Summary of Contents for Gree GTHD(09)AANK3A1AI
- Page 1 O P E R A T I O N & INSTALLATION INSTRUCTIONS FLOOR AND CEILING TYPE UNIT GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Read this operating & installation instruction carefully and keep it for future reference MODEL GTHD(09)AANK3A1AI GTHD(12)AANK3A1AI GTHD(18)AANK3A1AI...
-
Page 2: Table Of Contents
CONTENTS OPERATION INSTRUCTIONS Part names and their functions ......................1 How to use the remote control to operate the unit ................2 Maintenance............................11 Operating guide..........................12 Precautions ............................13 Checking before contact the service man..................14 INSTALLATION INSTRUCTIONS Installation of Indoor unit ........................15 Refrigerant piping work ........................ -
Page 3: Part Names And Their Functions
PART NAMES AND THEIR FUNCTIONS OPERATION INSTRUCTIONS Remote Control Remote Control Holder... -
Page 4: How To Use The Remote Control To Operate The Unit
How to use the remote control to operate the unit OPERATION INSTRUCTIONS Name and Function-Remote control Note: Be sure that there are no obstructions between receiver and remote controller. Don’t drop or throw the remote controller. Don’t let any liquid in the remote controller and put the remote controller directly under the sunlight or any place where is very hot. - Page 5 How to use the remote control to operate the unit OPERATION INSTRUCTIONS Name and Function-Remote control. (Remove the cover) Note: This type of remote controller is a kind of new current controller. some buttons of the controller which are not available to this Air con- ditioner will not be described below.
- Page 6 How to use the remote control to operate the unit OPERATION INSTRUCTIONS COOL mode operation procedure According to difference between room temp. and set temp., microcomputer can control cooling on or not. If room temp. is higher than set temp., compressor runs at COOL mode. If room temp.
- Page 7 How to use the remote control to operate the unit OPERATION INSTRUCTIONS HEAT mode operation procedure If room temp. is lower than set temp, compressor runs at HEAT mode; If room temp. is higher than set temp., compressor and outdoor fan motor stop. SET TEMP.
- Page 8 How to use the remote control to operate the unit OPERATION INSTRUCTIONS DRY mode operation procedure If room temp. is lower than set temp., compressor ,outdoor fan motor stop. If room temp. is between of set temp., air conditioner is drying.If room temp. is higher than set temp, it’s at COOL mode.
- Page 9 How to use the remote control to operate the unit OPERATION INSTRUCTIONS AUTO mode operation procedure Under Auto mode operation, standard SET TEMP. is 25 for COOL mode and 20 HEAT mode. 1.Plug in,press ON/OFF button, then air conditioner is turned on. 2.According to room temp.
- Page 10 How to use the remote control to operate the unit OPERATION INSTRUCTIONS TIMER mode operation procedure At stopping,press TIMER ON button, set ON TIME in range of 0 to 24 hour to start the unit automatically. Timer cancellation At operating,press TIMER OFF button, set OFF TIME in range of 0 to 24 hour to stop the unit automatically.
- Page 11 How to use the remote control to operate the unit OPERATION INSTRUCTIONS SLEEP mode operation procedure As the unit is cooling or drying, if SLEEP operation is set, SET TEMP. would increase 1 in 1 hour and 2 in 2 hours. As the unit is heating, if SLEEP operation is set, SET TEMP.
- Page 12 How to use the remote control to operate the unit OPERATION INSTRUCTIONS How to insert batteries 1.Remove the cover from the back of the remote control. 2.Insert the two batteries ( Two AAA dry - cell batteries ) and press but- ton “ACL”.
-
Page 13: Maintenance
MAINTENANCE OPERATION INSTRUCTIONS WARNING:Before inspection and maintenance of the unit, always set the power switch to "OFF" to cut off the power supply. 3.1 CLEANING THE AIR FILTERS WARNING The air filter must be cleaned by profressional. 3.2 CLEANING THE UNIT THE ENCLOSURE Clean the enclosure of the air conditioner and the remote control with dry cloth or a vacuum cleaner.If damp cloth is used, remove molsture... -
Page 14: Operating Guide
OPERATING GUIDE OPERATION INSTRUCTIONS ● ● The temperature should not be set To disribute cool air throughout the room, lower than what you need.This would adjust air flow directionas shown by the lead to increase energy cost. arrows (see picture)to diffuse cool air. ●... -
Page 15: Precautions
PRECAUTIONS OPERATION INSTRUCTIONS ● Turn off the air conditioner if,while running, ● Do not locate any obstacle against the air flow electricity interference occurs,if the unit is direction of indoor and outdoor unit.Inefficient not to be used for a long time,cut off the performance or malfunction may result. -
Page 16: Checking Before Contact The Service Man
CHECKING BEFORE CONTACT THE SERVICE MAN OPERATION INSTRUCTIONS Check the following before contacting the service man.You may find ● the solution to your problems.After checking,if it still does not operate, please contact your local dealer. P R O B L E M C A U S E S ● Check if breaker switch is still on. -
Page 17: Installation Of Indoor Unit
INSTALLATION OF INDOOR UNIT OPERATION INSTRUCTIONS WARNING:The air condition must be installated and maintained by professional. CAUTIONS FOR INSTALLATION WHERE SELECTION OF INSTALLATION LOCATION. AIR CONDITIONER TROUBLEIS LIABLE ● Such a place where cool air can be distributed throughout the room. TO OCCUR. - Page 18 INSTALLATION OF INDOOR UNIT OPERATION INSTRUCTIONS Fig.3 Fig.4 Fig.5 Fig.6 Fig.7...
- Page 19 INSTALLATION OF INDOOR UNIT OPERATION INSTRUCTIONS INSTALLATION DIMENSIONS OF THE INDOOR UNIT When installing the indoor unit, you can refer the paper pattern for installation, and make sure that the drainage side must be 10mm lower than the other side in order to drain the condensation water fluently.
-
Page 20: Refrigerant Piping Work
REFRIGERANT PIPING WORK OPERATION INSTRUCTIONS MODEL PIPE SIZE THICKNESS (mm.) GTHD(09)AANK3A1AI 1/4" GTHD(12)AANK3A1AI 1/4" GTHD(18)AANK3A1AI 1/4" Heat insulation layer MODEL PIPE SIZE THICKNESS (mm.) GTHD(09)AANK3A1AI 0.71 3/8" Heat insulation layer GTHD(12)AANK3A1AI GTHD(18)AANK3A1AI WARNING: The temperature of refrigerant circuit will be high. please keep the connecting... -
Page 21: Drain Piping Work
DRAIN PIPING WORK OPERATION INSTRUCTIONS... -
Page 22: Test Running
TEST RUNNING OPERATION INSTRUCTIONS EVALUATION OF THE PERFORMANCE CAUTION:Operating by professional. ● Check electrical main wire's voltage. ● Use a thermometer to measure cool air both in and out. ● The difference between in-air and out-air temperature should not be less than ８℃。 Thermometer ● The unit has Auto-restart funcation, it can remember the running model before power-broken. -
Page 23: Routine Check After Installation
ROUTINE CHECK AFTER INSTALLATION OPERATION INSTRUCTIONS Check after installation CAUTION:Operating by professional. Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop,shake or emit noise. It may cause insufficient refrigerating capacity. Have you done the refrigerant leakage test? It may cause condensation and dripping. -
Page 24: Fault Indication
FAULT INDICATION OPERATION INSTRUCTIONS serial LED （red） Meaning （ ） （yellow） （green） number Compressor high pressure protection Blink once unit stop Indoor unit anti-freezing protection Twice Low-pressure protection Three unit stop times Four Air exhaust protection unit stop times Five Over current protection unit stop times Communication malfunction unit stop... - Page 25 FAULT INDICATION OPERATION INSTRUCTIO When the unit is running operated by wire controller The Codes of Failure Definitions are as Follows: Meaning Wire controller Fault code Compressor high pressure protection unit stop Indoor unit anti-freezing protection Low-pressure protection unit stop Air exhaust protection unit stop Over current protection unit stop Communication malfunction unit stop...
- Page 26 GREE ELECTRIC APPLIANCES, INC. OF ZHUHAI Address : Jinji West Road, Qianshan, Zhuhai, Guangdong Tel : (0756) 8617555 (Customer Inquiry Service Center) Postcode : 519070 GREE ELECTRIC APPLIANCES,INC.OF ZHUHAI 66162469...
