Technical Specifications - ADC Gas Discharge Tube ComProtect Spec Sheet

ComProtect
Single-Pair Protectors For Series 2 Switching Blocks

Technical Specifications

DC Sparkover
Impulse Sparkover
Insulation Resistance
Impulse Discharge Current
Alternating Discharge current
Bit Error Rate (BER)
Longitudinal Balance
Operating Temperature
Housing material
DC Sparkover may exceed ±25% after discharge, but will continue to protect without venting.
1
INSERTION LOSS
dB frequency range
< 0.01 dB up to 16 MHz
< 0.025 dB 16 - 31.25 MHz
< 0.07 dB 31.25 - 42.6 MHz
< 0.15 dB 42.6 - 100 MHz
9.4 mm
9.4 mm
47.3 mm
21.3 mm
21.3 mm
ComProtect dimensions
O r d e r i n g I n f o r m a t i o n
Description
ComProtect GDT 2/1 CP TP280A1 - Quantity: 1 (Pack of 100)
Gel ComProtect GDT 2/1 CP TP280G1 - Quantity: 1 (Pack of 100)
