INSTALLATION AND OWNER'S MANUAL
24-3/4"
Serial #:
Date Installed:
Your Dealer:
MODEL CSWI & DSWI
Swing Gate Operator
UL 325 and UL 991 Listed
(MTG. HOLE PATTERN 20-1/2" X 20")
(FOOT PRINT 22" X 26")
WITH NEW NITRO BOARD
(INSTRUCTIONS INCLUDED)
READ THIS MANUAL CAREFULLY
BEFORE INSTALLATION OR USE.
SAVE THESE INSTRUCTIONS.
20-1/2"
22"
22"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSWI and is the answer not in the manual?

Questions and answers

Related Manuals for PowerMaster CSWI

Summary of Contents for PowerMaster CSWI

  • Page 1 INSTALLATION AND OWNER’S MANUAL MODEL CSWI & DSWI Swing Gate Operator UL 325 and UL 991 Listed 24-3/4” 22” 20-1/2” (MTG. HOLE PATTERN 20-1/2” X 20”) 22” (FOOT PRINT 22” X 26”) WITH NEW NITRO BOARD (INSTRUCTIONS INCLUDED) Serial #:...

  • Page 2: Table Of Contents

    Table of Contents Model CSWI/DSWI Swing Gate Operator Important Safety Information ..................3 UL Installation and Safety Considerations ..............4 System Designer Safety Instructions..............5 Installer Safety Instructions ................6-7 End User Safety Warnings ................. 8-9 Installation & Setup Procedure Before Installing Operator .................10 Installation of Cement Pad ................11...

  • Page 3: Important Safety Information

    IMPORTANT! FOR SWING GATE OPERATING SYSTEMS, SAFETY IS EVERYONE’S BUSINESS. Automatic gate operators provide convenience and security to users. However, because these machines can produce high levels of force, it is important that all gate operator system designers, installers, and end users be aware of the potential hazards associated with improperly designed, installed, or maintained systems.

  • Page 4: Ul Installation And Safety Considerations

    UL INSTALLATION AND SAFETY CONSIDERATIONS INSTALLATION CLASSES CLASS I - RESIDENTIAL VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in a home of one to four single-family dwellings, or a garage or parking area associated therewith. CLASS II –...

  • Page 5: System Designer Safety Instructions

    SYSTEM DESIGNER SAFETY INSTRUCTIONS ▲ 1. Familiarize yourself with the precautions and warnings for the installer. Users are relying on your design to provide a safe installation. ▲ 2. The operator is supplied with a primary obstruction sensing entrapment protection system. The installation must also have a secondary entrapment protection system installed, such as photoelectric sensors or an electric edge system.

  • Page 6: Installer Safety Instructions

    INSTALLER SAFETY INSTRUCTIONS BEFORE INSTALLATION ▲ 1. Check to see that the operator is proper for this type and size of gate and its frequency of use. If you are not sure, consult factory. ▲ 2. Check to see that there are no structures adjacent to the area, which may pose a risk of entrapment when gate is opening or closing.

  • Page 7: After Installation

    ▲ Control 5. Locate the controls at Station least 10 feet from the moving gate so that the user can observe 10 feet the gate operation, but is not able to come in 10 feet contact with the gate while operating the controls.

  • Page 8: End User Safety Warnings

    END USER SAFETY WARNINGS The manufacturer of the gate operator does not know what type of gate you have, or what type of automatic system is installed on your gate. Be sure you’ve been fully instructed on the sequence of operation for your specific gate system(s). Keep the gate properly maintained and have a qualified service person make repairs.
  • Page 9 ▲ DO NOT increase force adjustment to compensate for a damaged gate. The gate should always be maintained to operate manually as easily as possible to provide maximum protection. ▲ 10. Check all safety systems at least once per month for the correct force, speed and sensitivity.

  • Page 10: Before Installing Operator

    INSTALLATION INSTRUCTIONS & SET-UP PROCEDURE DO NOT APPLY POWER UNTIL TOLD TO DO SO! RISK WARNING OF ELECTRICAL SHOCK OR INJURY MAY RESULT! BEFORE INSTALLING OPERATOR IMPORTANT: Operator should always be mounted inside the gate. Determine whether the installation is Left hand or Right hand by the direction the gate moves in order to open, when viewed from inside the fence.

  • Page 11: Installation Of Cement Pad

    CSWI & DSWI CEMENT PAD LAYOUT 1. Lay out per drawing below. 2. Locate electrical conduit and mounting bolts. Note: Bolt pattern must be parallel to fence line as shown. 3. Pour cement, ensuring top surface is level and allow 2 days cure time before installing operator.

  • Page 12: Installation Of Operator

    OPERATOR INSTALLATION 1. Mount operator on cement pad, locating electrical conduit under access hole, and secure position with 1/2 inch hardware. 2. Set control arm on output shaft of operator without drive key, and install control arm extension using hand knobs to secure position. The diagram below shows the correct holes to start with.
  • Page 13 5. Locate gate bracket in position on gate, as shown below, and clamp in position. 6. Move control arm to its maximum close position. Arm assembly should be in locked position against stop bracket. 36" Gate Hinge Of Gate Connecting Rod Assembly Gate Control Arm Bracket...

  • Page 14: Manual Operation

    MANUAL OPERATION Disconnect operator control linkage in order to manually operate the gate as follows: 1. Unscrew and remove (2) hand knob bolts connecting control arm extension to control arm. 2. Lift control arm extension with linkage off of control arm. 3.

  • Page 15: Electrical Connections

    ELECTRICAL SET-UP AND CONNECTIONS DO NOT APPLY POWER UNTIL TOLD TO DO SO! RISK WARNING OF ELECTRICAL SHOCK OR INJURY MAY RESULT! CONNECTION OF INCOMING POWER NOTE: Before connecting the operator to an incoming power supply, use a voltmeter to determine that the electrical service is the same as that on the operator label.

  • Page 16: Limit Adjustment

    LIMIT ADJUSTMENT PROCEDURE WARNING WARNING READ ENTIRE PROCEDURE BEFORE STAY CLEAR OF ALL MOVING PARTS STARTING. TURN OFF MAIN POWER AND ELECTRICAL COMPONENTS OF BEFORE MAKING ANY ADJUSTMENTS! THE OPERATOR WHILE TESTING! NOTE: Operator should be completely installed, mechanically and electrically, before attempting to set limit switch cams.

  • Page 17: Nitro Insert

    SUPPLEMENTARY INSTRUCTION MANUAL for units equipped with PowerMaster Nitro Board...
  • Page 18 NITRO QUICK SETUP BEFORE MAKING ELECTRICAL MECHANICALLY INSTALL ENSURE GATE MOVES CONNECTIONS MAKE SURE POWER GATE OPERATOR SMOOTHLY IN BOTH IS TURNED OFF AT SOURCE NOTE: SEE MANUAL. DIRECTIONS. CONNECT INCOMING POWER SET LIMIT NUTS TO TO PREVENT RISK OF PERSONAL INJURY OR DEATH: CENTER OF TRAVEL DISCONNECT POWER AT THE...
  • Page 19 WARNING: These operators have been designed and constructed for use with voltages from 115 to 460 VAC. Check the operator nameplate label on the control box cover for the proper voltage and phase. The application of an improper input voltage or phase will result in catastrophic failure to the internal electrical components.
  • Page 20 WARNING WARNING: Control voltage of the TO PREVENT THE RISK OF PERSONAL INJURY door operator is 5 AND / OR DAMAGE TO DOOR OR PROPERTY, volts DC, Class 2. Do ONLY OPERATE DOOR CONTROL WHEN DOOR IS not run the power IN CLEAR VIEW.

  • Page 21: Lcd Display

    1 Board Interface LCD Navigation On Board 3-Button Controls The board is equipped with UP, DOWN, The board is equipped with OPEN, BACK, and ENTER buttons located to CLOSE, and STOP buttons located the upper right corner of the board. to the right side of the board.
  • Page 22 2 Headers Encoder Limits Expansion Headers 3 Wire Header DC Motor Header AC Motor Header Expansion Module Header Radio Header Nitro 6...
  • Page 23 3 Terminals Horn Terminal Brake Terminal Power Terminal 24 VDC Terminal Strip Nitro7...
  • Page 24 4 Setup Wizard Setup Introduction 1. To begin setting up the operator press the ENTER button. Operator Type 1. To select the correct operator type press the UP and DOWN buttons. 2. Once the desired operator type is selected, press the ENTER button. Operator Select 1.
  • Page 25 Handedness 1. To select the correct hand press the UP and DOWN buttons. 2. Once the desired hand is selected press the ENTER button. NOTE: The hand of the operator is the side of the driveway the operator is on from the inside looking out.
  • Page 26 Close Force Setup 1. By holding the CLOSE button run the operator from the FULLY OPEN position all the way to the CLOSE LIMIT. 2. Once the operator is at the FULLY CLOSED position press the ENTER button. NOTE: The close current setting adjusts the maximum current allowed to operate the door/gate in the close direction.
  • Page 27 5 Status 6 Menu Overview 7 Basic Programming Nitro11...

  • Page 28: Dual Gate

    Handing 1. When the pointer is at HANDING press the ENTER button. 2. To select the correct hand press the UP and DOWN buttons. 3. Once the desired hand is selected press the ENTER button. NOTE: The hand of the operator is the side of the driveway the operator is on from the inside looking out.
  • Page 29 Auto Close Time 1. When the pointer is at AUTO CLOSE TIME press the ENTER button. 2. By pressing the UP and DOWN buttons set the adjusted time for the auto close timer. 3. Once the desired time is set press the ENTER button.
  • Page 30 Open Current 1. When the pointer is at OPEN CUR- RENT press the ENTER button. 2. By pressing the UP and DOWN buttons set the maximum current for the open current setting. 3. Once the desired current is set press the ENTER button.
  • Page 31 Stop Contact 1. When the pointer is at STOP CON- TACT press the ENTER button. 2. By pressing the UP and DOWN buttons set Normally Open or Normally Close. 3. Once the desired contact is set press the ENTER button. NOTE: Stop Contact set’s whether the STOP contact is Normally Open or Nor- mally Close.
  • Page 32 Close Safety 1. When the pointer is at CLOSE SAFETY press the ENTER button. 2. By pressing the UP and DOWN buttons select the desired setting. 3. Once the desired setting is selected press the ENTER button. NOTE: Close safety will detect an obstruction during closing while the gate is moving.
  • Page 33 Aux Relay 1. When the pointer is at AUX RELAY press the ENTER button. 2. By pressing the UP and DOWN buttons select the desired setting. 3. Once the desired setting is selected press the ENTER button. •Aux Relay Off: the auxiliary relay will be disabled •Maglock: the magnetic gate lock will be enabled during pending or actual motion (open/close) •Strobe: the warning strobe light will be enabled during pending or actual motion...
  • Page 34 Soft Stop 1. When the pointer is at SOFT STOP press the ENTER button. 2. By pressing the UP and DOWN buttons select the desired setting. 3. Once the desired setting is selected press the ENTER button. NOTE: The soft stop feature will cause the operator to stop the DC motor slowly. This reduces gate malfunctions from wear and tear as well as an overload of cur- rent.
  • Page 35 9 About Cycle Count 1. When the pointer is at CYCLE COUNT press the ENTER button. 2. The cycle count will then be displayed. NOTE: The cycle count shows the number of cycles the operator has run for. 1 cycle is considered a full open and close motion. Revision 1.
  • Page 36 Language 1. When the pointer is at LANGUAGE press the ENTER button. 2. By pressing the UP and DOWN buttons select the desired setting. 3. Once the desired setting is selected press the ENTER button. NOTE: This setting allows the user to change the language for the LCD. Currently English and Spanish are supported.
  • Page 37 Setup Wizard 1. When the pointer is at SETUP WIZ- ARD press the ENTER button. 2. By pressing the ENTER button, the setup wizard will run. Incoming Voltage 1. When the pointer is at Incoming Voltage press the ENTER button. 2.
  • Page 38 10 Lockout Low Voltage: Reason: This lockout occurs when the total voltage of the system is below 21.5 volts. Fix: Restore voltage to above 21.5 volts. • Make sure that no fuses are blown and that there is adequate AC power. •...
  • Page 39 Motor Not Detected: Reason: This lockout occurs when the circuit board does not detect a that a motor is present. Fix: Press the STOP button on the circuit board. • Check that the motor overload isn’t tripped. • Check the motor wiring is correct and not damaged.
  • Page 40 Terminal Characteristics Terminal Voltage Description 0 VDC Ground connection OPEN 24-30 VAC Open command. This is a NO connection. CLOSE 24-30 VAC Close command. This is a NO connection. STOP 5 VDC Stop command. Can be configured NO or NC 5 VDC Auxiliary open command.

  • Page 41: Loop Detector Systems

    LOOP DETECTOR SYSTEMS AND INSTALLATION Figure 10 depicts the typical loop options for a Swing Gate installation. 1. The Exit Loop provides a signal to open the gate when a vehicle enters the loop zone. 2. The Reversing Loop protects a vehicle in the loop zone from Approx.
  • Page 42 2. Cut the required groove at the locations laid out according to the diagram below (Figure 11). Loop Wire (See Chart) Lead In Wire (Twisted at 6 turns per foot) 1/2” Conduit Conduit Cut 3/16” to 1/4” 1” to 2” 1”...

  • Page 43: Clutch Adjustment

    CLUTCH ADJUSTMENT NOTE: The clutch comes pre-adjusted from the factory and will function properly for the majority of installations. NEVER INCREASE FORCE SETTING TO MAKE UP FOR A GATE WARNING THAT IS NOT MAINTAINED PROPERLY. THIS WILL DESENSITIZE THE OPERATION OF THE SAFETY SYSTEM. If more sensitivity is desired on a light gate: Turn OFF power on electric plate.

  • Page 44: Secondary Obstruction Sensing Devices

    SECONDARY OBSTRUCTION SENSING DEVICES Another sensing device (either a contact or a non-contact system) must be installed and connected to this unit to increase protection against entrapment per UL requirements. NOTE: All safety device contacts must be NORMALLY OPEN. NOTE: 24 VAC power is available at marked terminals for devices that may require it (e.g. photo eyes, loop detectors, radio controls.
  • Page 45 CONTACT SENSOR INSTALLATION NOTE: Wireless sensors must be installed so there is no signal interference. NOTE: All hard wiring to safety edges must be installed so there is no threat of mechanical damage to Electric Edge Mounted on wiring between components when Outside Bottom of Gate the gate is moving.

  • Page 46: Non-Contact - Photo Eyes

    NON-CONTACT SENSOR INSTALLATION 1. Install photoelectric cell as close to FULL OPEN and FULL CLOSED Photo Electric Cell (For open direction) position of gate as possible. 2. Photocells should be installed across the gate opening and behind the gate at least 10 inches above ground (see image).

  • Page 47: Warranty

    A one year warranty applies if product has not been registered. ELECTRICAL PARTS (including boards, switches, relays, etc): PowerMaster warrants electrical parts for a two (2) year period, provided that product has been registered. A one year warranty applies if product has not been registered.
  • Page 48 Need Technical Support? Visit: www.PowerMasterNY.com/technical-information Call us toll free @ 1-800-243-4476 Email us: PMtech@PowerMasterNY.com /PowerMasterOperators /PowerMaster /company/PowerMaster Scan QR Code with your Smart phone to find us on the web! MANUFACTURED BY V.E. POWER DOOR CO,INC. www.PowerMasterNY.com REV 2020-0120...
