INSTRUCTION MANUAL

1. CAUTION – SAFETY WARNING
Users of this product agree by their use to accept the inherent risks involved in paddle sports activities and agree to follow all
instructions, cautions, and warnings carefully before using this kayak.
Please read the following caution statement carefully:
Safety Warning
Paddle sports can be very dangerous and physically demanding. The user of this product should understand that participation in paddle
sports may involve serious injury or death. Observe the following safety standards whenever using this product.
Get paddle sports instructions specific to this type of craft
•
Obtain certified first aid training and carry first aid and rescue safety equipment
•
Always wear a nationally approved personal flotation device
•
Always wear a helmet where appropriate
•
Dress appropriately for weather conditions, cold water and/or cold weather can result in hypothermia. Check your equipment
•
prior to each use for signs of wear or failure
Never paddle alone
•
Do not paddle in flood conditions
•
Be aware of appropriate river water levels, tidal changes, dangerous currents, weather changes, and strong off shore winds
•
Scout unfamiliar water; portage wherever appropriate
•
Do not exceed your paddling ability; be honest with yourself
•
Consult your physician prior to beginning your paddle sports training
•
You must not use alcohol or mind altering drugs prior to using this product
•
Follow the manufacturer's recommendations for the use of this product
•
If additional outfitting is required, use manufacturer's approved materials only; do not impair entry or exit access
•
Read Owner's information packet prior to using this product
•
The user of this product acknowledges both an understanding and an assumption of the risk involved in paddle sports.
The precautions listed in this manual and on the craft are not all-inclusive. If a procedure, method, tool or part is not specifically
recommended, you must satisfy yourself that it is safe for you and others, and that the craft will not be damaged or made unsafe as a
result of your decision. REMEMBER – always use common sense when paddling your kayak.
2. SPECIFICATION
Model
DragonFly XC
DragonFly2 XC
2.1 Capacity
Do not exceed the certified maximum capacities under any circumstances. Overloading will reduce freeboard and increase the
likelihood of swamping, especially in heavy seas. Overloading causes handling to become sluggish, making it difficult to react quickly.
2.2 Features
Rigid bow & stern: Built-in rigid panels define the bow and stern and improve tracking
Durable and light: Unique outer cover provides durability in a lightweight design
Easy to set up: New twist valves and high flow spring valves allow for quick setup time
Comfortable: High support provides comfort for hours of paddling
Hull design: Landing plate and tracking fin improve performance
See figure 3 for the following overview of kayak feature details: (A) Rigid form bow cuts the water, (B) Molded rubber handle, (C) Paddle
holder, (D) Mesh pocket, (E) Splash reflector, (F) Folding seat back, (G) Rigid stern cuts the water, (H) Skeg tracking fin, (I) Durable
fabric cover, (J) Welded seams, (K) Bungee deck lacing, (L) Inner tube cover, (M) Landing plate
3. ASSEMBLY/INFLATING/DEFLATION INSTRUCTION
TM
The DragonFly XC Kayak has a rigid bow and stearn that enhances its performance.
3.1 Assembly
Your kayak comes from the factory pre-assembled. The only assembly you should need to do is attach the adjustable seat.
3.2 Understanding Your Valves
The Advanced Elements DragonFly XC
valves (see figure 2).
Dimensions (cm) Weight
(kg)
Length Width
254 87 9
366 90 13
TM
kayak uses two types of valves: Advanced Elements spring valves (see figure 1) and twist
Capacity Rec. Pressure (bar)
(kg)
Main Chambers
113 0.10
159 0.10
3
Floor
Chambers
0.07
0.07
