INSTALLATION AND OWNER'S MANUAL
24-3/4"
*NOTE: FOR DSWI UNITS, REFER TO POWERMASTER CONTROL BOARD MANUAL
Serial #:
Date Installed:
Your Dealer:
MODEL CSWI & DSWI
Swing Gate Operator
UL 325 and UL 991 Listed
(MTG. HOLE PATTERN 20-1/2" X 20")
(FOOT PRINT 22" X 26")
FOR CIRCUIT BOARD INFORMATION.
READ THIS MANUAL CAREFULLY
BEFORE INSTALLATION OR USE.
SAVE THESE INSTRUCTIONS.
20-1/2"
22"
22"
Advertisement
Table of Contents
Related Manuals for PowerMaster DSWI
Summary of Contents for PowerMaster DSWI
- Page 1 24-3/4” 22” 20-1/2” (MTG. HOLE PATTERN 20-1/2” X 20”) 22” (FOOT PRINT 22” X 26”) *NOTE: FOR DSWI UNITS, REFER TO POWERMASTER CONTROL BOARD MANUAL FOR CIRCUIT BOARD INFORMATION. Serial #: Date Installed: READ THIS MANUAL CAREFULLY Your Dealer: BEFORE INSTALLATION OR USE.
-
Page 2: Table Of Contents
Table of Contents Model MSW Medium Duty Swing Gate Operator Important Safety Information ..................3 UL Installation and Safety Considerations ..............4 System Designer Safety Instructions..............5 Installer Safety Instructions ................6-7 End User Safety Warnings ................. 8-9 Installation & Setup Procedure Before Installing Operator .................10 Installation of Cement Pad ................11 Installation of Operator ................ -
Page 3: Important Safety Information
IMPORTANT! FOR SWING GATE OPERATING SYSTEMS, SAFETY IS EVERYONE’S BUSINESS. Automatic gate operators provide convenience and security to users. However, because these machines can produce high levels of force, it is important that all gate operator system designers, installers, and end users be aware of the potential hazards associated with improperly designed, installed, or maintained systems. -
Page 4: Ul Installation And Safety Considerations
UL INSTALLATION AND SAFETY CONSIDERATIONS INSTALLATION CLASSES CLASS I - RESIDENTIAL VEHICULAR GATE OPERATOR A vehicular gate operator (or system) intended for use in a home of one to four single-family dwellings, or a garage or parking area associated therewith. CLASS II –... -
Page 5: System Designer Safety Instructions
SYSTEM DESIGNER SAFETY INSTRUCTIONS ▲ 1. Familiarize yourself with the precautions and warnings for the installer. Users are relying on your design to provide a safe installation. ▲ 2. The operator is supplied with a primary obstruction sensing entrapment protection system. The installation must also have a secondary entrapment protection system installed, such as photoelectric sensors or an electric edge system. -
Page 6: Installer Safety Instructions
INSTALLER SAFETY INSTRUCTIONS BEFORE INSTALLATION ▲ 1. Check to see that the operator is proper for this type and size of gate and its frequency of use. If you are not sure, consult factory. ▲ 2. Check to see that there are no structures adjacent to the area, which may pose a risk of entrapment when gate is opening or closing. -
Page 7: After Installation
▲ Control 5. Locate the controls at Station least 10 feet from the moving gate so that the user can observe 10 feet the gate operation, but is not able to come in 10 feet contact with the gate while operating the controls. -
Page 8: End User Safety Warnings
END USER SAFETY WARNINGS The manufacturer of the gate operator does not know what type of gate you have, or what type of automatic system is installed on your gate. Be sure you’ve been fully instructed on the sequence of operation for your specific gate system(s). Keep the gate properly maintained and have a qualified service person make repairs. - Page 9 ▲ DO NOT increase force adjustment to compensate for a damaged gate. The gate should always be maintained to operate manually as easily as possible to provide maximum protection. ▲ 10. Check all safety systems at least once per month for the correct force, speed and sensitivity.
-
Page 10: Before Installing Operator
INSTALLATION INSTRUCTIONS & SET-UP PROCEDURE DO NOT APPLY POWER UNTIL TOLD TO DO SO! RISK WARNING OF ELECTRICAL SHOCK OR INJURY MAY RESULT! BEFORE INSTALLING OPERATOR IMPORTANT: Operator should always be mounted inside the gate. Determine whether the installation is Left hand or Right hand by the direction the gate moves in order to open, when viewed from inside the fence. -
Page 11: Installation Of Cement Pad
CSWI & DSWI CEMENT PAD LAYOUT 1. Lay out per drawing below. 2. Locate electrical conduit and mounting bolts. Note: Bolt pattern must be parallel to fence line as shown. 3. Pour cement, ensuring top surface is level and allow 2 days cure time before installing operator. -
Page 12: Installation Of Operator
OPERATOR INSTALLATION 1. Mount operator on cement pad, locating electrical conduit under access hole, and secure position with 1/2 inch hardware. 2. Set control arm on output shaft of operator without drive key, and install control arm extension using hand knobs to secure position. The diagram below shows the correct holes to start with. - Page 13 5. Locate gate bracket in position on gate, as shown below, and clamp in position. 6. Move control arm to its maximum close position. Arm assembly should be in locked position against stop bracket. 36" Gate Hinge Of Gate Connecting Rod Assembly Gate Control Arm Bracket...
-
Page 14: Manual Operation
MANUAL OPERATION Disconnect operator control linkage in order to manually operate the gate as follows: 1. Unscrew and remove (2) hand knob bolts connecting control arm extension to control arm. 2. Lift control arm extension with linkage off of control arm. 3. -
Page 15: Electrical Connections
ELECTRICAL SET-UP AND CONNECTIONS DO NOT APPLY POWER UNTIL TOLD TO DO SO! RISK WARNING OF ELECTRICAL SHOCK OR INJURY MAY RESULT! CONNECTION OF INCOMING POWER NOTE: Before connecting the operator to an incoming power supply, use a voltmeter to determine that the electrical service is the same as that on the operator label. -
Page 16: Left Hand/Right Hand Conversion
Swings RIGHT to open is a right hand installation; swings LEFT to open is a left hand installation. NOTE: FOR DSWI UNITS AND CSWI UNITS WITH THE POWERMASTER CONTROL BOARD (BLUE), PLEASE REFER TO THE POWERMASTER CONTROL BOARD MANUAL INCLUDED WITH YOUR OPERATOR. -
Page 17: Connection Of A Three Button Station
CONNECTION OF A THREE-BUTTON STATION NOTE: All control contacts must be PO ER OPEN NORMALLY OPEN unless Dipswitch #3 PUSH L MT FREE LOOP LD11 OPEN ED E LD12 RADO CLOSE ED E is placed to the ON position, which will RH OP N RADO LH CL O... -
Page 18: Master/Slave Installation
MASTER-SLAVE INSTALLATION NOTE: A single unit is considered a Master. In a Master/Slave installation, one unit must be converted to LEFT HAND operation. 1. Place Dipswitch #5 on the Master operator’s control board in the OFF position. 2. Place Dipswitch #5 on the Slave operator’s control board in the ON position. MASTER OPERATOR SLAVE OPERATOR CONTROL BOARD... -
Page 19: Limit Adjustment
LIMIT ADJUSTMENT PROCEDURE WARNING WARNING READ ENTIRE PROCEDURE BEFORE STAY CLEAR OF ALL MOVING PARTS STARTING. TURN OFF MAIN POWER AND ELECTRICAL COMPONENTS OF BEFORE MAKING ANY ADJUSTMENTS! THE OPERATOR WHILE TESTING! NOTE: Operator should be completely installed, mechanically and electrically, before attempting to set limit switch cams. -
Page 20: Emergency Control Station
EMERGENCY CONTROL STATION OPTION Provision has been made to change the POWER LD18 LD19 OPEN control station operational mode to one LIMIT PUSH LD10 FREE LOOP that would only be activated when the OPEN LD11 EDGE LD12 RADIO entrapment sensing system is in stop mode; CLOSE OPN/ EDGE... -
Page 21: Auxiliary Circuit
AUXILIARY CIRCUIT FOR USE WITH GATE LOCKS, WARNING LIGHTS, ETC. An auxiliary 24VAC power circuit (for use with a 24V control relay) has been provided. This circuit will be activated just prior to gate movement and will continue to be active until the gate stops. -
Page 22: Accessory Connections
ACCESSORY CONNECTIONS RADIO CONTROL INSTALLATION A three or four wire radio control receiver can be installed on this operator. This radio control receiver can only be used to open the gate, therefore the TIMER TO CLOSE option must be activated for closing. NOTE: If your radio’s connecting wires are not color coded COMMON... -
Page 23: Cutting The Required Groove
STANDARD LOOP LAYOUTS FOR APPROX. 36” HEIGHT DETECTION CAUTION: The loop wires LOOP WIRE LOOP SIZE # OF TURNS LENGTH (FT) and lead-in wires must be 4’ X 4’ 64’ a continuous piece of wire without splices. Only use 4’ X 6’ 80’... -
Page 24: Loop Connections
3. Leaving enough wire for the lead-in, insert the specified number of turns of wire in the cut grooves (see chart). CAUTION: Be careful not to damage the wire insulation during installation. 4. After completing the required number of loop turns, twist the ends together at the rate of 6 turns per foot to form the lead-in. -
Page 25: Safety Device Connections
SHADOW LOOP CONNECTION LD17 OPEN PHOTO LD13 CLOSE PHOTO FORCE ADJUSTMEN T Not Used DRIVEWAY LOOP NOTE: TWIST LEADS APPROX. 6 TURNS PER FOOT SAFETY DEVICE CONNECTIONS INHERENT OBSTRUCTION SENSING DEVICE NOTE: The gate MUST move smoothly WARNING and easily in manual operation before attempting this adjustment. -
Page 26: Clutch Adjustment
CLUTCH ADJUSTMENT NOTE: The clutch comes pre-adjusted from the factory and will function properly for the majority of installations. NEVER INCREASE FORCE SETTING TO MAKE UP FOR A GATE THAT IS NOT MAINTAINED PROPERLY. THIS WILL DESENSITIZE WARNING THE OPERATION OF THE SAFETY SYSTEM. If more sensitivity is desired on a light gate: Turn OFF power on electric plate. -
Page 27: Secondary Obstruction Sensing Devices
CONTACT SENSOR INSTALLATION NOTE: Wireless sensors must be installed so there is no signal interference. NOTE: All hard wiring to safety edges must be installed so there is no threat of mechanical damage to Electric Edge Mounted on wiring between components when Outside Bottom of Gate the gate is moving. -
Page 28: Non-Contact - Photo Eyes
NON-CONTACT SENSOR INSTALLATION 1. Install photoelectric cell as close to FULL OPEN and FULL CLOSED Photo Electric Cell (For open direction) position of gate as possible. 2. Photocells should be installed across the gate opening and behind the gate at least 10 inches above ground (see image). -
Page 29: 2004 Led & Dipswitch Information/Wiring
MAINTENANCE SUGGESTIONS The Reducer is completely sealed and should not require lubrication. Periodically check drive belt and all hardware (nuts, bolts, screws, etc) for tightness. LED AND DIPSWITCH INFORMATION FOR 2004 UMCB-01 CONTROL BOARD To Control Relay Aux. Control Circuit for Gate Lock, Warning Lights, etc. - Page 30 Notes...
-
Page 31: Warranty
A one year warranty applies if product has not been registered. ELECTRICAL PARTS (including boards, switches, relays, etc): PowerMaster warrants electrical parts for a two (2) year period, provided that product has been registered. A one year warranty applies if product has not been registered. - Page 32 Need Technical Support? Visit: www.vepower.net/faqs Call us toll free @ 1-800-243-4476 Email us: PMtech@VEpower.net www.facebook.com/PowerMasterOperators Scan QR Code with your Smart phone to find us on the web! MANUFACTURED BY V.E. POWER DOOR CO,INC. WWW.VEPOWER.NET REV 2017-1031...
