Plug In Pciii Connectors; Locate Throttle Position Sensor; Reinstall All Bodywork - Dynojet POWER COMMANDER 3 Installation Instructions And Technical Information

Unplug
i437-411 www.powercommander.com
Stock connector
PCIII connectors
9 Plug the PCIII connectors in line with
the stock injector connectors (Fig. G).
The PCIII ORANGE wires go to the
GREEN connector for cylinder #1.
The PCIII YELLOW wires go to the
BLACK connector for cylinder #2.
10 Locate the Throttle Position Sensor on
the right side of the throttle body,
below the air filter cover (Fig. H).
11 Unplug the stock wiring harness from
the TPS.
12 Plug the PCIII wiring harness in-line
of the stock harness and TPS (Fig. J).
13

Reinstall all bodywork.

2008 Yamaha Tmax 500 - PCIII USB - 4
