Accessories & routes
***CONSISTING VIDEO***
12. Accessories & routes
The top menu bar is similar to the control panel, only the switch
symbol has changed to a loco symbol. You can toggle back to the
control panel by pressing the loco symbol.

12.1. Panel mode (Route control)

On the next screen press the menu-button in the top right corner or the
hardware menu-button below the display and choose the option "create
panel".
On the next page you can enter a name and choose the items to be added to
the panel. At first, please enter a name, e.g. "panel 1". Confirm this name
on the keyboard.
Figure 39: MC II Switching mode – empty screen

12.2. New panel

• Select "Create panel" from the context menu
• Enter a name for the panel
Figure 40: New panel context menu

12.2.1 Creating new accessories

At first there will be no accessories to choose from. By touching the desired
position you can create a new accessory to control.
• Touch the desired position for placing the new accessory.
• Choose Create Accessory
• Name the Accessory
• Select the desired Accessory
Figure 41: Create Accessory
Similar to the menu "new locomotive" you have to enter a name and an
address first. Additionally, you have the choice of different symbols and ac-
cessory settings.
19
