Page 1: User Manual
USER MANUAL [ G - T E C H S E R I E S ] GWH09AEC-K6DNA1A (GWH09AEC-K6DNA1A/I + GWH09AEC-K6DNA1A/O) GWH12AEC-K6DNA1A (GWH12AEC-K6DNA1A/I + GWH12AEC-K6DNA1A/O) ORIGINAL INSTRUCTIONS, VER. 01 2019-12-10... - Page 2 IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 3: Table Of Contents
Content Operation Notices The Refrigerant ....................1 Precautions......................2 Maintenance Emergency operation ................... 8 Clean and maintenance..................9 Screen Operation Guide Parts name......................20 Buttons on remote controller................21 Introduction for buttons on remote controller............22 Function introduction for combination buttons............. 26 Replacement of batteries in remote controller ............. -
Page 4: Explanation Of Symbols
Explanation of Symbols Indicates a hazardous situation that, if not avoided, will DANGER result in death or serious injury. Indicates a hazardous situation that, if not avoided, could WARNING result in death or serious injury. Indicates a hazardous situation that, if not avoided, may CAUTION result in minor or moderate injury. -
Page 5: The Refrigerant
Appliance filled with flammable gas R32. Before use the appliance, read the owner’s manual first. Before install the appliance, read the installation manual first. Before repair the appliance, read the service manual first. The Refrigerant To realize the function of the air conditioner unit, a special refrigerant circulates in the system. -
Page 6: Precautions
Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 7 Precautions WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
- Page 8 Precautions WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
- Page 9 Precautions WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
- Page 10 Precautions WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
- Page 11 Precautions WARNING The air conditioner is not allowed to use in a room that has running fire (such as fire source, working coal gas ware, operating heater). It is not allowed to drill hole or burn the connection pipe. The air conditioner must be installed in a room that is larger than the minimum room area.
-
Page 12: Emergency Operation
Emergency operation If remote controller is lost or damaged, please use aux. button to turn on or turn off the air conditioner. The operation in details is as below: As shown in the fig. Open panel, press aux. button to turn on or turn off the air conditioner. -
Page 13: Clean And Maintenance
Clean and maintenance Schematic diagram of parts Filter Panel Evaporator Storage groove of screw Swing motor Base Cross buckle Silver screw Bottom case Blade Drainage pipe Guard network Air-outlet frame Screw cover Swing blade Clasp of swing blade Guide louver... - Page 14 Clean and maintenance Notices for clean When the unit has operated for a period of time and the display flashes to display " " continuously, it indicates you should clean the air conditioner. When hold “ ” button on the remote controller for 3s to enter into deep cleaning (power must be cut off for cleaning) under off status, the reminding status will disappear after turning on the unit.
- Page 15 Clean and maintenance Filter clean Filter ①Hold the handles at both sides of filter with both hands, and then pull the filter upwards to remove it. Handle ②Use clear water to wash it or dust catcher to clean it. If the filter is very dirty (such as grease), use warm water (45℃) dissolved with neutral detergent to clean it, and then put it at the shady place to dry it.
- Page 16 Clean and maintenance Deep clean (parts clean) Guide louver clean ①Under standby status, press button for 3s, and the display flashes to display . Meanwhile, the guide louver will open automatically. T-ON ②When the guide louver automatically ③Press the clasp at the left side of rotates to the maximum position, the swing blade and pull it to the right side, and then it can separate...
- Page 17 Clean and maintenance Air-outlet frame clean Caution The black screw is the removable screw. Prohibit disassembling the silver screw at your will (except the silver screw of blade). Prevent the air-outlet frame dropping to avoid injury. ①Open the panel with both hands. ②Use screwdriver to remove 3 black When the panel is opened to the screws on the upper side of the...
- Page 18 Clean and maintenance Bottom case and parts clean 1.Pull out the drainage pipe Press the beige locking spring at both ends of white drainage pipe simulta- neously, and then pull the drainage pipe backwards. Caution: There may be residual water drop in the drainage pipe.
- Page 19 Clean and maintenance ③Remove 4 black screws at both sides used for fixing the bottom case. ④Press the appointed positions at both sides with both thumbs (as shown in below figure), hold the bottom case with other four fingers and then lift it upwards, and then remove the bottom case of the air conditioner.
- Page 20 Clean and maintenance Indoor unit installation Caution Before reinstall the bottom case when it has been cleaned, please check whether the blade has been pushed to the left side. Install bottom case Hold the position with " " under the bottom case, push it upwards parallel along the guide rail of base and then check whether the both ends of bottom case is set into the tail of the guide rail of base for ensuring the installation.
- Page 21 Clean and maintenance Pull blade Hold the blade node to pull it to the right side until to the locking status. Blade node Locking status Unlocking status Tighten silver screw Please make sure the blade is locked and then the silver screws of blade can be tightened clockwise.
- Page 22 Clean and maintenance Install drainage pipe Hold the joint of white drainage pipe with hand, install the drainage pipe to the direction of drainage mouth until you have head a sound. White drainage pipe Install air-outlet frame Insert the clasp at the back side of the air-outlet frame into the groove of the base (as shown in fig.3) until you have heard a sound.
- Page 23 Clean and maintenance Install guide louver Hold the guide louver with the left ②Hold the left side connection rod with ① hand, hold the connection rod with left hand, hold the air louver with the right hand and then install the the right hand and then assemble "cross groove"...
-
Page 24: Parts Name
Parts name power indicator temp. indicator display receiver window HOLD 3S WiFi remote controller... -
Page 25: Buttons On Remote Controller
Buttons on remote controller Note: with multifunction; For some function, which the model doesn't have, if press the corresponding button on the remote controller that the unit will keep the original running status. Operation indicator " " is ON (red indicator, the colour is different for different models). -
Page 26: Introduction For Buttons On Remote Controller
Introduction for buttons on remote controller ℃ Note: Only for models with heating function. 、 、 、 、... - Page 27 Introduction for buttons on remote controller Press this button can select left & right swing angle. Fan blow angl e can be selected circularly as below: no display (stops at current position) Press this button continuously more than 2s, the main unit will swin g back an forth from left to right, and then loosen the button, the u nit BUTTON will stop swinging and present position of guide louver will be kept...
- Page 28 Introduction for buttons on remote controller (1)Under Sleep 3 mode, press "Turbo" button for a long time, remote controller enters into user individuation sleep setting status, at this time, the time of remote controller will display "1hour", the setting temperature "88" will display the corresponding temperature of last setting sleep curve and blink (The first entering will display according to the initial curve setting value of original factory);...
- Page 29 Introduction for buttons on remote controller T-ON button "T-ON" button can set the time for timer on. After pressing this button, " " icon disappears and the word "ON" on remote controller blinks. Press "▲" or " " button to adjust TIMER ON setting.
-
Page 30: Function Introduction For Combination Buttons
Function introduction for combination buttons Under cooling mode, press "TEMP" and "CLOCK" buttons simultane- ously to start up or turn off energy-saving function. When energy-saving function is started up, "SE" will be shown on remote controller, and air conditioner will adjust the set temperature automatically according to ex-factory setting to reach to the best energy-saving effect. -
Page 31: Replacement Of Batteries In Remote Controller
Replacement of batteries in remote controller NOTICE ● During operation, point the remote control signal sender at the receiving window on indoor unit. ● The distance between signal sender and receiving window should be no more than 8m, and there should be no obstacles between them. ●... -
Page 32: Malfunction Analysis
Malfunction analysis General phenomenon analysis Please check below items before asking for maintenance. If the malfunction still Phenomenon Check items Solution ● Whether it's interfered severely ● Pull out the plug. Reinsert (such as static electricity, stable the plug after about 3min, and voltage)? then turn on the unit again. - Page 33 Malfunction analysis 16℃ ℃. ● Set temperature range in HEAT mode: 8℃ ~30℃. ● Whether there’s odour source, ● Eliminate the odour source. Odours are such as furniture and cigarette, emitted etc.
- Page 34 Malfunction analysis Phenomenon Check items Solution ● Whether there’s interference, ● Disconnect power, put back Air conditioner such as thunder, wireless power, and then turn on the operates nor- devices, etc. unit again. mally suddenly ● The noise is the sound of “Water ●...
-
Page 35: Error Code
Malfunction analysis Error Code Error code Troubleshooting E1,E5,E8 It can be eliminated after restarting the unit. If not, please contact qualified professionals for service. H3,H6 C5,E6 F3,F4 Please contact qualified professionals for service. F0,F1,F2 WARNING... - Page 36 Appliance filled with flammable gas R32. In case of quality problem or other please contact your local supplier or authorized service center. Emergency number: 112 PRODUCER GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI West Jinji Rd, Qianshan, 519070 Zhuhai China REPRESENTATIVE GREE Czech &...
