Getting Started with NI 7340/7350
Motion Controllers and AKD Servo
Drives
This document explains how to install and configure the AKD servo drives for use with the
NI 7340 and NI 7350 motion controllers.
If you encounter any problems during setup, refer to the
Tip
Troubleshooting
Contents
What You Need to Get Started ................................................................................................. 2
Hardware .......................................................................................................................... 2
Software............................................................................................................................ 3
Related Documentation .................................................................................................... 4
NI Motion Controller Configuration and Installation............................................................... 5
Step 1: Install NI-Motion.................................................................................................. 5
Step 2: Install the NI 7340/7350 Motion Controller......................................................... 5
RT PXI Controller (PXI 7340/7350 Only).................................................................... 7
NI UMI and AKD Servo Drive Configuration and Installation ............................................... 8
Step 1: Connect and Configure the NI UMI..................................................................... 8
Step 2: Mount the Drive and Connect the Protective Earth ............................................. 14
Step 5: Connect the Motor and Encoder to the Drive....................................................... 19
Step 6: Connect the AC Input Power................................................................................ 20
Step 7: Connect the Drive Communication...................................................................... 21
Step 8: Confirm Drive Connections ................................................................................. 22
Software Installation and Configuration................................................................................... 23
Step 1: Update Firmware on the Motion Controller......................................................... 23
Step 2: Configure the NI Motion Controller .................................................................... 23
Step 3: Install AKD WorkBench and Configure the Drive .............................................. 25
Step 4: Test the Motor In MAX........................................................................................ 33
Tips and Troubleshooting ......................................................................................................... 34
The Drive Does Not Enable.............................................................................................. 34
Cannot Communicate With the Drive Using Ethernet ..................................................... 34
UMI-7772/74 Does Not Turn On ..................................................................................... 34
Drive Does Not Turn On .................................................................................................. 34
Connecting to the PC Using a Static IP............................................................................ 34
section for assistance.
Tips and
