LTE TDD B40
LTE TDD B41
(100M BW)
SIM7100-PCIE(A) provides various hardware interfaces via Mini PCI Express card connector.
 Power supply: : 3.3V+0.3/-0.1V

USB Interface

Audio Interface
 UART Interface
 SIM Interface
 PCM Interface
 W_DISABLE#
 WAKE#
 PERST#
 LED_WWAN#
