Measures
Input X
INDICATION
To change the value of X and therefore vary the phase from which the data is read, press the ENTER key after entering the
submenu.
Measures Batteries
Measures
Misc.
Power Absorbed input active power on phase X [W]
Appar. Power Absorbed input apparent power on phase X [VA]
Vrms Effective input voltage of phase X [V rms]
Vrms bypass Effective input voltage of phase X of bypass line of the UPS [V rms]
Vrms ph-ph Effective input line voltage [V rms]
Irms Absorbed effective input current on phase X [A rms]
Peak Current Input peak current of phase X [A]
Frequency Pure sine input voltage frequency on phase X [Hz]
I Crest Factor Crest factor for phase X
Power Fact. Power factor of the load connected to the UPS on phase X
Voltage Battery voltage [V]
Current supplied by the batteries
Current
(negative if the UPS is charging the batteries) [A]
Residual
Battery charge status, expressed as percentage [0-100%]
Cap.
Battery charge operating status:
- Battery Stand-by
- Discharging
- Reserve autonomy
- End autonomy
- Charging - ph1
(Status) - Charging - ph2
- Charging - maint.
- Charging - float.
- Testing batteries
- Equaliz. batteries
- BATTERY FAULT
- MaxTime on Battery
Total Auton. Total autonomy the UPS would have with batteries 100% charged
Resid.Auton. Residual autonomy of the UPS
V Res.Th. Threshold voltage of the string of batteries for autonomy end [V]
Disch.Count Total number of complete battery discharges
Usage Total number of hours in which the UPS has functioned in battery mode [h]
Day and time of the last calibration.
Cal.
The text "Factory" is displayed if no calibration has yet been made.
Calibr.count Total number of calibrations made
Int.Temp Temperature inside the UPS [°C]
Pos.H.V.Bus Voltage on positive DC BUS [V]
Neg.H.V.Bus Voltage on negative DC BUS [V]
