SPL Elector User Manual page 2

Welcome
and thank you for choosing the Elector.
The Elector is based on the Director Mk2 and designed as a pure analog preamplifier. It features a total of six ana-
log inputs. Three of which are balanced with XLR connectors. The Elector is equipped with the big remote control-
lable aluminum volume control with marker LED and two mechanical VU meters.
Fans of analog tape machines or external audio processing can insert their beloved gear in the Tape Monitor loop.
VOLTAiR technology is what we also call the SPL 120V Rail Technology within the Professional Fidelity series. This
makes the Elector an outstandig device in terms of dynamic range, signal-to-noise ratio and headroom delivering an
exceptional sound experience with invincible serenity, transparency and realness.
Elector
INPUT SELECTOR
3 4
2 5
1 6
VOLTAiR
120V DC Audio Rail
2
ON
TAPE MONITOR VU
Off On 6 12
0
Analog Preamplifier
