- Page 1 Original instructions Thermocassette HP ..9 ..13 ..15 ... 17 ..11 ... 19 ... 21...
- Page 2 Regulation also does not apply to installations in vehicles, offshore or outdoors. Many of Frico's products can be used as both local space heaters (as defined in (EU) 2015/1188) and for technical heating purposes. It is up to the installer responsible for the installation to assess whether the Ecodesign Regulation is applicable or not.
- Page 3 Также требования Экодизайн не применяются в случае установки оборудования в транспортных средствах, сооружениях на море и на открытых площадках. Многие виды оборудования Frico могут применяться как в качестве приборов локального обогрева (как определено нормативами (EU) 2015/1188) так и в качестве составных частей...
- Page 4 Thermocassette HP HP3N HP6N 1,8 m 1,8 m Minimum mounting distance [mm] 1800 Flammable material Fig. 1...
- Page 5 Thermocassette HP Mounting Fig. 1 Fig. 2...
-
Page 6: Technical Specifications
Thermocassette HP Technical specifications Type Output (1) Voltage (2) Amperage (3) Max. surface Weight (5) temperature (4) [°C] [kg] HP3N 230V~ HP6N 230V~ 10,7 Protection class: IP55 CE compliant. Complies with the requirements for flammable areas according to SEMKO 111FF. SE: Uppfyller kraven för brandfarliga rum enligt SEMKO 111FF . - Page 7 Thermocassette HP Accessories Type 74701 Wire mounting kit Controls Type HxWxD [mm] 87x87x53 TAP16R 87x87x55 TEP44 82x88x25 RTX54 TAP16R TEP44 RTX54 SKG30 115x85x40 SKG30 Controls for installations not covered by the Ecodesign Regulation (EU) 2015/1188 Type HxWxD [mm] 165x57x60 KRT1900 KRTV19 165x57x60 KRT1900...
-
Page 8: Wiring Diagram
Thermocassette HP Wiring diagram 230V~ TAP16R TAP16R 230V~ 230V~ T2 T1 SKG30 Controls for installations not covered by the Ecodesign Regulation (EU) 2015/1188 230V~ Thermostat... - Page 9 Thermocassette HP Installation and operating instructions General Instructions Bracket mounting See fig. 2 Read these instructions carefully before 1. Mounting height above floor shall be at installation and use. Keep this manual for least 1,8 m, and lateral distance to wall at future reference.
- Page 10 Thermocassette HP Control Safety When using this product as a local space • For all installations of electrically heated heater according to Ecodesign Regulation products should a residual current circuit (EU) 2015/1188, it must be supplemented breaker 300 mA for fire protection be used. with one of the following approved controls.
- Page 11 Place this drawing adjacent to the distribution board OBS! – do not restrict the thermal emission of the heated ceiling – do not affix materials other than those recommended – do not insert nails or screws HP3N, 300W, 220-240V HP6N, 600W, 220-240V Drawing of the installation...
- Page 12 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
