SIM900D Hardware Design

ringtones or alert tones. The tone level can be adjusted over a 24 dB range in 4 dB steps, or it can be muted.

Table24: Pin definition of the PWM

Pin Name

PWM

SIM900D_Hardware Design_V1.04

Pin Number

47

Pulse-Width Modulator Signal

52

2010.10.09
