Daewoo Compact Wooden User Manual page 5

Description of Parts – Rear Panel
20
19
14. Telescopic Aerial
15. Battery Compartment
16. Battery Compartment Catch
17. Micro USB DC Power Socket
18. Headphone Jack Socket
19. On/Off Switch
20. Bass Port
21. Mains Adaptor
22. Micro USB DC Power Plug
Before the first time you use your DAB Radio
Please read these operating instructions thoroughly and keep them in a safe place for future reference.
Remove all packing materials and discard responsibly.
Using the Radio with Batteries
• Open the Battery Compartment (15) and push the tab on the Battery Compartment Cover (16) to
the right and remove (arrowed below)
• Insert four 1.5V AA Batteries (not supplied) into the battery compartment being careful to observe
the polarity markings inside:
• Replace the Battery Compartment Cover.
14
18 17
16
22
15
21
5
