Congratulations for buying a quality product. FERMAX ELEC-
TRONICA S.A.E. manufactures and sells its well known
prestigious equipment, designed to the most technologic and
aesthetic requirements. The components of this KIT have been
designed by Ramón Benedito, National Spanish Design Award
winner, and developed by FERMAX ELECTRÓNICA S.A.E. We
hope you will have many years of service from it.
If you wish further information about FERMAX, or make any
sugestion, contact us in the web (http:\\www.fermax.es).
ENGLISH
Pag 16
Advertisement
Table of Contents
Related Manuals for Fermax KIT VIDEOCHALET CITYMAX
Summary of Contents for Fermax KIT VIDEOCHALET CITYMAX
- Page 1 Ramón Benedito, National Spanish Design Award winner, and developed by FERMAX ELECTRÓNICA S.A.E. We hope you will have many years of service from it. If you wish further information about FERMAX, or make any sugestion, contact us in the web (http:\\www.fermax.es). ENGLISH...
-
Page 2: Table Of Contents
How to add terminals ................27 ACCESORIES ...................... 28 Extension call ..................36 Stair light Relay ..................28 Second door control ................28 Connection to TV set ................28 TROUBLESHOOTING HINTS ................29 KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 17... -
Page 3: Introduction
INTRODUCTION The KIT VIDEOCHALET CITYMAX is an advanced Video Door Entry professional system to be installed in bungalows or small residential complexes. It is basically made up of an Outdoor Panel, which is installed outside the house, and a Mo- nitor, installed inside. -
Page 4: The Citymax Monitor
Only in installations with AUXILIARY CAMERA KIT or ADDITIONAL VIDEO PANEL (optional). THE OUTDOOR PANEL Volume for OUTDOOR PANEL AMPLIFIER mesh Volume for MONITOR Terminals for CAMERA CONNECTION module PAN & TILT control TEST connector CALL Push buttons PUSHBUTTON connector KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 19... -
Page 5: Camera Test Connector Detail
Camera Test Connector detail The test connector included in the CityMax camera is used for testing that both camera and Monitor are working correctly. Once the Monitor is plugged into this connector the screen will be activated automatically. 1. TEST connector Detail. 2. -
Page 6: Outdoor Panel Installation
1.Before embedding the box, break the 2.Place the embedding box at the desired flange where the cables will be passed height (1.7m aprox.). Make sure that the through. box is totally flush with the wall. KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 21... - Page 7 3.Place the waterproof tapes supplied with 4.Use the hinges to connect the wires and the KIT. handle the Panel comfortably. 5.Push up the houvre behind nameplate 6.Close the Panel and fasten the screws the louvre and place the label. You can with the allen key supplied.
-
Page 8: Power Supply Installation
NOTE: The Power Supply must be installed in a place dry and safe from inclemency of weather. It is advisable to install it protected through a thermo-magnetic circuit breaker at the main input. KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 23... -
Page 9: Operation
OPERATION Calling * When the monitor is idle, the screen and the led indicator are off. When the call pushbuton at the Outdoor Panel is pressed a tone is heard from the monitor but also from the outdoor panel. The screen turns on and led indicator turns off. Call sound is also heard in any additional equipments in the same house. -
Page 10: Installation Diagrams
INSTALLATION DIAGRAMS The following are the installation diagrams for the KIT VIDEOCHALET 1 and 2 lines. Check suitable wire sections with the table. Wiring for KIT VIDEOCHALET CITYMAX 1/L Ref. 6002 KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 25... - Page 11 Cut the Resistor Wiring for KIT VIDEOCHALET CITYMAX Ref. 6006 Pag 26...
-
Page 12: How To Add Terminals
FLAT ADDITIONAL MONITOR 1 FLAT MONITOR 1 FLAT MONITOR C U T C U T RESIST. RESIST. C U T RESIST. KIT 1/L with additional Monitor KIT 2/L with additional Monitor (cascade connection) KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 27... -
Page 13: Accesories
ACCESORIES Extension call The electronic extension call (Ref. 2040) is used for extending the call sound in a place different from the one where the Monitor is installed, for instance in the garden. Ref. 2040 MONITOR Stairs light relay The relay (Ref. 2013) is used to activate an external device as stair or garden light, by means of the pushbutton in the Monitor... -
Page 14: Troubleshooting Hints
3. Verify that there is no shortcut between wires "3" and "6". No call tone 1. Check that terminal "4" connection is correctly connected. 2. Check the connection of terminal "3" (there is no speech from Panel to Monitor). KIT VIDEOCHALET CITYMAX Cod: 94017 Pag 29...
