple, pleasurable riding, the vehicle is equipped with automatic transmission. The system is designed to give the best possible performance in terms of both acceleration and consumption, on level ground and uphill to do adjustments to engine speed and transmitted torque.
  • Page 72 Know Your APRILIA SR TIPS FOR IMPROVING FUEL ECONOMY Fuel leaks Check for fuel leaks on a daily basis from tank, carburetor REGULAR CHECKS and fuel lines if any. Loss of fuel due to leaks may drain the Carry out the periodic maintenance checks as specified in fuel tank completely.

  • Page 73: Safe Riding Tips

    Safe Riding Tips SAFE RIDING TIPS FAMILIARIZE YOUR SCOOTER We suggest you to practice your scooter in a low traffic condition until you are thoroughly familiar with your vehicle and its controls. Go through this manual again, if required or call your nearest Piaggio 2W Authorized Dealer for assistance.
  • Page 74 2. Hold your arms at an angle of about 120°. 3. Hips should be in a position so that arms and shoulders It is essential for you to always maintain your APRILIA SR in are relaxed. good condition by periodically serviced and checked at 4.

  • Page 75: Maintenance

    Adequate maintenance is fundamental to ensuring long-lasting, optimum operation and performance of APRILIA SR. To facilitate you in taking care for your APRILIA SR series of checks and maintenance operations are elaborated in the form of table on the following page. Any minor faults should be reported without delay to our Piaggio 2W Authorized Dealer without waiting until the next scheduled service to solve it.

  • Page 76: Maintenance Schedule

    Maintenance Maintenance Schedule: Periodic Services every 3 months or 3000kms (after 1st year or 12000 km) whichever comes earlier. This schedule will be Service Number repeated for every year. Sl.No. Months after Date of Sale 0.5 - 1 2.5 - 3 5.5 - 6 8.5 - 9 12 - 12.5 3 Months 6 Months 9 Months 12 Months...
  • Page 77 Maintenance Periodic Services every 3 months or 3000kms (after 1st year or 12000 km) whichever comes earlier. This schedule will be repeated for every year. Service Number Sl.No. Months after Date of Sale 0.5 - 1 2.5 - 3 5.5 - 6 8.5 - 9 12 - 12.5 3 Months 6 Months 9 Months 12 Months Remarks...
  • Page 78 Maintenance ENGINE OIL LEVEL ENGINE OIL LEVEL CHECK The engine oil is used to lubricate the distribution elements, main bearings and thermal group. An insufficient quantity of oil can seriously damage the engine. A loss of efficiency in oil performance and certain consumption should be considered normal.
  • Page 79 Maintenance Caution ENGINE OIL CHANGE Running the engine with insufficient engine oil quantity or wrong grade of oil may increase wear and tear on the moving parts and may cause serious damage. Characteristic Engine oil: 700 ml (Refilling quantity during recommended replacement interval).
  • Page 80 Maintenance Start up the vehicle after pouring oil and tightened oil Warning dipstick and oil filler plug. Leave it running for a few minutes and switch it «OFF». After about 5 minutes, check the level Running the engine with insufficient engine oil quantity or and if necessary top up without exceeding the «MAX»...
  • Page 81 Maintenance TYRE Periodically check the inflation pressure of each tyre in cold condition. Characteristic Tyres are fitted with wear indicators. The tyre should be replaced as soon as tyre indicator become visible on the Gear oil : 110 ml (Refilling quantity). tyre tread.
  • Page 82 Maintenance SPARK PLUG Dismantle the spark plug for inspection in COLD condition with following procedure : 1. Park the vehicle on side stand 2. Remove center cover as shown in photographs (Show arrow ) 3. Use spark plug opener to remove / replacement of spark plug.
  • Page 83 Maintenance To refit, repeat the procedure in reverse order using the SHOCK ABSORBERS ADJUSTMENT wrench to insert the spark plug or to tighten it in its seat. Care should be taken while fixing it to avoid mishandling and hitting to ensure fitment at correct inclination. Warning The spark plug must be removed when the engine is COLD.
  • Page 84 Maintenance operation you will need to use the specific spanner. Spring AIR FILTER : pre-loading increases by turning the ring nut towards «A», 1. Remove the air cleaner cover after unscrewing the 7 but decreases if the ring nut is turned towards «B». fixing screws.
  • Page 85 Maintenance BATTERY regulations. The kick start allows the vehicle to start, even if the Ÿ electric system is not performing. In this case, please promptly restore the electric system Ÿ by an efficient battery in order to use properly the engine starter.
  • Page 86 Maintenance Battery Checking LONG PERIODS OF INACTIVITY In case of any electrical malfunctioning related to electrical Battery performance will decrease if the vehicle is not used lamps, horn and self starting, recharging of battery may be for a long time. This is the result of the natural phenomenon required.
  • Page 87 Maintenance Caution Fuse no Ratting Power consumer Fuse 1 (5A) +Key ABS Do not disconnect the battery cables with the engine in Fuse 2 (10A) Blinker, USB, Headlamp, Front running condition. This can cause permanent damage to position, Licence plate lamp, +Key the vehicle electrical circuit.
  • Page 88 Maintenance specifications of the system, can cause errors in functioning FRONT LIGHT GROUP and risk of fire. In the front headlight there are BULBS 1. High beam light bulb 2. Low beam light bulb 3. Position light bulb Lamp Type Power Headlight bulb 12V-35/35W...
  • Page 89 Maintenance HEADLIGHT ADJUSTMENT FRONT TURN INDICATORS 1. Place the vehicle with engine «ON» with the tyres inflated to the prescribed pressure on a flat surface 10 m away from a white screen situated in a shaded area, making sure that the longitudinal axis of the vehicle is perpendicular to the screen.
  • Page 90 Maintenance REAR TURN INDICATORS Rear Turn indicators are sealed lamp. To remove the lamp remove the screw shown in the fig and replace as assembly. NUMBER PLATE LAMP: 1. Remove the lower LH & RH fairing by removing two screws. TAIL LIGHT BULB 2.
  • Page 91 Maintenance REAR-VIEW MIRRORS CARBURETOR: IDLE ADJUST The mirrors can be set to the desired position by adjusting the mirror frame. 1. Rest the vehicle on its center stand and lift the saddle and remove the helmet compartment. 2. To adjust the idle speed, start the engine, then loose or tighten «Idle rpm setting screw»...
  • Page 92 Authorized Dealer. Characteristic Engine Idle RPM: Aprilia SR 150 & 125 : 1550 ±100 First loosen lock nut «A» then operate adjustment nut «B». The front and rear brake control lever free play should be adequate (10 - 20 mm). so that the wheel should rotate...
  • Page 93 Maintenance FRONT DISC BRAKE Warning The brake disc and pad wear is automatically compensated, Check brake pads for wear on a regular basis (as indicated therefore it has no effect on the functioning of the front and in the schedule maintenance tables). If the thickness of one rear brakes.
  • Page 94 Maintenance CHECKING THE BRAKE FLUID LEVEL When the sight glass «A» is full, the level inside the reservoir exceeds the MIN level. When it is partially full, the level drops to the MIN level and when it is fully empty, the level of fluid in the reservoir is below the MIN level.
  • Page 95 Maintenance 2. The braking circuit fluid is highly corrosive. Therefore, when topping it up, avoid letting it come into contact with the painted parts of the vehicle. The braking circuit fluid is hygroscopic, that is, it absorbs humidity from the surrounding air.
  • Page 96 Maintenance PERIODS OF INACTIVITY CLEANING THE VEHICLE In order to soften the dirt and mud deposited on the painted surfaces, use a low pressure jet of water. Once softened, mud and dirt must be removed with a soft sponge for bodywork soaked in lot of water with 2-4% of car shampoo.
  • Page 97 Maintenance Caution Detergents pollute water. Therefore the vehicle should be washed in the area equipped for the proper drainage and disposal system. Warning 1. Never wash the vehicle under direct sunlight, especially when the vehicle is still hot. The car shampoo may dry before being rinsed off and could damage the paint finish.
  • Page 98 Maintenance ROAD SIGNS Mandatory signs: These road sings inform drivers / riders of the traffic rules that apply on a certain stretch of road, thereby instructing them on how to drive / ride. Mandatory signs are distinguished by the bright red circle with black and blue markings.
  • Page 99 Maintenance Cautionary Signs: These signs inform the driver / rider of Informatory Signs: These are facility signs that provide the road conditions ahead. Cautionary signs therefore important about road directions or maps of specific serve as a warning. They are usually in a red triangle with destinations.

  • Page 100: Spare Parts

    Value for money. Ÿ 3. Piaggio APRILIA markets its own line of accessories that are recognized and guaranteed for use. It is therefore essential, in order to choose and mount the accessories correctly, contact our Piaggio 2W Authorized Dealer.

  • Page 101: Troubleshooting

    Troubleshooting TROUBLESHOOTING: Symptom Cause Remedies No fuel in tank Refuel Start up problems Filters, jets or carburettor body dirty or clogged contact to Piaggio 2W Authorized Dealer Insufficient battery charging Rechage battery Check that the plug gap is properly set (0.7 to 0.8 mm). Check that the electrodes areclean (clean with pure petrol and metal brush).

  • Page 102: Warranty Terms

    SCOPE OF WARRANTY Piaggio Vehicles Pvt. Ltd., (here in after called as PVPL) offers warranty for "APRILIA" (here in after called as Products) manufactured in its Baramati plant and sold through its Piaggio 2W Authorized Dealer. Piaggio Vehicles Private Ltd. (PVPL)
  • Page 103 Warranty Terms 3. PVPL undertake no liability in the matter of consequential loss or damage caused due to the failure of parts. Delay, if any, for carrying out the repairs at Piaggio 2W Authorized Dealer, shall not be a ground for extending the warranty period, nor shall it give any right to the customer for claiming any compensation for damages.
  • Page 104 Emission Policy PIAGGIO EMISSION CONTRACT POLICY SCOPE OF WARRANTY: PVPL warrants all its scooters, assembled / manufactured at its Baramati plants and sold through its Authorized Dealers, to comply with emission standards as specified in sub rule (2)(b) of Rule 115 of Central Motor Vehicles Rules, 1989, which reads that CO (Carbon Monoxide) emission limit for all two wheeled petrol driven vehicles shall not exceed 3 percent by volumes and HC (Hydro Carbon) 3000 ppm, subject to following terms and conditions.
  • Page 105 Emission Policy g) It is mandatory to avail all the services as per the recommended schedule to be eligible for the emission warranty benefits. Please ensure that each paid service is availed within sixty days from the date of previous services or as per the recommended schedule, whichever is earlier.
  • Page 106 Certified that the following vehicle complies with the provisions of the Motor Vehicles Act. 1988, and the rules made there under, including the following mass emission norms and noise standards. Brand Name of the Vehicle: APRILIA SR Chassis Number: Engine Number: Sub-Rule No. of rule 115: 115(2), 115(6), 115(7), 115(16), 120 Emission Norms: Bharat Stage IV For PIAGGIO VEHICLES PVT.
  • Page 108 Certified that the following vehicle complies with the provisions of the Motor Vehicles Act. 1988, and the rules made there under, including the following mass emission norms and noise standards. Brand Name of the Vehicle: APRILIA SR Chassis Number: Engine Number: Sub-Rule No. of rule 115: 115(2), 115(6), 115(7), 115(16), 120 Emission Norms: Bharat Stage IV For PIAGGIO VEHICLES PVT.

  • Page 110: Delivery Certificate

    DELIVERY CERTIFICATE I certified that I have taken delivery of one APRILIA SR scooter bearing the following particulars: Engine No: Frame No: Colour / Model: Key No: Date of Sale: I have been explained by the dealer about correct and safe driving habits, warranty terms and conditions, service schedules and maintenance tips.
  • Page 111 I hear by declared the vehicle has been delivered to me in factory fresh condition to my satisfaction by the dealer (details provided below) and I have understood all the terms and conditions of warranty. I also declare that my personal data will be kept confidential by PVPL and can be only used by PVPL for certain products and marketing campaigns.
  • Page 112 DELIVERY CERTIFICATE I certified that I have taken delivery of one APRILIA SR scooter bearing the following particulars: Engine No: Frame No: Colour / Model: Key No: Date of Sale: I have been explained by the dealer about correct and safe driving habits, warranty terms and conditions, service schedules and maintenance tips.
  • Page 113 I hear by declared the vehicle has been delivered to me in factory fresh condition to my satisfaction by the dealer (details provided below) and I have understood all the terms and conditions of warranty. I also declare that my personal data will be kept confidential by PVPL and can be only used by PVPL for certain products and marketing campaigns.

  • Page 114: Service Coupons

    SERVICE COUPON SERVICE COUPON Valid if serviced between 250 - 750 Km or Valid if serviced between 250 - 750 Km or 0.5 - 1 month from the date of sale, whichever is earlier 0.5 - 1 month from the date of sale, whichever is rame No.
  • Page 115 1st Service Instructions to the servicing Dealer 1st Service Instructions to the servicing Dealer (Note: Refer the Maintenance schedule chart for more details) (Note: Refer the Maintenance schedule chart for more details) • Replace engine oil. • Replace engine oil. •...
  • Page 116 SERVICE COUPON SERVICE COUPON Valid if serviced between 2500 - 3000 Km or Valid if serviced between 2500 - 3000 Km or 2.5 - 3 month from the date of sale, whichever is earlier 2.5 - 3 month from the date of sale, whichever is Frame No.
  • Page 117 2 Service Instructions to the servicing Dealer 2 Service Instructions to the servicing Dealer (Note: Refer the Maintenance schedule chart for more details) (Note: Refer the Maintenance schedule chart for more details) • Inspect and top up (if required) engine oil. •...
  • Page 118 SERVICE COUPON SERVICE COUPON Valid if serviced between 5500 - 6000 Km or Valid if serviced between 5500 - 6000 Km or 5.5 - 6 month from the date of sale, whichever is earlier 5.5 - 6 month from the date of sale, whichever is Frame No.
  • Page 119 3 Service Instructions to the servicing Dealer 3 Service Instructions to the servicing Dealer (Note: Refer the Maintenance schedule chart for more details) (Note: Refer the Maintenance schedule chart for more details) • Replace engine oil. • Replace engine oil. •...
  • Page 120 SERVICE COUPON SERVICE COUPON Valid if serviced between 8500 - 9000 Km or Valid if serviced between 8500 - 9000 Km or 8.5 - 9 month from the date of sale, whichever is earlier 8.5 - 9 month from the date of sale, whichever Frame No.
  • Page 121 4 Service Instructions to the servicing Dealer 4 Service Instructions to the servicing Dealer (Note: Refer the Maintenance schedule chart for more details) (Note: Refer the Maintenance schedule chart for more details) • Inspect and top up (if required) engine oil. •...

  • Page 122: Ownership Record And Data

    PIAGGIO VEHICLES PVT. LTD. OWNERSHIP RECORD AND DATA NAME ADDRESS MODEL REGN. NO. ENGINE NO. FRAME NO. DATE OF PURCHASE KM READING DEALERS NAME ADDRESS BATTERY MAKE BATTERY SERIAL NO. DEALERS STAMP AND SIGNATURE...
  • Page 124 SERVICE RECORD SHEET Service Kms Range Service Date Kms at Service Job card No Servicing Dealer code and stamp...
  • Page 125 SERVICE RECORD SHEET Service Kms Range Service Date Kms at Service Job card No Servicing Dealer code and stamp Note: ' * ' Indicates these are fully paid services...
  • Page 126 SERVICE / JOB HISTORY RECORD DATE JOB CARD NO SERVICE / JOB DETAILS PARTS DETAILS SERVICING DEALER NAME...
  • Page 127 DATE JOB CARD NO SERVICE / JOB DETAILS PARTS DETAILS SERVICING DEALER NAME...

  • Page 128: General Information

    GENERAL INFORMATION For any feedback / query / requirements please contact your respective Zonal / Regional / Area Office Plant Delhi Office Chennai Office Piaggio Vehicles Pvt. Ltd. Piaggio Vehicles Pvt. Ltd. Piaggio Vehicles Pvt. Ltd. F-19, M.I.D.C Area, Baramati - 413 133 1st Floor, 6, Sant Nagar, Second Floor, MKV Towers Dist-Pune, Maharashtra.

This manual is also suitable for:

Sr 125
