  • Page 1 Owner’s Manual...

  • Page 2: Table Of Contents

    UNITY MOTORHOME TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION Pre-Trip Inspection Owner’s Manual Emergency Equipment Checklist Motorhome Information Kit Final Checks Options and Equipment Maximum Occupancy Vehicle Certification Labels Seat/Shoulder Belts Driver/Passenger Seat Controls Reference Number Codes Traveling Certification Label Samples Unity Floor Plans Driving Characteristics Service Assistance...
  • Page 3 Entertainment System Schematics Extending the Awning Satellite Pre-wire Schematic Beds and Seating Retracting the Awning Auto-Retract Leisure Lounge Plus System (optional) Leisure Lounge Plus Seating APPLIANCE AND EQUIPMENT OPERATION 57 U24CB Seating/Sleeping Dometic IoT System (U24RL Multiplex System) U24TB Sleeping...
  • Page 4 UNITY MOTORHOME TABLE OF CONTENTS Starting the Auxiliary LP Gas Generator Using On-Site Sewer Hook-Ups Water Heater Stopping the Auxiliary LP Gas Generator Auto Gen Start (Available with LP Generator) Water heater operation Auxiliary Diesel Generator (Optional) Truma AquaGo® Water Heater Starting the Auxiliary Diesel Generator Switching ON the Appliance Stopping the Auxiliary Diesel Generator...
  • Page 5 TABLE OF CONTENTS UNITY MOTORHOME Cabinetry, Tables and Countertops Sinks Refrigerator Stove Top - General Stove Top - Burners Microwave/Convection Oven Bathroom - General Toilet Doors and Windows Storage and Winterization Storage Checklist Cold Temperature Storage Spring Startup Cold Temperature Operation Chassis LP Gas Waste System...

  • Page 6: Introduction

    For clarification or further details on any of the enclosed information, please contact: Your motorhome has been designed and manufactured to enhance your travel and camping experience and Your Leisure Travel Vans Dealer or Triple E RV Customer to provide you with safe, efficient and trouble-free Service at: operation.

  • Page 7: Motorhome Information Kit

    OPTIONS AND EQUIPMENT GROSS AXLE WEIGHT RATING (GAWR) Leisure Travel Vans are available in various sizes The value specified as the load carrying capacity of and floor plan configurations and with differing a single axle system, as measured at the tire-ground optional equipment.

  • Page 8: Certification Label Samples

    UNITY MOTORHOME INTRODUCTION COLD TIRE INFLATION PRESSURE Inflation pressures recommended (while cold) for the tires originally installed on your motorhome. These tire pressure levels must be maintained to ensure proper handling, safety and fuel economy. CARGO CARRYING CAPACITY(CCC)(CANADA) LOCATED ON DRIVE-SIDE DOOR FRAME (CANADA MODELS) Equal to GVWR minus each of the following: UVW, full fresh (potable) water weight (including water heater), full LP-Gas weight and SCWR.

  • Page 9: Unity Floor Plans

    INTRODUCTION UNITY MOTORHOME UNITY FLOOR PLANS U24MB PASSENGER SIDE VIEW Light Entrance Step Furnace Exhaust Refrigerator Vents BBQ Hook-Up Generator Compartment External Receptacle Storage Compartment Ladder Awning Inverter and Storage Compartment U24MB DRIVER SIDE VIEW Awning Diesel Fill Shore Power Connection Slide Out Room Storage Compartment Utility Center...
  • Page 10 UNITY MOTORHOME INTRODUCTION U24MB TOP VIEW Solar Panel Air Conditioner Stack Vent Roof Vent WiFi/TV Antenna Sky Light Satellite 1 1 1 U24MB LEISURE LOUNGE FLOOR PLAN...
  • Page 11 INTRODUCTION UNITY MOTORHOME U24MB LEISURE LOUNGE PLUS FLOOR PLAN...
  • Page 12 UNITY MOTORHOME INTRODUCTION U24CB PASSENGER SIDE VIEW Light BBQ Hook-Up Entrance Step Inverter and Storage Compartment Storage Compartment Ladder Option External Receptacle Furnace Exhaust Water Heater Awning U24CB DRIVER SIDE VIEW Slide Out Room Diesel Fill Shore Power Connection Awning Generator Compartment Utility Center Refrigerator Vents...
  • Page 13 INTRODUCTION UNITY MOTORHOME U24CB TOP VIEW Solar Panels Stack Vent TV/WiFi Antenna Roof Vent Satellite Stack Vent Skylight U24CB BOOTH DINETTE FLOOR PLAN...
  • Page 14 UNITY MOTORHOME INTRODUCTION U24CB U-LOUNGE FLOOR PLAN...
  • Page 15 INTRODUCTION UNITY MOTORHOME U24IB PASSENGER SIDE VIEW Light BBQ Hook-Up Awning Inverter and Storage Compartment Storage Compartment Entrance Step External Receptacle Furnace Exhaust Ladder Option Generator Compartment Refrigerator Vents U24IB DRIVER SIDE VIEW Water Heater Storage Compartment Sewer Termination Sewer Hose (Behind Doors) Utility Center Diesel Fill Shore Power Connection...
  • Page 16 UNITY MOTORHOME INTRODUCTION U24IB TOP VIEW Solar Panels Stack Vent TV/WiFi Antenna Roof Vent Satellite Skylight U24IB FLOOR PLAN...
  • Page 17 INTRODUCTION UNITY MOTORHOME U24TB PASSENGER SIDE VIEW Light BBQ Hook-Up Awning Inverter and Storage Compartment Storage Compartment Entrance Step External Receptacle Furnace Exhaust Ladder Option Generator Compartment Refrigerator Vents U24TB DRIVER SIDE VIEW Water Heater Storage Compartment Sewer Termination Sewer Hose (Behind Doors) Utility Center Diesel Fill Shore Power Connection...
  • Page 18 UNITY MOTORHOME INTRODUCTION U24TB TOP VIEW Solar Panels Stack Vent TV/WiFi Antenna Roof Vent Satellite Skylight U24TB FLOOR PLAN...
  • Page 19 INTRODUCTION UNITY MOTORHOME U24 FX PASSENGER SIDE VIEW Light Generator Compartment Furnace Exhaust Inverter and Storage Compartment BBQ Hook-Up Water Heater External Receptacle Storage Compartment Ladder Option Awning Entrance Step U24FX DRIVER SIDE VIEW Refrigerator Vents Storage Compartment Utility Center Awning Sewer Hose (Behind Doors) Slide Out Room...
  • Page 20 UNITY MOTORHOME INTRODUCTION U24FX TOP VIEW Solar Panels Stack Vent TV/WiFi Antenna Roof Vent Satellite Skylight U24FX FLOOR PLAN...
  • Page 21 INTRODUCTION UNITY MOTORHOME U24RL PASSENGER SIDE VIEW Light Awning Entrance Step Inverter and Storage Compartment Storage Compartment Fridge Vents External Receptacle BBQ Hook-Up Ladder Option U24RL DRIVER SIDE VIEW Diesel Fill Utility Center Water Heater Generator Compartment Shore Power Connection Sewer Termination Storage Compartment Furnace Vent...
  • Page 22 UNITY MOTORHOME INTRODUCTION U24RL TOP VIEW Solar Panels Stack Vent TV/WiFi Antenna Roof Vent Satellite Skylight U24RL FLOOR PLAN...

  • Page 23: Service Assistance

    INTRODUCTION UNITY MOTORHOME SERVICE ASSISTANCE REPORTING SAFETY DEFECTS Your dealer will assist you with any additional information If you suspect your motorhome has a safety defect that you need and will answer any questions you have could cause injury or death, immediately contact Triple about the operation of your motorhome.

  • Page 24: Coach Specifications

    UNITY MOTORHOME INTRODUCTION COACH SPECIFICATIONS Chassis 3500 Sprinter Engine - 3.0L V6 Blue TEC Diesel 188hp / 325 lb-ft Torque Transmission - 5 Speed Automatic U24MB U24CB U24IB U24TB U24FX U24RL Turning Circle - 54.6' Axel Ratio - 3.92:1 Tires - LT215/85R16 GVWR - lbs (kg) 11,030 (5003) 11,030 (5003)
  • Page 25 INTRODUCTION UNITY MOTORHOME...

  • Page 26: Safety

    UNITY MOTORHOME SAFETY SAFETY or sub-assemblies must be familiar with this manual and the manuals in the Motorhome Information Kit. Every Safety, comfort and ease of operation are key operator and occupant is responsible for following all considerations during the design and manufacture of safety items covered in this and other manuals.

  • Page 27: Alarms

    SAFETY UNITY MOTORHOME 4. Test the CO/LP gas alarm before each trip by ALARMS depressing the test button . Test the CO/LP alarm All models are equipped with a combination LP gas, after removing the motorhome from storage, before carbon monoxide, and smoke alarm as standard safety each trip and weekly thereafter.

  • Page 28: Fuel And Propane Safety

    UNITY MOTORHOME SAFETY   ᘐ WARNING after the RV is properly ventilated. PROPANE GAS ALARM Test this alarms operation after each storage The Red Gas LED will Flash and the alarm will sound period, before each trip and at least once per week during use.

  • Page 29: Smoke Alarm

    SAFETY UNITY MOTORHOME   ᘐ NOTICE SMOKE ALARM Smoke alarms are not perfect and do not respond The smoke alarm sounds whenever there is an unsafe amount of smoke in the motorhome. Always open the in all situations. The best safeguard is fire prevention.

  • Page 30: Emergency Escape - Egress Window

    UNITY MOTORHOME SAFETY   ᘐ WARNING EMERGENCY ESCAPE - EGRESS WINDOW Stay a safe distance from the fire and near an exit. Use the side entry doors or rear emergency egress Stay close to the floor to avoid heat and fumes. The chemical from the fire extinguisher will shoot window exit (if equipped) as emergency escape routes.
  • Page 31 SAFETY UNITY MOTORHOME FUNCTION Fire extinguishers are designed to put out a fire in its initial stages. Once you cannot get within 10 feet (3 m) of the fire, it is out of control and too big to fight with your extinguisher.

  • Page 32: Motorhome Operation

    UNITY MOTORHOME MOTORHOME OPERATION MOTORHOME OPERATION that can be added to the motorhome without exceeding the GVWR. Refer to the Certification Labels Samples section on page 7 for visual appearance and relevant locations in the motorhome MOTORHOME PREPARATION Before beginning an extended trip, ensure you are The Gross Combination Weight Rating (GCWR) is the thoroughly familiar with your motorhome’s condition, maximum allowable loaded weight of the motorhome...

  • Page 33: Towing

    MOTORHOME OPERATION UNITY MOTORHOME TOWING AUXILIARY VEHICLE TOWING Towing a trailer can affect the handling, durability, If you are planning to tow another vehicle or a trailer performance and fuel economy of your motorhome. The with your motorhome, contact your local department factory-installed class III towing hitch is rated as follows: of transportation for towing information.

  • Page 34: Pre-Trip Inspection

    UNITY MOTORHOME MOTORHOME OPERATION   ᘐ DANGER PRE-TRIP INSPECTION Turn off all appliances while refueling any 1. Ensure the motorhome and all of its components, devices, systems and subsystems are serviced and motorhome or LP gas tanks. Do NOT smoke while refueling.

  • Page 35: Final Checks

    MOTORHOME OPERATION UNITY MOTORHOME   ᘐ WARNING FINAL CHECKS All occupants must be in seats equipped with lap 1. Secure all objects in the motorhome. Tie, latch or lock all loose objects as appropriate. or shoulder harness seatbelts with the seatbelt fastened when the motorhome is in motion.
  • Page 36 UNITY MOTORHOME MOTORHOME OPERATION   ᘐ CAUTION LAP BELTS The dinette is equipped with lap belts (not available Placing a child or child restraint system in a on all models). Never allow occupants to travel in a seat that is not equipped with a lap or shoulder belt. rear-facing or side-facing seat is not safe under any circumstances.

  • Page 37: Driver/Passenger Seat Controls

    MOTORHOME OPERATION UNITY MOTORHOME 3. Pull the swivel lock lever (located near the base DRIVER/PASSENGER SEAT of the seat) to the left, and swivel the seat slowly toward the center line of the motorhome to prevent CONTROLS damage to the seat, door panel and post. SWIVEL FUNCTION 1.

  • Page 38: Traveling

    UNITY MOTORHOME MOTORHOME OPERATION BACK REST ADJUSTMENT GENERAL HANDLING Slide the back rest adjustment button forward or backward to adjust the angle of the seat back. The motorhome power-to-weight ratio is lower than that of the average automobile. It is essential to compensate for slower acceleration when moving into traffic or when passing another vehicle.

  • Page 39: Driving Safety Tips

    MOTORHOME OPERATION UNITY MOTORHOME   ᘐ CAUTION DRIVING SAFETY TIPS Extended brake applications can cause excessive 1. When backing the motorhome, have a person stand wear, overheating and under extreme conditions, to the rear on the driver’s side to guide you. brake failure that could cause you to lose control 2.

  • Page 40: Severe Weather Information

    UNITY MOTORHOME MOTORHOME OPERATION requires a much different driving style than your SEVERE WEATHER family car. 4. When towing a vehicle, make sure the combined INFORMATION weight of the towed vehicle does not exceed the GCWR as stated on the vehicle certification label located on the passenger door frame (US models As a motorhome traveler, you may want to explore new only).

  • Page 41: Emergencies While Driving

    MOTORHOME OPERATION UNITY MOTORHOME 8. Use a jacking board for stability on loose or soft EMERGENCIES WHILE DRIVING ground. Your motorhome is designed with features that allow the 9. Raise the motorhome with the jack according to driver and occupants to resolve some emergencies or the instructions in the chassis manual.

  • Page 42: Parking

    UNITY MOTORHOME MOTORHOME OPERATION   ᘐ WARNING PARKING BATTERY BOOST WARNING: Consult the chassis PARKING manual in the Motorhome Information Kit for proper jump starting/boosting procedures. You can stop and park your motorhome much like an automobile; however, always remember that the unit is longer, wider and higher than a typical automobile and OVERHEATING requires more room and clearance.

  • Page 43: Extended Occupancy

    MOTORHOME OPERATION UNITY MOTORHOME BACK-UP MONITORING SYSTEM EXTENDED OCCUPANCY Your motorhome is equipped with a rear camera monitoring system. The rear camera view will Your motorhome is designed for recreational and automatically display on the in-dash entertainment short-term occupancy. In case of extended occupancy, system display when you shift the vehicle into reverse.

  • Page 44: Stabilizers

    UNITY MOTORHOME MOTORHOME OPERATION   ᘐ CAUTION LEVELING JACKS Exercise care and caution when parking and Your motorhome may be equipped with automatic leveling your motorhome. Make sure all pets leveling jacks. The leveling jack control panel and people, especially children, are clear of the located in the cabinet above the coach entrance motorhome until leveling is complete and the doorway.

  • Page 45: Manual Operation

    MOTORHOME OPERATION UNITY MOTORHOME NOTE: The jacks down LED lights must be off for Auto- MANUAL OPERATION Level to function. If needed, press the ALL RETRACT button to clear and then Auto-Level should function. 1. Power On: Make sure your parking brake is engaged and the ignition key is in the OFF position.

  • Page 46: Refueling The Vehicle Chassis

    UNITY MOTORHOME MOTORHOME OPERATION 4. Retracting the Jacks: To retract all jacks REFUELING THE VEHICLE simultaneously, press and release the ALL RETRACT button . All jacks will automatically retract and CHASSIS return to stowed position. The pump will run in  ...

  • Page 47: Removing The Fuel Cap

    MOTORHOME OPERATION UNITY MOTORHOME DOOR LOCKS REMOVING THE FUEL CAP Separate keys are required for the ignition switch The fuel tank filler cap is located behind a flap installed in the chassis and motorhome door locks. adjacent to the driver’s door. Slowly remove the fuel cap to release any built up pressure.

  • Page 48: Entry Door Step

    UNITY MOTORHOME MOTORHOME OPERATION INSIDE THE MOTORHOME ENTRY DOOR STEP Your motorhome can be locked/unlocked from the inside using the buttons located on the driver and The entry system is equipped with a magnetic interlock passenger side doors. Press the button to unlock all system that activates the lowering and raising of the entrance doors;...

  • Page 49: Step Override Switch

    MOTORHOME OPERATION UNITY MOTORHOME STEP OVERRIDE SWITCH Depress the top of the step override switch , located inside the coach entrance in the Unity MB, CB, FX, TB and IB, or in the overhead console in the RL, to prevent the steps from retracting when the coach door is closed.

  • Page 50: Entry Step Electrical Diagram

    UNITY MOTORHOME MOTORHOME OPERATION ENTRY STEP ELECTRICAL DIAGRAM...

  • Page 51: Lighting

    MOTORHOME OPERATION UNITY MOTORHOME   ᘐ NOTICE LIGHTING Turn the battery disconnect switch to internal A light is located above each cab door and comes on when the door is opened. It lights up the seat and cab 12 volt DC power to operate the interior roof lights.

  • Page 52: Slide Out Room

    UNITY MOTORHOME MOTORHOME OPERATION   ᘐ DANGER SLIDE OUT ROOM Do NOT drive your motorhome with the slide out Your motorhome may be equipped with an expandable slide out room , which provides extra living area for room extended. This is dangerous and violates all North American traffic laws.

  • Page 53: Extending The Slide Out Room

    MOTORHOME OPERATION UNITY MOTORHOME EXTENDING THE SLIDE OUT ROOM SLIDE OUT ROOM EMERGENCY OPERATION The slide out control switch  is located in the cabinet above the coach entrance doorway. If the slide out room fails to extend or retract electrically, you can manually operate the slide out mechanism.
  • Page 54 UNITY MOTORHOME MOTORHOME OPERATION   ᘐ CAUTION 7. Remove foil covering the access panel on the right side. If you have unplugged the motor electrical connectors ( & ) from the control module , do NOT move the motorhome unless the slide out room and the slide out room motors electrical connectors ( &...
  • Page 55 MOTORHOME OPERATION UNITY MOTORHOME ACCESSING THE MOTOR WHEN SLIDE OUT IS 11. Peel back the exterior sweep gasket from the top corners of the slide out, and lift the slide out motor approximately ½” to release. 1. Turn the battery disconnect switch to the “OFF” position, and disconnect the shore power.

  • Page 56: Awning

    UNITY MOTORHOME MOTORHOME OPERATION 4. Remove the slide out snap-on trim boards AWNING both sides. 5. Remove the mounting screws on either side EXTENDING THE AWNING 1. Turn the main awning power switch located on the passenger side seat base to the “ON” position. 2.

  • Page 57: Retracting The Awning

    MOTORHOME OPERATION UNITY MOTORHOME   ᘐ CAUTION RETRACTING THE AWNING Always place the main awning power switch 1. Ensure the main awning power switch located on the passenger side seat base is set to the “ON” the “OFF” position when the awning is not used and during transit.

  • Page 58: Appliance And Equipment Operation

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION APPLIANCE AND OPERATING THE REFRIGERATOR EQUIPMENT OPERATION DOMETIC 3-WAY REFRIGERATOR The dometic 3-way refrigerator in your motorhome Appliances and equipment may vary according to your operates in any one of the following modes: motorhome model, specifications and floor plan. Refer to the Motorhome Information Kit for operation and • 120 volt AC electric maintenance details relating to the specific appliances...

  • Page 59: Refrigerator Operating Tips

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME STOVE TOP REFRIGERATOR OPERATING TIPS 1. Ensure the refrigerator is cold before placing items The stove top operates on LP Gas. It must be lit manually in it. using the integrated igniter. Ensure the LP gas valve 2.

  • Page 60: Microwave/Convection Oven

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION 6. Do not remove the warning label on the stove top lid. MICROWAVE/CONVECTION 7. Do not operate burners with glass stove top lid closed. OVEN   ᘐ WARNING OPERATING THE MICROWAVE/ CONVECTION OVEN Never use the stove top burners to heat the interior of your motorhome.

  • Page 61: Exterior Bbq Connection

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME EXTERIOR BBQ CONNECTION LP GAS FURNACE Your motorhome is equipped with an exterior supply OPERATING THE LP GAS FURNACE source to furnish LP Gas to your own barbeque (BBQ). The connection point is located at the rear on the The LP Gas furnace is controlled by the single-zone passenger side.

  • Page 62: Dometic Comfort Control Center

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION 2. Do not attempt to manually light the furnace. The ROOF AIR CONDITIONER WITH furnace does not have a pilot light. It is ignited by a direct spark ignition system. HEAT PUMP NOTE: Press the °F/°C button to switch between °F and °C.

  • Page 63: Maintaining The Roof Air Conditioner/Heat Pump

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME COACH POWER ROOF VENT MAINTAINING THE ROOF AIR CONDITIONER/HEAT PUMP The coach power roof vent is used to provide controlled Clean or change the air conditioner filter at least every air flow throughout the coach cabin. Use the vent fan two weeks when the air conditioner is in operation.

  • Page 64: Bathroom Roof Vent

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION VENT HOOD HEIGHT CONTROL BATHROOM ROOF VENT The rotary knob controls the height position of the vent hood. Turn the knob clockwise to pull the hood The bathroom roof vent provides air flow and venting down and close it.

  • Page 65: Side Window Vents

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME SIDE WINDOW VENTS MANUAL ROOF VENT Turn the knob counterclockwise to open the window Use the manually operated roof vent in conjunction vent and clockwise to close the window vent. with the power roof vent to provide adequate air flow throughout the motorhome.

  • Page 66: Closing The Roof Vent

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION CLOSING THE ROOF VENT ADJUSTING THE TENSION INCREASING TENSION 1. Lift the handle to release it from the seat 2. Pull down the roof vent using the handle To increase the spring tension remove the end cap, 3.

  • Page 67: Entertainment Systems

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME ENTERTAINMENT SYSTEMS U24CB, U24FX AND U24RL FLOOR PLANS The TV is stowed in the following locations: In these floor plans, TVs are located in the bedroom U24IB AND U24TB FLOOR PLANS area & , and in the front of the couch beside the These floor plans are equipped with 2 TVs.

  • Page 68: U24Mb Floor Plan

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24MB FLOOR PLAN TV OPERATION The TV is stowed in the coach passenger side countertop Refer to the TV manual in the Motorhome Information and is accessed by pulling the release lever located Kit for detailed operating instructions. at the coach entrance.

  • Page 69: Tv Utility Panel

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME TV UTILITY PANEL EXTERNAL CABLE TV CONNECTION The TV utility panel (location varies depending on floor plan) is equipped with a TV antenna booster /WiFi Your motorhome is equipped with an external cable TV power switch .

  • Page 70: Hdmi Switch Box

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION HDMI SWITCH BOX Your motorhome may be equipped with an HDMI audio/ video switch box . This enables HD quality viewing for your DVD player or satellite receiver (not supplied). Refer to the “Entertainment System Schematics” section in this manual and the HDMI switch box manual in the Motorhome Information Kit for further details.

  • Page 71: Entertainment System Schematics

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME ENTERTAINMENT SYSTEM SCHEMATICS U24IB/TB ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 72 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24CB/FX ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 73 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME U24MB ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 74 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION U24RL ENTERTAINMENT SYSTEM SCHEMATIC...
  • Page 75 APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME HDMI MATRIX SWITCH SCHEMATIC...

  • Page 76: Satellite Pre-Wire Schematic

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION SATELLITE PRE-WIRE SCHEMATIC Your motorhome is pre-wired for satellite dish installation (location varies according to floor plan).

  • Page 77: Beds And Seating

    BEDS AND SEATING when the chair is slightly rotated to ensure the seat locks into the next position. LEISURE LOUNGE PLUS SYSTEM 5. Remove the lounge chair seat back cushions and (OPTIONAL) headrests and fold the seat backs forward until...
  • Page 78 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION   ᘐ CAUTION RAISING THE MURPHY BED 1. Pull the adjustable headboard/backrest toward you for desired comfort. To collapse headboard/ Failure to pull the release strap will cause damage backrest, pull it out all the way and it will release. to the Murphy Bed Push it back toward the wall.

  • Page 79: Leisure Lounge Plus Seating

    : You can rotate the chairs by LEISURE LOUNGE PLUS SEATING lifting and holding the lock button on the side of Leisure lounge recliners can be configured as follows: the chair and releasing the lock when the chair is at the desired angle. • Coffee Table : Use the small flip-up coffee table/ support for a dinette table or to support large table.

  • Page 80: U24Cb Seating/Sleeping

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION BOOTH DINETTE BED U LOUNGE U24CB SEATING/SLEEPING CONVERSION (Varies According to Floor Plan) BOOTH DINETTE BED CONVERSION 1. Pull the table release handles and lower the table until it is level with the seating base. 1.

  • Page 81: U24Tb Sleeping

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME U24TB SLEEPING U24IB/TB SEATING TWIN BED CONVERSION INSTALLING THE REMOVABLE TABLE 1. Fold out the cushion support ASSEMBLY 1. Locate the table leg and table top stored in the bedroom cabinet/bed base. 2. Engage the table leg into the floor plate install the table top onto the leg.

  • Page 82: Leisure Lounge Seating

    UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION 4. Bed down with the headboard tilted out as backrest LEISURE LOUNGE SEATING (Available in U24MB and U24FX) 1. Bench configuration 5. Rear seating (lock ottoman to prevent movement while the vehicle is in motion) 2.

  • Page 83: U24Rl Rear Lounge

    APPLIANCE AND EQUIPMENT OPERATION UNITY MOTORHOME RAISING THE MURPHY BED U24RL REAR LOUNGE 1. Before raising the Murphy bed, be sure to unplug LOWERING THE MURPHY BED and remove any devices that may be in the rear 1. Remove the back rest cushions from the Rear cubby.
  • Page 84 UNITY MOTORHOME APPLIANCE AND EQUIPMENT OPERATION 5. Replace the cushions on the rear lounge. REAR LOUNGE FOOT RESTS To raise or lower the foot rests on the Rear Lounge, you must either be connected to shore power, or have the inverter running.
  • Page 85 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME...

  • Page 86: Electrical System Operation

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION ELECTRICAL SYSTEM SHORE POWER OPERATION To operate using shore power, connect the 120 volt AC power supply cable (stored in the driver’s side rear exterior storage compartment) to the external receptacle located on the driver’s side of the motorhome. ELECTRICAL SUPPLY Your motorhome is equipped with two electrical systems To connect the 30 amp power supply cable, rotate the...

  • Page 87: Wiring Schematic

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME WIRING SCHEMATIC U24MB 30 AMP 120V WIRING SCHEMATIC U24CB 30 AMP 120V WIRING SCHEMATIC...
  • Page 88 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION U24IB 30 AMP 120V WIRING SCHEMATIC U24TB 30 AMP 120V WIRING SCHEMATIC...
  • Page 89 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME U24FX 30 AMP 120V WIRING SCHEMATIC U24RL 30 AMP 120V WIRING SCHEMATIC...
  • Page 90 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION U24MB 12V WIRING SCHEMATIC U24CB 12V WIRING SCHEMATIC...
  • Page 91 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME U24IB 12V WIRING SCHEMATIC U24TB 12V WIRING SCHEMATIC...
  • Page 92 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION U24FX 12V WIRING SCHEMATIC U24RL 12V WIRING SCHEMATIC...

  • Page 93: System Monitor

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME WATER HEATER SWITCH SYSTEM MONITOR This switch controls the power to the water heater. Turn The system monitor panel, located in the cabinet above the switch counterclockwise from the “OFF” position the coach entrance doorway, monitors the following for water heater function or clockwise from the “OFF”...

  • Page 94: Power Distribution Panels

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION If a circuit breaker “trips,” allow a brief cool down period POWER DISTRIBUTION PANELS of 30–90 seconds, then reset the breaker by turning The power distribution panels , located in a lower it “OFF” and then “ON.” If a circuit breaker “trips” cabinet fascia, contain the 120 volt breakers for the 120 repeatedly, the circuit is overloaded or there may be a volt AC system and 12 volt fuses for the 12V DC system.

  • Page 95: 12 Volt Dc Chassis Fuses

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME 12 VOLT DC CHASSIS FUSES Refer to the chassis operator’s manual for chassis fuse functions. DRIVER SEAT PEDESTAL FUSES Fuse #24: 5 amp fuse powers the following components: • Electric step safety retract • Stabilizer jack safety retract • Refrigerator (when on AUTO select 12 V power source NOTE: GFCI receptacles may not appear as shown in...

  • Page 96: Operating The Auxiliary Lp Gas Generator

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION OPERATING THE AUXILIARY LP GAS STARTING THE AUXILIARY LP GAS GENERATOR GENERATOR Turn on the LP Gas valve by depressing the top of the 1. Depress and hold the STOP/PRIME of either of LP Gas shut off switch located in the utility center the two generator start buttons for about 5 seconds in the driver’s side exterior compartment.

  • Page 97: Auto Gen Start (Available With Lp Generator)

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME AUXILIARY DIESEL GENERATOR (OPTIONAL) The auxiliary diesel generator is located below the coach floor in a location which varies depending on the floor plan.   ᘐ NOTICE There is a breaker on the side of the unit. If the power plant is running and there is no power, check this breaker.

  • Page 98: Stopping The Auxiliary Diesel Generator

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION   ᘐ WARNING 2. Depress the start button until the diesel generator Press the stop switch to stop the generator set engine starts running then release the button. The display screen will show “GEN OFF” until the engine or to prevent it from starting while performing maintenance and/or service.

  • Page 99: Generator Safety

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME GENERATOR SAFETY AUTOMATIC POWER TRANSFER SWITCH ELECTRICAL AUTOMATIC SWITCH OVER   ᘐ WARNING Starting the generator will automatically switch power from 120 volt AC shore power to generator power. Exercise extreme care and caution when handling the generator and its components.

  • Page 100: 12 Volt Dc System

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION 12 VOLT DC SYSTEM The 12 volt DC power system in your motorhome consists of the following two distinct, but interconnected, battery systems CHASSIS BATTERY The chassis battery operates the vehicle starter, vehicle accessories and all vehicle controls on the instrument console, such as the heater fans, exterior COACH BATTERIES (12 VOLT DC lights, horn, speed control, windshield wipers, etc.

  • Page 101: Coach Battery Condition Meter

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME   ᘐ NOTICE COACH BATTERY CONDITION METER A surge protection fuse is installed inside the coach battery storage compartment . If the For voltage readings, refer to Xantrex Inverter Remote coach batteries fail to operate, inspect this fuse Control Status display and press OK and replace if necessary.

  • Page 102: Long-Term Storage

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION NOTE: When removing, replacing, boosting or charging LONG-TERM STORAGE the batteries, ensure the red positive (+) cable terminals Turn off the coach battery disconnect during extended are connected to the positive (+) posts and the black periods of storage.

  • Page 103: Inverter

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME   ᘐ CAUTION   ᘐ NOTICE Remove rings, metal watchbands and other The invert feature needs to be manually switched metal jewelry before working around a battery. ON and OFF. However if the inverter feature is Use caution when using metal tools.

  • Page 104: Inverter Remote Control Panel

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION SURGE GUARD (OPTIONAL) INVERTER REMOTE CONTROL PANEL The Inverter Remote Control Panel is located in the cabinet above the coach entrance doorway. The Inverter Remote Control Panel is equipped with an Inverter Function - ON/OFF switch .

  • Page 105: Accidental 240 Volt Protection

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME TROUBLESHOOTING GUIDE Error Code Chart In order to help troubleshoot the problem(s) you are experiencing and render the best possible solution, Normal Operating Condition. it is necessary you be at your motorhome when you Reverse Polarity (hot and neutral wires reversed). place your call.

  • Page 106: Lighting Maintenance

    UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION   ᘐ NOTICE SIDE MARKER LIGHTS The solar power unit is intended to charge the coach batteries only. It does not generate enough power to run the motorhome’s electrical system. LIGHTING MAINTENANCE The following procedures detail replacement of the coach interior and exterior lights.

  • Page 107: Interior Lighting

    ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME 3. Unclip the electrical connector from the light INTERIOR LIGHTING you are replacing. CEILING AND OVERHEAD CABINET LIGHTS 4. Remove the two nuts securing the support bracket to the light assembly and remove the support bracket. 5.
  • Page 108 UNITY MOTORHOME ELECTRICAL SYSTEM OPERATION READING LIGHTS EXTERIOR UTILITY CENTER LIGHT The coach reading lights are not serviceable. If the The exterior utility center light is controlled by the reading light stops working, have the entire unit replaced exterior storage and utility center light switch inside the by a qualified service technician.
  • Page 109 ELECTRICAL SYSTEM OPERATION UNITY MOTORHOME BAGGAGE COMPARTMENT LIGHT The baggage compartment light is controlled by the exterior storage and utility center light switch inside the coach. Refer to the “Exterior/Interior Light Switches” section in the “Motorhome Operation” section for instructions. NOTE: This is a sealed LED unit and must be replaced as complete unit.

  • Page 110: Water And Plumbing System

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM WATER AND PLUMBING CITY WATER SUPPLY SYSTEM The city water source supplies your motorhome’s water system with water at pressure of the external source when the water pump is switched off. WATER SUPPLY CONNECTING THE EXTERNAL WATER SUPPLY Your motorhome is designed with fresh water, grey water Press any water pump switch to turn off the water pump.

  • Page 111: Filling The Fresh Water Tank

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME   ᘐ NOTICE DISCONNECTING THE CITY WATER SUPPLY 1. Turn off the city water supply. Always turn off the water pump switch 2. Relieve the water pressure in the line by opening a faucet in the motorhome. leaving the motorhome unattended for an extended period of time and when driving to 3.

  • Page 112: Water Pump Switch

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM DISINFECTING THE WATER WATER PUMP SWITCH To power the water pump one of the three switches TANK needs to be turned on. The light above the water pump switch will light up. To shut down depress any switch, and the light above water pump switch Periodically disinfect the fresh water system.

  • Page 113: Water Pump

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME WATER PUMP WATER PUMP INITIAL STARTUP The water pump is designed to supply on-demand 1. Make sure all drain valves are closed. water from the fresh water tank to the various water 2. Turn off the water pump switch and plumbing systems in your motorhome.

  • Page 114: Water Pump Electrical Diagram

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM IF WATER PRESSURE DROPS 1. Check faucets and connections for leaks. 2. Make sure faucet aerators and filters are clean. 3. Make sure there is water in the tank. 4. Make sure the chassis battery is not discharged. 5.

  • Page 115: Draining The Fresh Water System

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME DRAINING THE FRESH WATER DRAINING THE HOT AND COLD WATER SYSTEMS SYSTEM 1. Disconnect the city water supply if connected To drain the fresh water tank , open the fresh water 2. Turn off the water pump at any water pump switch. tank drain valve located either under the bed or on...

  • Page 116: Water Filter

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM WATER FILTER WASTE SYSTEMS The water filter is located below the kitchen or GREY WATER WASTE HOLDING TANK bathroom sink (location varies depending on floor plan). Replace the water filter at least annually to ensure water The drainage from the kitchen sink and shower pan is quality.

  • Page 117: Dumping Holding Tanks

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME DUMPING HOLDING TANKS BLACK WATER WASTE TANK RINSE 1. Connect the sewer hose to the tank outlet The motorhome is equipped with a black water waste located on the rear driver’s side underbody. The tank flushing system to improve draining and to reduce sewer hose is stored on the driver’s side under odor.

  • Page 118: Macerator

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM Refer to the macerator manual located in the Motorhome MACERATOR Information Kit for further information. Your motorhome may be equipped with a macerator . The macerator breaks down the solid matter in the WASTE WATER HOLDING TANK - black water holding tank.

  • Page 119: Using On-Site Sewer Hook-Ups

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME WATER HEATER USING ON-SITE SEWER HOOK-UPS When staying at a campsite where sewer hook-up is WATER HEATER OPERATION available, the sewer hose may be attached and left in place for the duration of the stay. The water heater is accessible from outside the coach.

  • Page 120: Truma Aquago® Water Heater

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM TRUMA AQUAGO® WATER HEATER SWITCHING ON THE APPLIANCE 1. Open the access door. 2. To switch on the appliance, switch the POWER switch to one of the two “ON” positions. Both ON positions on the POWER switch have the same function.

  • Page 121: Operating Mode / Description

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME   ᘐ NOTICE LED ROTARY SWITCH ECOCLEAN For safety reasons, after 30 seconds the With the rotary switch you can choose between the following operating modes: decalcification process cannot be stopped until the system has been rinsed in accordance with the instructions.

  • Page 122: Macerator Toilet

    UNITY MOTORHOME WATER AND PLUMBING SYSTEM SPRAY NOZZLE WATER FILL The manual flush toilet is equipped with a hand held Press and release button to raise the water in the spray nozzle toilet. NORMAL FLUSH Press and release button to flush. NOTE: To adjust the flush settings from “Normal”...

  • Page 123: Showers

    WATER AND PLUMBING SYSTEM UNITY MOTORHOME 5. If the operation of the manual flush valve is EXTERIOR SHOWER diminished or becomes stiff, lubricate the toilet plunger. Keep the toilet plunger lubricated by leaving Your motorhome is equipped with an exterior shower a small amount of water in the toilet or turning off unit located in the exterior utility center.

  • Page 124: Liquid Propane Gas System

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM LIQUID PROPANE GAS SAFE USE OF LP GAS SYSTEM The LP Gas system is designed and built to adhere to federal government and industry regulatory LP (Liquid Petroleum) Gas is a colorless gas compressed requirements.

  • Page 125: How Lp Gas Works

    LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME HOW LP GAS WORKS There are two types of LP (liquid petroleum) Gas: propane and butane. Both are compressed into a liquid state for easier transportation and storage. Common names used for LP Gas are tank gas, bottle gas, or simply LP.

  • Page 126: After Refilling The Lp Gas Tank

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM LP Gas stations are found in all parts of the country. AFTER REFILLING THE LP GAS TANK Check the yellow pages in your telephone book or on-line if you have trouble finding a station. Look under “Gas - Liquid Petroleum - Bottled and Bulk”...

  • Page 127: Lp Gas Tank Regulator

    LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME   ᘐ CAUTION LP GAS TANK REGULATOR Do not use an open flame or a heat lamp to thaw The LP Gas tank regulator has a plastic cover to protect it from the weather. Only qualified service personnel are the regulator.

  • Page 128: Avoiding Asphyxiation

    UNITY MOTORHOME LIQUID PROPANE GAS SYSTEM 7. Close rear windows when driving to prevent drawing AVOIDING ASPHYXIATION exhaust fumes into the motorhome. 1. Do not use portable fuel-burning equipment such as wood or charcoal grills, heaters or stoves inside the NOTE: When the motorhome is new, some of the motorhome.
  • Page 129 LIQUID PROPANE GAS SYSTEM UNITY MOTORHOME...

  • Page 130: Motorhome Maintenance

    UNITY MOTORHOME MOTORHOME MAINTENANCE MOTORHOME MAINTENANCE the motorhome, it is time to polish and wax it. This will not only improve the appearance of your motorhome, but will also protect the painted surfaces EXTERIOR CARE AND from oxidation and corrosion making it easier to wash. MAINTENANCE  ...

  • Page 131: Solar Panels

    MOTORHOME MAINTENANCE UNITY MOTORHOME INTERIOR CARE SOLAR PANELS Solar panels should be cleaned monthly using water and Dirt and dust accumulation can not only detract from a soft sponge or cloth. If required, a mild non-abrasive the motorhome’s appearance, but can also shorten the cleanser can be used for more stubborn residue.

  • Page 132: Draperies, Curtains And Bedspreads

    UNITY MOTORHOME MOTORHOME MAINTENANCE DRAPERIES, CURTAINS AND SINKS BEDSPREADS The sinks can be cleaned with warm water and soap. Draperies, curtains and bedspreads are made from a Wipe dry to avoid streaks. For stubborn stains, a mild variety of fabrics and materials. Many of these materials abrasive may be necessary.

  • Page 133: Microwave/Convection Oven

    MOTORHOME MAINTENANCE UNITY MOTORHOME STORAGE AND WINTERIZATION MICROWAVE/CONVECTION OVEN Keep the door and inside of your microwave/convection Inspect all systems, components and appliances prior oven clean. Do not allow grease, spatter or solid matter to storing your motorhome. to build up. An accumulation of solid matter can absorb microwave energy and increase cooking time.

  • Page 134: Cold Temperature Storage

    UNITY MOTORHOME MOTORHOME MAINTENANCE   ᘐ WARNING COLD TEMPERATURE STORAGE Do NOT use alcohol-based antifreeze or other SPRING STARTUP petroleum products. After storing the motorhome for an extended period of time, run the water pump to pressurize the water system and check for leaks.

  • Page 135: Water System Winterization

    MOTORHOME MAINTENANCE UNITY MOTORHOME WATER SYSTEM WINTERIZATION DRAINING THE WATER SYSTEM NOTE: Remove the water filter from the cannister before this procedure is performed. 1. Switch off the water pump and disconnect the water hose at city water outside. 2. Switch off the water heater inside the motorhome 8.

  • Page 136: Blowing Out The Air Lines

    UNITY MOTORHOME MOTORHOME MAINTENANCE   ᘐ NOTICE fresh water before reinstalling both components on the water pump. Do NOT depress the toilet flush pedal if there is 4. Go outside and remove the screen from the city water fill connection, depress the center stem air pressure in the system or damage to the toilet flush valve could result.

  • Page 137: Maintenance And Servicing

    MOTORHOME MAINTENANCE UNITY MOTORHOME   ᘐ NOTICE MAINTENANCE AND SERVICING Refer to the detailed operating and safety LP GAS TANK VALVE instructions in the Motorhome Information Kit before performing the stabilizer override If the electrically operated LP Gas valve (located underneath the motorhome) fails to operate the LP procedure.

  • Page 138: Entry Door Step

    UNITY MOTORHOME MOTORHOME MAINTENANCE ENTRY DOOR STEP Periodically lubricate the electric entry door step mechanism . Refer to the electric step manual in the Motorhome Information Kit for details. 4 POINT LEVELING SYSTEM Periodically check the transmission fluid in the pump reservoir and refill as necessary.
  • Page 139 MOTORHOME MAINTENANCE UNITY MOTORHOME   ᘐ CAUTION Following manual override operation, return all valves to normal operational position. Failure to do so may result in drifting from the retracted (stowed) position of leveling jacks. Cartridge valves: Rotate the center screw fully counter-clockwise until lightly seated.

  • Page 140: New Vehicle Limited Warranty

    UNITY MOTORHOME NEW VEHICLE LIMITED WARRANTY NEW VEHICLE LIMITED parts shall include only the metal structure of the coach and all metal members welded to it, studs WARRANTY and framing in the walls of the coach, roof rafters and delamination of the fiberglass body parts of the TRIPLE E CANADA LTD.
  • Page 141 NEW VEHICLE LIMITED WARRANTY UNITY MOTORHOME every such separate warranty with respect to a failure of hoses, fittings, connections or lines and Component as the sole, exclusive and only warranty failure to operate and maintain the Motorhome as in respect of such Component. Triple E RV provides recommended or required in the Owner’s Manual.
  • Page 142 UNITY MOTORHOME NEW VEHICLE LIMITED WARRANTY beyond those expressed herein. Your warranty 9. Time Limitation for Initiating Claims expressly excludes liability for incidental or Any claim for breach of this Warranty or any consequential damages. applicable implied or statutory warranty must be initiated within one year after the date on which the 7.
  • Page 143 NOTES UNITY MOTORHOME NOTES...
  • Page 144 LTV Roadside Assistance 4287 Beltline Road, Box #198 Addison, TX 75001 for EMERGENCY ROADSIDE CALL 1•877•219•3831...
  • Page 145 Triple E Recreational Vehicles and Leisure Travel Vans are brands and trademarks of Triple E Canada Ltd. 301 Roblin Blvd., Box 1230 Winkler, MB Canada R6W 4C4 Telephone: 204-325-4361 Fax: 204-325-5241 US Address: P.O. Box 68 Walhalla, ND 58282 www.tripleerv.com • info@tripleerv.com • www.leisurevans.com • general@leisurevans.com Product improvement is a continuing process at Triple E Recreational Vehicles.

Table of Contents
