HOW TO FOLD AND MOVE THE TREADMILL

HOW TO FOLD THE TREADMILL
Before folding the treadmill, adjust the incline to
the lowest position. If you do not do this, you
may damage the treadmill when you fold it.
Remove the key and unplug the power cord.
CAUTION: You must be able to safely lift 45 lbs.
(20 kg) to raise, lower, or move the treadmill.
1. Hold the metal frame firmly in the location shown
by the arrow below. CAUTION: Do not hold the
frame by the plastic foot rails. Bend your legs
and keep your back straight. Raise the frame
about halfway to the vertical position.
1
Frame
2. Hold the treadmill firmly with your right hand as
shown. Pull the latch knob to the left and hold it.
Raise the frame until the catch is past the latch pin.
Then, slowly release the latch knob; make sure
that the catch is resting against the latch pin.
To protect the floor or carpet, place a mat under the
treadmill. Keep the treadmill out of direct sunlight.
Do not leave the treadmill in the storage position in
temperatures above 85° F (30° C).
PITL50714_manual_UK_M01300.indd 13
HOW TO MOVE THE TREADMILL
Before moving the treadmill, fold it as described
at the left. CAUTION: Make sure that the catch is
resting against the latch pin. Moving the treadmill
may require two people.
1. Hold the frame and one of the handrails, and
place one foot against a wheel.
1
Frame
Handrail
Wheel
2. Pull back on the handrail until the treadmill will roll
on the wheels, and carefully move it to the desired
location. CAUTION: Do not move the treadmill
without tipping it back, do not pull on the frame,
and do not move the treadmill over an uneven
surface.
3. Place one foot against a wheel, and carefully
lower the treadmill.
HOW TO LOWER THE TREADMILL FOR USE
1. Hold the upper end of the treadmill with your right
hand as shown. Pull the latch knob to the left and
hold it. Next, lower the frame until it is past the latch
pin. Then, release the latch knob.
2. See drawing 1 at the left. Hold the metal frame
firmly with both hands, and lower it to the floor.
CAUTION: Do not hold the frame by the plastic
foot rails, and do not drop the frame. Bend your
legs and keep your back straight.
