CabControl settings

13.7 Assignment of buttons – Key Bindings
In the menu selection "Key Bindings" you can assign certain functions to
the hardware buttons (two on the left, two on the right-hand side of the
housing). The allocation is valid globally for all locomotives.
Figure 49: Set-up of assignment of buttons - overview
• Select the button you want to assign a function to.
• Choose the function to be assigned to this button from the list.
Figure 50: Assignment of functions – list of functions
***CONFIGURATION MENU / KEY BINDINGS***
22
14. CabControl Settings within the Configuration Menu
Once your CabControl ICU is connected to the Mobile Control II the "Cab-
Control Settings" Options will be active.
Figure 51: Configuration menu with CabControl
By pressing the "CabControl Settings" tab within the Configuration menu
you can enter into another group of settings.
Figure 52: CabControl Settings

14.1. Locomotive Takeover

This option allows you to ,,steal" a locomotive from another Mobile Control
II throttle.
