- Page 1 TECH TIPS Service Call: No start after transport P9B and/or Boom length switches fault Tools Needed: None Model: S120/125...
- Page 2 Tech Tips Safety Rules Danger Failure to obey the instructions and safety rules in the appropriate Operator's Manual and Service Manual for your machine will result in death or serious injury. Many of the hazards identified in the operator’s manual are also safety hazards when maintenance and repair procedures are performed.
- Page 3 TECH TIPS Step 1 Locate the limit switches on the left side of the zero tube. Under the cable track tube you will find a cover that has a hole and 2 limit switches inside. Step 2 Look threw the hole and see if limit switch arm is dropped into a slot in the boom.
- Page 4 TECH TIPS Step 3 Note: This is out of the slot. Step 4 Press auxiliary and boom retract buttons at the same time to retract boom, hold for 10-15 sec. to allow the pressure to build.
- Page 5 TECH TIPS Step 5 Once the boom retract it should look like the picture. If it does not call 1-800-536-1800 for further tech support.
