For address setting, press the MODE button until the display shows "SYSTEM MODE".
Press the SET UP button until the display shows „DMX-Channel". The desired DMX start address can be
selected via the UP or DOWN buttons.
Controlling:
After having addressed the LED C-1 DMX Lighting Controller, you may now start operating it via your lighting
controller.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last device in the link in order to
ensure proper transmission on the DMX data link.

DMX-protocol

Control Channels

Channel 1
Value: Option
0-12 Blackout
13-25 Red
26-38 Green
39-51 Yellow
52-64 Blue
65-77 Purple
78-90 Cyan
91-103 White
104-116 Colour change
117-129 Slow flow 1
130-142 Slow flow 2
Channel 2: Speed
0-255 Step Time Value of 1/min up to 100/sec
Channel 3: Flash
0-255 Flash varies from OFF to 20Hz
Value: Option
143-155 Roll chase 1
156-168 Roll chase 2
169-181 Multi colour
182-194 Fast flow 1
195-207 Fast flow 2
208-220 2 colour chase
221-233 2 colour flow
234-246 Colour fade
247-255 Auto run
