1. Parts and Functions

Handset
Key functions
Handset
Handset curve
Unlock button
Call button/Unlock
2nd button
Speaker

Terminal Descriptions

SW- SW+ K4
K3
L2 L1
97
2
Pick up to communicate with visitor.
Connect handset with monitor.
Press to release the door.
In standby mode, pick up handset, then press Call button to
activate the inner call;
During calling/talking state, press Unlock 2nd button to
release the second door.
Send out voice from the visitor.
K4
SW- SW+
SW+,SW-
K3
L1, L2
L2 L1
Unlock button
Call button/Unlock 2nd button
Speaker
handset curve
:
SW+,SW- Door bell call button connection port
K4
:
L1,L2 Bus terminal.
K3
4:
K Used to Ring Tone setting.
DIP2
:
K3 Used to Ring Volume setting
DIP1(Bit1~6):
DIP1
DIP2(Bit1~3):
33
Side View
.
Used to User Code setting
Used to Slave Monitor Address
or Extended Address setting
.
.
.
