Electrical Test Instruments PI-2500 & PI-5000
Section II - Detailed Description
==============================================================================
INPUT SUPPLY:
208/240 or 480 VAC +/- 10% (Field switchable)
SINGLE PHASE
60 HZ (50 Hz at 10% lower line voltages)
15 KVA (Continuous) at 12 KVA output (80% efficiency)
OUTPUT CURRENT & OVERLOAD CAPABILITIES:
7.6V (Par) 15.2 V (Ser)
2000 A 1000 A
2800 A 1400 A
4000 A 2000 A
6000 A 3000 A
8000 A 4000 A
10000 A 5000 A
14000 A* 7000 A*
20000 A* 10000 A*
*Available with 480 VAC input only; Max ON Times may be less at 208 or 240 VAC
DIMENSIONS AND NET WEIGHT
Height:
Width: 29.0in. (737 mm)
Depth: 25.0 in. (635 mm)
Weight:
STANDARD ACCESSORIES
Stabs, BS-50HV (½" bus, horizontal or vertical)
Stabs, BS-75HV (¾" bus, horizontal or vertical)
Stab adaptor assembly
Series bars
Input power plugs
Contacts leads
Technical manual
OPTIONAL ACCESSORIES
Remote initiate cable
Serial Interface Cable
==============================================================================
Copyright(C) 1994-2008
PI-2500 SPECIFICATIONS
Ovld Duty Max ON Time
1x 100% CONTINUOU
S
1.4x 50% 15 Minutes
2x 25% 5 Minutes
3x 10% 1.5 Minutes
4x 6% 45 Seconds
5x 4% 4 Seconds
7x 2% 1 Second
10x 1% 0.2 Second
41 in. (1041 mm) (includes castors and hood)
515 lb. (192 kg)
Electrical Test Instruments, LLC.
Page II-7
Min OFF Max Inp Curr
Time (@480/240)
N/A 32 / 64
15 Minutes 45 / 90
15 Minutes 64 / 128
15 Minutes 96 / 192
15 Minutes 128 / 256
2 Minutes 160 / 320
2 Minutes 224 / (448 *)
2 Minutes 320 / (640 *)
1 set
1 set
1 pair
3 pcs
3 pcs
1 pair
1 copy
