Summary of Contents for EuroLite LVH-8

  • Page 1 USER MANUAL BEDIENUNGSANLEITUNG LVH-8 VIDEO CONTROLLED RELAY LVH-8 VIDEO CONTROLLED RELAIS INPUT LOOP THRU SYNC © Copyright Nachdruck verboten! www.eurolite.de Reproduction prohibited!
  • Page 3 The input signal fed through is available at the output LOOP THRU. The detection circuit bridges a 1 volt video line. The LVH-8 may be inserted in a video line with the LOOP THRU video output feeding a terminated load. It may alternatively be installed at the end of a video line by installing the supplied 75 terminator plug to the jack LOOP THRU.
  • Page 4 Koaxialkabel mit BNC-Steckern an die Buchse INPUT an. Am Ausgang LOOP THRU steht das durchgeschleifte Eingangssignal zur Verfügung. Die Detektorschaltung überbrückt eine 1 V Videoleitung. Das LVH-8 kann mit dem durch- geschleiften Videoausgang an eine Videoleitung angeschlossen werden und speist dabei eine abgeschlossene Last.
