Summary of Contents for Frico Thermocassette HP3

  • Page 1 Thermocassette HP ..6 ..10 ..12 ... 14 ..8 ... 16 ... 18...
  • Page 2 Thermocassette HP Minimum mounting distance Min.distance [mm] Ceiling (A) Wall, long side of the unit (B) Wall, short side of the unit (B) Flammable material (C) Floor (D) 1800 Fig. 1: Minimum mounting distance...
  • Page 3 Thermocassette HP Mounting Fig. 1 Fig. 2...
  • Page 4 Thermocassette HP Technical specifications | Thermocassette HP . Type E-nr [SE] EL-nr [NO] Output (1) Voltage (2) Amperage (3) Max. surface Weight (5) temperature (4) [°C] [kg] 85 700 21 230V~ 85 700 34 230V~ 10,7 Protection class: (IP55), jet-proof design. CE compliant.
  • Page 5: Output Control

    Thermocassette HP Wiring diagrams HP Internal wiring diagram 230V~ Output control K 1 2 U 3 4 U K G G 230V~ Control by thermostat 230V~ Thermostat...
  • Page 6 Thermocassette HP Mounting and assembly instruction General Instructions dismounting, T-profile 32x15: 150 mm, Read these instructions carefully before T-profile 38x24: 200 mm. NOTE! Avoid installation and use. Keep this manual for fixing vertical bars in the T-profile where a future reference. heating panel is to be installed.
  • Page 7 Thermocassette HP adjacent to the distribution board and it has to contain (drawing) the locations of the heating units. Replacement of cable 1. Because of limitations in the IP55 category the cable cannot be changed. 2. If the cable is damaged the unit has to be scrapped.
  • Page 11 Place this drawing adjacent to the distribution board OBS! – do not restrict the thermal emission of the heated ceiling – do not affix materials other than those recommended – do not insert nails or screws HP3, 300W, 220-240V HP6, 600W, 220-240V Drawing of the installation...
  • Page 12 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...

This manual is also suitable for:

Thermocassette hp6
