Hanna Instruments WATER TEST Instruction Manual

MAINTENANCE

• Separate the compartment from the tester.
• Remove deposits formed on the liquid
and the pH glass bulb by soaking in HI 7061
solution for 1½ hour.
• Soak the platinum wire in acetone for half hour.
• Rinse the bulb, platinum wire and liquid junction
thoroughly with distilled water
• Reassemble the compartment and the tester.
• Fill the compartment with tap water.

BATTERY REPLACEMENT

When the Water Test cannot be switched on or the
display fades, pull out the battery cover and replace
all three 1.4V batteries, paying attention to their po-
larity. Battery replacement must only take place in a
non hazardous area using the battery types speci-
fied in this instruction manual.

ACCESSORIES

HI 7004M Buffer solution pH 4.01 (230 ml)
HI 7004L Buffer solution pH 4.01 (460 ml)
HI 7007M Buffer solution pH 7.01 (230 ml)
HI 7007L Buffer solution pH 7.01 (460 ml)
HI 7010M Buffer solution pH 10.01 (230 ml)
HI 7010L Buffer solution pH 10.01 (460 ml)
HI 7031M Conductivity solution 1413 µS/cm @25°C (230 ml)
HI 7031L Conductivity solution 1413 µS/cm @25°C (460 ml)
HI 7061M General Cleaning solution (230 ml)
HI 7061L General Cleaning solution (460 ml)
BATT009/P 1.4V battery (100 pcs)
HI 76501/P Calibration screwdriver (20 pcs)

RECOMMENDATIONS FOR USERS

Before using this product, make sure that it is entirely suitable for
the environment in which it is used.
Operation of this instrument in residential area could cause
unacceptable interferences to radio and TV equipments,
requiring the operator to take all necessary steps to correct
interferences.
The glass bulb at the end of the pH electrode is sensitive to
electrostatic discharge.
Avoid touching this glass bulb at all times.
For calibration it is recommended to use an antistatic
screwdriver.
Any variation introduced by the user to the supplied equipment
may degrade the instrument's EMC performance.
To avoid electrical shock, do not use this instrument when voltages
at the measurement surface exceed 24 VAC or 60 VDC.
To avoid damages or burns, do not perform any measurement in
microwave ovens.
Water Test
junction
ON / OFF RANGE
4 pH 7
BATTERY
COVER
IMMERSION LEVEL

DECLARATION OF CONFORMITY

We
Hanna Instruments Srl
V.le delle industrie 12
35010 Ronchi di Villafranca (PD)
ITALY
herewith certify that the pH / ORP / Conductivity / Temperature meter
Water Test
has been tested and found to be in compliance with the following regulations:
IEC 801-2 Electrostatic Discharge
IEC 801-3 RF Radiated
EN 55022 Radiated, Class B
Date of Issue: 12-12-1995
D.Volpato - Engineering Manager
On behalf of
Hanna Instruments S.r.l.
WATER TEST
The "four-in-one" portable meter

GENERAL DESCRIPTION

The HANNA Water Test is a "four-in-one" portable meter designed for
fast and accurate analysis and monitoring of water in biological
applications, industrial wastewater, rivers, lakes, etc. It measures the
main parameters in water analysis, namely, pH, oxidation-reduction
potential (REDOX), conductivity and temperature. All is needed for
the analysis is a small sample of the water which is poured into the
compartment and the 4 measurements are immediately available.
The instrument has a complete pH range from 0 to 14, an ORP range
from -1000 to +1000 mV, a conductivity range from 0 to 2000 µS/cm
and a temperature range from 0 to 60°C. The instrument can be
calibrated for pH and conductivity and comes with replaceable batteries.

SPECIFICATIONS

pH ORP
RANGE 0.0 to 14.0 pH ±1000 mV
RESOLUTION 0.1 pH 1 mV
ACCURACY ±0.2 pH ±5 mV
(@20°C/68°F)
TYPICAL EMC ±0.4 pH ±2mV
DEVIATION
CALIBRATION
pH: Manual double point through Offset and Slope trimmers
µS/cm: Manual single point through trimmer
BATTERY 3 x 1.4V batteries for approx. 200 hours of continuous use
DIMENSIONS 190 x 85 x 85 mm
(7.4 x 3.3 x 3.3")
WEIGHT 260 g (9.2 oz.)
Water Test
LIQUID
CRYSTAL
DISPLAY
ON / OFF
ON / OFF
SWITCH
Stay in Touch with the Manufacturer !
Conductivity Temperature
0 to 1999 µS/cm 0.0 to 60.0°C
1 µS/cm 0.1°C
±2% Full Scale ±1°C
±2% Full Scale ±1°C
FRONT BACK
RANGE SWITCH
RANGE
4 pH 7
OFFSET & SLOPE
CALIBRATION
TRIMMERS
COVER
BATTERY
COVER
MAXIMUM IMMERSION LEVEL
IMMERSION
LEVEL
BLACK
COMPARTMENT
