  • Page 1 METROLOGIC INSTRUMENTS, INC. ™ MS2122 Stratos E Installation and User’s Guide...
  • Page 2 Copyright © 2007 by Metrologic Instruments, Inc. All rights reserved. No part of this work may be reproduced, transmitted, or stored in any form or by any means without prior written consent, except by reviewer, who may quote brief passages in a review, or provided for in the Copyright Act of 1976.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS NTRODUCTION Manual Scope ..................................1 Product Overview ..................................1 Model Number Designation..............................2 Base Kit Components and Accessories ........................... 2 Replacement Parts................................... 3 General Precautions................................. 4 MS2122 Design Specifications..............................5 ODEL HARACTERISTICS MS2122 Scanner..................................6 Components ..................................6 Dimensions ..................................
  • Page 4 ABLE OF ONTENTS Power Save Modes ................................26 Beeper Options and Button Functions............................ 27 The Multi-Function Button ..............................27 Startup....................................28 Power-Up Test Mode ................................28 Configuration Mode ................................28 AINTENANCE Daily Maintenance.................................. 29 Horizontal Scan Window Replacement ..........................29 Vertical Scan Window Replacement ............................

  • Page 5: Manual Scope

    This guide provides an overview of the scanner and scanner operation with detailed information about setup and installation. ® ® Adobe Acrobat versions of the user's manuals are also available for download from the Metrologic website (www.metrologic.com). RODUCT VERVIEW Metrologic’s Stratos is designed to meet the demanding needs of high volume supermarket and point-of-sale applications.

  • Page 6: Model Number Designation

    CCESSORIES Part # Description MS2122* StratosE Scanner * See model number designation above for detailed information on interface type and window type. 00-02028x MS2122 StratosE Installation and User’s Guide 00-02407x MetroSelect ® Configuration Guide Stratos Series Configuration Addendum 00-02034x Guides also available for download at www.metrologic.com.

  • Page 7: Replacement Parts

    220V – 240V China 46-46928 220V – 240V Australia Other items may be ordered for the specific protocol being used. To order additional items, contact the dealer, distributor or call Metrologic’s Customer Service Department at 1-800-ID-METRO or 1-800-436-3876. EPLACEMENT ARTS...

  • Page 8: General Precautions

    NTRODUCTION ENERAL RECAUTIONS The following are some general precautions to remember when handling your MS2122 scanner. the unit upside down with the platter in place. Figure 2. RESS on the window in the replacement platter or the vertical window frame. Figure 3.

  • Page 9: Ms2122 Design Specifications

    NTRODUCTION MS2122 D ESIGN PECIFICATIONS Design Specifications Operational Light Source: VLD 650 nm Peak Laser Power: <2.2 mW Horizontal Depth of Field: 0 mm - 152 mm (0”- 6”) for 0.33 mm (13 mil) bar code Vertical Depth of Field: 0 mm - 216 mm (0”- 8.5”) for 0.33 mm (13 mil) bar code Scan Speed: 6000 scans lines per second...

  • Page 10: Base Model Characteristics Ms2122 Scanner

    ODEL HARACTERISTICS MS2122 Scanner Components Figure 6. MS2122 Components ESCRIPTION Blue and White LED Bar Volume/Tone Button (Multi-Function) Diamonex or Sapphire Horizontal Window (Laser Aperture) Flow Direction Indicator Stainless Steel Platter (Replaceable) Replaceable Vertical Window with High Impact Frame (Laser Aperture) Debris Guard Speaker Platter Support Channel and Alignment Guides...

  • Page 11: Dimensions

    ODEL HARACTERISTICS MS2122 Scanner Dimensions Figure 7. MS2122 Connectors Connector Panel Figure 8. MS2122 Connectors...

  • Page 12: Caution And Serial Number Labels

    ODEL HARACTERISTICS MS2122 Scanner Caution and Serial Number Labels Figure 9. MS2122 Label Locations (Top) and Examples (Bottom) Caution: To maintain compliance with applicable standards, all circuits connected to the scanner must meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950-1. To maintain compliance with standard CSA C22.2 No.

  • Page 13: Installation

    Ventilation and Spacing All Stratos models have a die-cast housing to dissipate heat allowing the unit to operate without a ventilation fan. Metrologic recommends that the temperature surrounding the unit does not exceed 40°C (104°F). There should be adequate convection and minimal heat producing equipment in close proximity of the unit.

  • Page 14: Unpacking The Unit

    NSTALLATION NPACKING THE Make sure the shipping box is top-side up before opening. Remove the accessories box and check its content for the following items. • Product Manuals • Power Supply • Communication Cable(s) Figure 10. Lift the scanner out of the shipping box by gripping the bottom of the unit on both sides.

  • Page 15: Option A: Two-Point Support

    NSTALLATION NSTALLING THE NIT IN THE OUNTER There are two options for mounting your MS2122 scanner. Option A, is a two-point mounting system that supports the unit at the front and back. Option B, is a three-point mounting system that supports the unit at the back and on the sides. Before starting to mount the MS2122 determine: •...

  • Page 16: Option B: Three-Point Support

    NSTALLATION NSTALLING THE NIT IN THE OUNTER Option B: Three-Point Support Figure 17. Option B, Three-Point Support...

  • Page 17: Interface:rs232

    Metrologic recommends using a switched AC outlet. The switch should be located on the operator’s side of the checkout counter in close proximity to the StratosE to facilitate service of the unit.

  • Page 18: Full Speed Usb (Integrated)

    The outlet should be located near the equipment and be easily accessible. Metrologic recommends using a switched AC outlet. The switch should be located on the operator’s side of the checkout counter in close proximity to the StratosE to facilitate service of the unit.

  • Page 19: Ibm 46Xx

    The outlet should be located near the equipment and be easily accessible. Metrologic recommends using a switched AC outlet. The switch should be located on the operator’s side of the checkout counter in close proximity to the StratosE to facilitate service of the unit.

  • Page 20: Ocia

    The outlet should be located near the equipment and be easily accessible. Metrologic recommends using a switched AC outlet. The switch should be located on the operator’s side of the checkout counter in close proximity to the StratosE to facilitate service of the unit.

  • Page 21: Secondary Scanner

    ABLE NSTALLATION The following steps describe how to properly install the cables between a secondary Metrologic scanner and the StratosE. The StratosE and the secondary scanner must then be configured to communicate properly. Cable installation alone does not guarantee that the StratosE will communicate properly with the host system and secondary scanner.

  • Page 22: Eas Deactivation

    SW1 & SW2 switches 1 and 6 set to ON The StratosE has a connector (marked EAS In) on the bottom of the scanner. Metrologic has an optional EAS cable 52-52511A) available for purchase for connection between the Checkpoint device and the StratosE.

  • Page 23: Scanner Operation Scan Zone

    CANNER PERATION Figure 25. Checker-Side (13 mil) Figure 26. Horizontal Left / Right (13 mil) Specifications are subject to change without notice.
  • Page 24 CANNER PERATION Figure 27. Horizontal Direct (13 mil) Figure 28. Vertical Direct (13 mil) Specifications are subject to change without notice.

  • Page 25: Ir Activation Area (Ir Led Output)

    CANNER PERATION Figure 29. Top-Down (13 mil) IR A CTIVATION † † The StratosE’s default power save mode is Dual Action Power Save Mode #2 (see page 26). This power save mode turns the laser OFF after a configured period of non-use then turns the motor OFF after thirty-minute intervals. Any movement detected by the IR in the activation area, shown below in grey, will cause the scanner to exit the power save mode.

  • Page 26: Indicator Descriptions

    CANNER PERATION NDICATOR ESCRIPTIONS Audible When in operation the StratosE provides audible feedback that indicates the status of the unit and the current scan. Eight settings are available for the tone of the beep (normal, 6 alternate tones and no tone) plus three volume settings. To change the tone or volume, refer to the Changing the Beeper Tone &...

  • Page 27: Failure Modes

    CANNER PERATION NDICATOR ESCRIPTIONS Visual Steady Blue When all lasers are active, the blue LED is illuminated. The blue LED will remain illuminated until all lasers are deactivated. Steady Blue and Single White Flash When the scanner successfully reads a bar code, the white LED will flash and the scanner will beep once. If the white LED does not flash or the scanner does not beep once, then the bar code has not been successfully read.

  • Page 28: Diagnostic Indicator Display

    CANNER PERATION NDICATOR ESCRIPTIONS Diagnostic Indicator Display There is a two-digit error code display located under the platter near the bottom right corner of the output window (see figure below). Figure 32. Diagnostic Indicator Display The following is a list of possible error codes and their meanings. Some errors will require immediate scanner maintenance. Error Description Code...
  • Page 29 CANNER PERATION NDICATOR ESCRIPTIONS Diagnostic Indicator Display Error Description Code LASER #1 (VERTICAL) ERROR – The laser in the vertical scanning subsystem denotes a failure. The scanner will try three times to correct the laser operation. If the laser error persists, the vertical scanning subsystem will be shut down and this error code will remain on the Diagnostic Indicators.

  • Page 30: Power Save Modes

    CANNER PERATION OWER ODES The MS2122 has five configurable power save modes. Refer to the MetroSelect Configuration Guide ( 00-02407x) for MLPN additional information on Power Save Modes. Blink Power Save Mode: Blinks the laser OFF & ON after a configured period of non-use. When the scanner recognizes a bar code it will exit the Blink mode.

  • Page 31: Beeper Options And Button Functions

    CANNER PERATION EEPER PTIONS AND UTTON UNCTIONS Changing the Beeper Tone Beeper tones may be configured directly or incrementally using the following bar code. The new tone will be heard followed by a short pause. Two more new tones will be heard signifying the new setting has been stored in memory. The silent (no beep) tone is also selectable.

  • Page 32: Startup

    ONFIGURATION All MS2122 scanners have been configured at the factory with a set of default communication protocols. Since many host systems have unique formats and protocol requirements, Metrologic provides a wide range of configurable features that may ® be selected with the use of the MetroSelect...

  • Page 33: Maintenance Daily Maintenance

    AINTENANCE AILY AINTENANCE Smudges and dirt can interfere with the proper scanning of a bar code. Therefore, the output window will need occasional cleaning. For the glass window: Spray glass cleaner onto lint free, non-abrasive cleaning cloth. Gently wipe the scanner window. For the red window: Use mild soap and water with lint free, non-abrasive cleaning cloth.

  • Page 34: Vertical Scan Window Replacement

    AINTENANCE ERTICAL INDOW EPLACEMENT Figure 38. Vertical Scan Window Replacement...

  • Page 35: Troubleshooting

    ROUBLESHOOTING The following guide is for reference purposes only. Contact a Metrologic representative at 1-800-ID-METRO or 1-800-436-3876 to preserve the limited warranty terms. Symptom Possible Cause(s) Solution All Interfaces No LEDs, beep or motor No power is being supplied to Check the transformer, outlet and the power strip.
  • Page 36 The auxiliary input port’s data format must match the main output format of the secondary scanner. * Refer to the MS2xxx Stratos Series Configuration Addendum ( 00-02034x) under Scanner Configuration Bar Codes: MLPN Auxiliary Port, Quick Start for a Secondary Metrologic Scanner.

  • Page 37: Rs232 Demonstration Program

    ROUBLESHOOTING RS232 D EMONSTRATION ROGRAM If an RS232 scanner is not communicating with your IBM compatible PC, key in the following BASIC program to test that the communication port and scanner are working. This program is for demonstration purposes only. It is only intended to prove that cabling is correct, the com port is working, and the scanner is working.

  • Page 38: Default Settings

    EFAULT ETTINGS OMMUNICATION ARAMETERS Many functions of the scanner can be "configured" - that is, enabled or disabled. The scanner is shipped from the factory pre- configured to a set of default conditions. The default parameter of the scanner has an asterisk ( * ) in the charts on the following pages.
  • Page 39 EFAULT ETTINGS OMMUNICATION ARAMETERS OCIA RS232 IBM 46 ARAMETER EFAULT Expanded ID “]e0” RSS Limited Enable RSS Limited ID “]e0” RSS Limited App ID “01” RSS Limited Check Digit DTS/SIEMENS DTS/NIXDORF NCR F NCR S Beeper Tone Normal Beep Transmit Sequence Before Transmit Beeper Volume Loudest...
  • Page 40 EFAULT ETTINGS OMMUNICATION ARAMETERS OCIA RS232 IBM 46 ARAMETER EFAULT Number of Scan Buffers UPC GTIN-14 Format EAN-8 Enable Transmit EAN-8 Check Digit Convert EAN-8 to EAN-13 EAN-8 with Small Borders EAN-13 Enable Transmit EAN-13 Check Digit UPC-A Enable Convert UPC-A to EAN-13 Transmit UPC-A Check Digit Transmit UPC-A Number System Transmit UPC-A Manufacturers ID.
  • Page 41 Activate on DC2 Character Xmit No Read Message on DC2 Timeout No Transmit LED During No Read Message Configurable “No Read” Message Recv “I” = Transmit “METROLOGIC” Recv “i” = Transmit Scanner ID Byte STX Prefix TAB Prefix Metrologic Prefix...
  • Page 42 EFAULT ETTINGS OMMUNICATION ARAMETERS OCIA RS232 IBM 46 ARAMETER EFAULT Carriage Return Suffix Line Feed Suffix UPC Suffix Transmit LRC Start LRC on 1 Byte Start LRC on 2 Byte ‘c’ Prefix for UPC ‘$’ Prefix for UPC Configurable Prefix Characters 10 avail Configurable Suffix Characters 10 avail...
  • Page 43 EFAULT ETTINGS OMMUNICATION ARAMETERS OCIA RS232 IBM 46 ARAMETER EFAULT German 434/439 Supplements Convert Bookland to ISBN Bookland 979 Supplements Convert 979 to ISBN Convert 290 to ISBN Reformat ISBN Add EAN Article ID Transmit ISBN / EAN Check Digit 977 Supplements (2-digit) Convert 977 to ISSN Reformat ISSN...

  • Page 44: Scanner And Cable Terminations

    CANNER AND ABLE ERMINATIONS CANNER INOUT ONNECTIONS The MS2122 scanner interfaces terminate to 10-pin modular jacks located on the bottom of the units. The serial number label indicates the model number of the scanner. Auxiliary RS232 In Function Function EAS In Signal Ground EAS Out RS232 Receive Input...

  • Page 45: Cable Connector Configurations

    CANNER AND ABLE ERMINATIONS ABLE ONNECTOR ONFIGURATIONS Cable Connector Configurations RS232 Interface Cable, 57-57000x-N-3 MLPN Function Signal Ground RS232 Transmit Output RS232 Receive Input DTR Input Power/Signal Ground Reserved 9-Pin D-Type Connector CTS Input RTS Output +5VDC From Host Full Speed USB Cable, 57-57200x-N-3 MLPN Function...
  • Page 46 CANNER AND ABLE ERMINATIONS ABLE ONNECTOR ONFIGURATIONS Cable Connector Configurations Aux Port Configuration Cable*, 57-57008x-N-3 MLPN Function No Connect Output from the Scanner Input to the Scanner No Connect 9-Pin D-Type Connector Ground 6 - 9 No Connect RS232 LSO/AUX Cable, 57-57099x-3 MLPN †...

  • Page 47: Regulatory Compliance Safety

    EGULATORY OMPLIANCE AFETY ITE Equipment IEC 60950-1; EN 60950-1 Laser Laser Class 1: IEC 60825-1:1993+A1+A2, EN: 60825-1:1994+A1+A2 Caution Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser light exposure. Under no circumstances should the customer attempt to service the laser scanner. Never attempt to look at the laser beam, even if the scanner appears to be nonfunctional.

  • Page 48: Emc

    EGULATORY OMPLIANCE Emissions: FCC Part 15, ICES-003, CISPR 22, EN 55022 Immunity: CISPR 24, EN 55024 Class A Devices The following is applicable when the scanner cable is greater in length than 3 meters (9.8 feet) when fully extended: Les instructions ci-dessous s’appliquent aux cables de scanner dépassant 3 métres (9.8 pieds) de long en extension maximale: Folgendes trifft zu, wenn das Scannerkabel länger als 3 Meter ist: This equipment has been tested and found to comply with limits for a Class A digital device, pursuant to part 15 of the FCC...
  • Page 49 EGULATORY OMPLIANCE Class B Devices The following is applicable when the scanner cable is less than 3 meters (9.8 feet) in length when fully extended: Les instructions ci-dessous s’appliquent aux cables de scanner ne dépassant pas 3 métres (9.8 pieds) de long en extension maximale: Folgendes trifft zu, wenn das Scannerkabel kürzer als 3 Meter ist: This device complies with Part 15 of the FCC Rules.

  • Page 50: Limited Warranty

    This warranty is limited to repair, replacement of product or refund of product price at the sole discretion of Metrologic. Faulty equipment must be returned to one of the following Metrologic repair facilities: Blackwood, New Jersey, USA; Madrid, Spain;...

  • Page 51: Patents

    ATENTS Patent Information For patent information, please refer to www.honeywellaidc.com/patents.

  • Page 53: Index

    NDEX AC ..............see power handles ..............5, 8, 12 accessories ..............12 host ........24, 25, 33–35, 36–42, 36–42 aperture.................4, 8 application ..............26, 35 audible............see indicators IBM 46xx ..........36–42, see interface AUX................8, 34 indicators audible..........6, 24, 30, 37, 38, 39 beep ...............6, 30 beep ..............see indicators diagnostic .............26–27...
  • Page 54 NDEX transformer............see power safety.................47, 48 troubleshooting............33–35 scan zone..............21–23 scanner pinouts..............43–45 secondary scanner ............19 USB............ 36–42, see interface SELV .................15–18 specifications electrical .............6–7, 11 ventilation ..............6, 11 environmental ............6–7 visual................25 mechanical ...............6–7 voltage .............. 4, 6, 15–18 operational..............6–7 volume ................8, 29 storage ................6 switch ................20 warranty ..............33, 49...
  • Page 56 March 2008 0 0 - 0 2 0 2 8 C...
