ACCESSORIES
L'apparecchio è fornito del cavo di alimentazione di rete, and it can be used with
following accessories forniti in dotazione:
Description
Power cable supply (spina schuko)
Spare FUSES (see technical specifications)
User manual
Smart-card
Capacitive probe
Kit 3 capacitive electrodes (diameters 30,50,70)
Resistive probe
Kit 3 resistive electrodes (diameters 30,50,70)
Metallic mass (steel plate)
Bottle of conductive cream 1000ml
The accessory installing is simple and intuitive: each cable for the therapy, that allows
the connection with the 2 output channels, is equipped with a multi-pin connector to
be inserted into the socket on the front panel of the device.
Contact authorised dealers for problems or difficulty installation.
CONNECTIONS
The power entry module can be found on the back of the unit and consists of a three-
pole socket for the cable set, an extractible fuse box with two fuses (see technical
specifications) and the main switch.
Plug the power supply cable three-pin plug into the integrated board and ensure that
it is correctly plugged into the connector.
When using an extension lead, make sure that it has been earthed.
Failure to comply with the above instructions may lead to dangerous electrical
discharge causing machine damage and harm to persons.
The connection of the probe/applicator is simple: you need to connect your cable to
the device, inserting it into the connector on the rear panel.
Once you have checked that installation and assembly have been carried out
according to instructions provided up to this point in the manual, switch on the
machine making sure that the display screen is turned on correctly.
Optional
Supplied
1
1
1
1
1
1
1
1
1
1
I.A.C.E.R. Srl
8
