Appendix E – ELECTRO-MAGNETIC COMPATIBILITY TABLES
Guidance and manufacturer's declaration – electromagnetic emissions
FOR ALL ME EQUIPMENT
The ME EQUIPMENT is intended for use in the electromagnetic environment specified below.
The customer or the user of the ME EQUIPMENT should assure that it is used in such an
environment.
Emissions test Compliance
RF Emissions
Group 2
CISPR 11
RF Emissions
Class A
CISPR 11
Harmonic emissions
Class A
IEC 61000-3-2
Voltage fluctuations/
flicker emissions Complies
IEC 61000-3-3
Electromagnetic environment – guidance
The ME EQUIPMENT must emit electromagnetic
energy in order to perform its intended function.
Nearby electronic equipment may be affected.
The ME EQUIPMENT is suitable for use in all
establishments, other than
establishments and those directly connected to the
public low voltage power supply network that
supplies buildings used for domestic purposes .
Guidance and manufacturer's declaration – electromagnetic immunity
The ME EQUIPMENT is intended for use in the electromagnetic environment specified below.
The customer or the user of the ME EQUIPMENT should assure that it is used in such an
environment.
Immunity test
Electrostatic
discharge (ESD)
IEC 61000-4-2
Electrical fast
transient/burst
domestic
IEC 61000-4-4
Sovra-tensioni
IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11
Power frequency
(50/60Hz) magnetic
field
IEC 61000-4-8
NOTE : UT is the a.c. mains voltage prior to application of the test level.
I.A.C.E.R. Srl
FOR ALL ME EQUIPMENT
IEC 60601
Compliance level
Test level
± 6kV contact ± 6kV contact
± 8kV air ± 8kV air
± 2kV for power ± 2kV per power
supply lines supply lines
± 8kV for
NOT APPLICABLE
input / output lines
± 1kV line(s) to ± 1kV line(s) to
line(s) line(s)
± 2kV line(s) to ± 2kV line(s) to
earth earth
<5% U
T
(>95% buco in U )
<5% U per 0.5 cicli
T
T
per 0.5 cicli
40% UT (60% dip in
<5% UT for 1 cycle
UT) for 0.5 cycles
70% UT (30% dip in
70% UT for 25
UT) for 25 cycles
cycles
<5% UT (>95% dip
<5% UT for 5 sec
in UT) for 5 sec
3 A / m 3 A / m
Electromagnetic environment –
guidance
Floors should be wood, concrete
or ceramic tile.
If floors are covered with
synthetic material, the relative
humidity should be at least 30 %.
Mains power quality should be
that of a typical commercial or
hospital environment
Mains power quality should be
that of a typical commercial or
hospital environment
Mains power quality should be
that of a typical commercial or
hospital environment. If the user
of the ME EQUIPMENT requires
continued operation during
power mains interruptions, it is
recommended that the ME
EQUIPMENT be powered from an
uninterruptible power supply or
a battery.
Power frequency magnetic fields
should be at levels characteristic
of a typical location in a typical
commercial or hospital
environment
