QUICK SETUP GUIDE
Attaching the barrel
The barrel simply threads on. The barrel threads are autococker type.
Attaching the loader
Open the clamp lever and place the loader into the feedneck. Adjust the tightness of the clamp with a 5/32" hex key. Close the clamp
lever.
Battery replacement
Remove grip cover from foregrip. Press the button on the lower front of the foregrip. Pull the 9V battery out and dislodge it from the
battery cap. Replace with a fresh 9V battery. We recommend the use of a high quality alkaline battery.
Connecting the air source
The CODE has a standard ASA to accept a screw in air tank. First, make sure that the On/OFF is in OFF position (lever pointing to the
front). Carefully screw in the air tank until it stops. Flipping the lever backward will allow air to flow into the marker from the tank.
To remove the tank, flip the lever forward. This will release all the air in ASA and make it easier to remove the tank. We recommend the
use of compressed air or nitrogen air tank with a maximum output pressure of 800 PSI.
valken.com
QUICK SETUP GUIDE
Turning the marker ON
Press power button. Eyes on is blue/blinking blue for blocked/
unblocked eyes. Blinking yellow for eye malfunction (if the eyes
don't see the bolt return like if you block the eyes continually
with your finger). Eye malfunction reduces rate of fire to prevent
additional chopping.
Turning the marker OFF
Hold power button for 2 seconds or until the LED goes off to turn
off the marker.
Intelligent break beam ball sensor system
The CODE has a break beam sensor system. The eyes can be cleaned by simply removing the bolt and using a squeegee, or using
a 1/16" hex key to remove the eye cover. If any malfunction should occur the software automatically overrides the eye function and
reduces the rate of fire. When the marker first powers up, the eyes are on by default. To disable the sensor system, press the on/off
button for 1 sec until the LED is blinking red. To enable the eyes again, simply press the on/off button again for 1sec until the LED is
blinking blue.
