Eaton Greengate PPS-5 Installation Instructions Manual

Installation Instructions
Outdoor Contact Input Photosensor
Photodétecteur extérieur à entrée par contact
Fotosensor de entrada de contacto para exteriores
General Information
The Outdoor Contact Input Photosensor (PPS-5) can be
used with any Greengate lighting controller. It is made
with a weatherproof casing allowing outdoor application
and can operate with temperatures from -40º to 158º F .
The photosensor is powered directly from the Greengate
Lighting Controller 24VDC peripheral power terminal.
Getting Started
1. Do not discard these installation instructions. Please
keep for future reference and operation information.
2. It is recommended that all low voltage wiring be
done with power removed to the logic board to
protect components from potential shorts during the
wiring process.
1. Use only as intended and at the listed voltage.
2. All installation and service must be performed by
qualified personnel or service technicians.
3. Install in accordance with the National Electrical Code
and any other codes which may apply.
4. Installation and wiring information contained in this
document is based on industry-accepted standards
and practices. If conflicts exist between these
instructions and any applicable codes or ordinances,
please contact Greengate before proceeding with the
installation.
5. High voltage is present inside the lighting enclosure.
Use extreme caution when performing maintenance
on this equipment.
6. Document all wiring and device terminations and
locations so that devices can be properly configured
and programmed for operation.
Model# PPS-5
Mounting Detail
Position the sensor so that the sensor window is north
facing and is not viewing artificial light from the controlled
load.
Mount the sensor on any approved weatherproof outdoor
box. Mounting stem screws into ½" – 14 threaded hole.
It can also be mounted in a ½" knockout ( 7/8" hole).
Make certain that connection is weather tight by using
suitable tape or sealant on the threading.
Wiring Detail
All low voltage wiring is Class 2 wiring. All low voltage
wiring must be run in separate conduit from line voltage
wiring. Failure to separate high voltage from low voltage
wiring may cause interference with lighting controller or
motion sensor function. Low voltage wiring must enter
the Greengate lighting controller enclosure through the
low voltage section of the enclosure.
Cabling should be 18 AWG twisted, three-conductor,
unshielded cable. Maximum length for dry contact closure
device wiring is 1000 feet.
Wiring the PPS-5 to a Lighting Controller
The PPS-5 photosensor wires to the low voltage switch
input channels on the lighting controller's logic board.
1. Connect the White wire to the ON of the input
channel.
2. Connect the Red wire to the +24 VDC of the input
channel.
3. Connect the Black wire to the Ground (GND)
connection on the peripheral power terminal.
INS #
