PROGRAMMING MODE
Ramp %(Aqua) Use by PSP and normal ramping Modes.
Blinks % Blinks % Blinks
1 10 11 110(Default) 21
2 220 12 120 22
3 30 13 130 23
4 40 14 140 24
5 50 15 150 25
6 60 16 160 26
7 70 17 170 27
8 80 18 180 28
9 90 19 190 29
10 100 20 200 30
valken.com
% Blinks % Blinks %
210 31 310 41 410
220 32 320 42 420
230 33 330 43 430
240 34 340 44 440
250 35 350 45 450
260 36 360 46 460
270 37 370 47 470
280 38 380 48 480
290 39 390 49 490
300 40 400 50 500

MAINTENANCE

MAINTAINING YOUR CODE
The CODE has been designed to require a minimal amount of maintenance for proper operation. It is recommended that before each
use you put 2 drops of light gun oil in the ASA. When the marker is gassed up the oil will distribute through the marker. This will be
adequate to keep the marker working properly.
Removing the ball detents for cleaning
The CODE uses two rubbery ball detents to prevent the double feeding of paintballs. They are located near the front of the receiver.
To remove, insert a 1/16" hex key into the access hole in the eye cover. Make sure that the hex key is fully engaged in the screw
otherwise you may strip the hex in the screw. Unscrew the cover and lift out the ball detent.
To install the ball detent
Place the ball detent and detent spring in the hole in the receiver. Put the cover screw in the slot of the cover and put the hex key in
the screw through the access hole in the cover. Place the cover over the ball detent/spring and tighten the screw.
Note: Do not over-tighten the screw otherwise you may strip the hex in the screw which will make it difficult to remove the cover.
Cleaning the CODE
First remove the bolt assembly by lifting the Cap button at the back
of the rear cap and pull it out. If the bolt is left in the breach, insert
a soft head stick from the front to push the bolt back out. You can
use a standard squeegee to clean the bore of the marker. Insert the
squeegee from the back of the marker and pull it through the front.
When the bore is cleaned, push the bolt assembly back from the
back until it click. PLEASE MAKE SURE THE REAR CAP BUTTON IS
LOCKED(DOWN)POSITION.
