INSTALLATION GUIDE
Installing Your GPIB-SCSI-A
and NI-488.2 for Solaris
This document describes how to configure and connect the GPIB-SCSI-A to
your Sun SPARC system and how to install NI-488.2 for Solaris. The NI-488.2
software included in this kit is intended for use with Sun SPARC systems running
Solaris 2.6 or later. Other documentation, including the software reference
manual, is available on your NI-488.2 software for Solaris CD in the
\documentation
Before you install your GPIB controller, consult the manual that came with your
workstation for specific instructions and warnings. You must have superuser
privileges to install the hardware and software.
October 2003
323734A-01
™
folder.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for National Instruments GPIB-SCSI-A
Summary of Contents for National Instruments GPIB-SCSI-A
- Page 1 NI-488.2 for Solaris ™ This document describes how to configure and connect the GPIB-SCSI-A to your Sun SPARC system and how to install NI-488.2 for Solaris. The NI-488.2 software included in this kit is intended for use with Sun SPARC systems running Solaris 2.6 or later.
-
Page 2: Configuring The Hardware
Optional parity checking on the SCSI port is disabled. The SCSI ID that the GPIB-SCSI-A responds to is set at 5, and the primary GPIB address is set at 0. Additionally, the GPIB-SCSI-A kit is shipped from the factory with a SCSI Installing Your GPIB-SCSI-A and NI-488.2 for Solaris... -
Page 3: Configuration Switch Settings For Sw1
SCSI ID (Target ID) and the GPIB address. Do not change any other switch settings from the factory default settings. The factory default setting of the GPIB-SCSI-A Target ID is 5. To confirm that a Target ID of 5 is available in your system, print out the startup messages from the... -
Page 4: Configuration Switch Settings For Sw2
The DIP switch at location SW2 on the rear panel in Figure 3 is used to configure the mode of operation for the GPIB-SCSI-A. These switch settings should not be changed for use with the Sun SPARC system. Figure 3 shows the factory default settings. - Page 5 Switch Position Indication 1–3 Reserved and should remain OFF Double buffering is enabled GPIB-SCSI-A completes all data requests to the count specified GPIB-SCSI-A buffers data during data transfer commands GPIB-SCSI-A neither notices nor reports SCSI parity errors Operating in S (SCSI) mode ©...
-
Page 6: Connecting The Hardware
Sun SPARC system for specific instructions and warnings. There are two methods for connecting the GPIB-SCSI-A to the Sun SPARC system. One method is connecting the GPIB-SCSI-A directly to the Sun SPARC system unit by using a cable with the proper connectors at each end. The other method is daisy-chaining. -
Page 7: Step 2. Connect The Cables
SCSI bus. Complete the following steps to connect the cables: 1. Connect the SCSI cable to the GPIB-SCSI-A and fasten it securely. Connect the other end to your SCSI system. Be sure to use only shielded SCSI cables. Total cable length in your SCSI system should be less than 6 m, and... -
Page 8: Using Scsi Terminating Resistors
Read the documentation for each device in your system to find out what kind of termination it provides. If your GPIB-SCSI-A is located at the end of an SCSI bus, you can prevent echoes by leaving the terminating resistor pack installed on one of the ports on the rear panel of the GPIB-SCSI-A. - Page 9 6 SCSI Host Figure 4. Location of Terminating Resistors for GPIB-SCSI-A at End of SCSI Bus If your GPIB-SCSI-A is not located at the end of the SCSI bus, remove the terminating resistor pack from the rear panel of the GPIB-SCSI-A. Also ensure that all other devices in the middle of the bus (for example, the SCSI disk drive in Figure 4) do not have terminating resistors installed.
-
Page 10: Step 4. Power On Your System
Step 3. Switch On Your GPIB-SCSI-A Switch on your GPIB-SCSI-A by using the rocker switch on the rear panel. The POWER LED should come on immediately and the READY indicator on the front panel should come on after the GPIB-SCSI-A has passed its power-on self-test, indicating that the unit is ready for operation. -
Page 11: Configuring The Software With Ibconf (Optional)
2. Type the following command to start ibconf ibconf After you have installed and configured the software, you should verify the installation. Refer to the Installation Verification section. © National Instruments Corporation Installing Your GPIB-SCSI-A and NI-488.2 for Solaris... -
Page 12: Removing Ni-488.2 (Optional)
Removing NI-488.2 (Optional) If you ever decide to stop using your GPIB-SCSI-A, you can remove NI-488.2 from your system. To remove NI-488.2 from the kernel configuration, you must have superuser privilege and the driver must not be in use. Enter the following command to unload the software:... -
Page 13: Introduction To Ibic
C/C++. You must link the language interface library with your compiled source code. Link the GPIB C language interface library using one of the following commands, © National Instruments Corporation Installing Your GPIB-SCSI-A and NI-488.2 for Solaris... -
Page 14: Common Questions
NI-488.2M Software Reference Manual. What could be causing a problem if the installation process fails? The most probable reason is that the GPIB-SCSI-A is at a different SCSI Target ID than what you entered during installation. Reinstall using the correct ID. -
Page 15: Technical Support And Professional Services
For information on using the NI-488.2 language interfaces, refer to the Programming Considerations section. Technical Support and Professional Services Visit the following sections of the National Instruments Web site at ni.com technical support and professional services: • Support—Online technical support resources include the following: –... - Page 16 National Instruments™, NI™, ni.com™, NI-488™, NI-488.2™, and NI-488.2M™ are trademarks of National Instruments Corporation. Product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
