Placing In Rotary Hook - TAJIMA SAI MDP-S0801C(200×300)S Operation Manual

Chapter 2 Getting Ready to Embroider
4.
Adjust the tension of the under thread.
Suspend the bobbin case by holding the end of the thread, and
swing it back and forth. If the under thread comes out slowly, it
means that the tension is set to the appropriate amount.
2
If an adjustment is necessary, turn the thread tension
adjustment screw using the bobbin-case-use flat head
screwdriver.
5.
Wrap the under thread twice around the thread
guide coil.

2.3.3 Placing in rotary hook

1.
Pull out about 5 cm length of under thread from the bobbin case.
2.
Place the bobbin case inside the rotary hook and listen for it to click.
24
Let the under thread hang loosely in front of the bobbin case.
