- Page 1 Quadrum OneTouch / Quadrum OneTouch Green auto Laser 530-670 nm IP 66...
-
Page 2: General Safety Instructions
Quadrum OneTounch / Quadrum OneTounch Green Please read the operating instructions as well as the enclosed brochures "Guarantee and additional notices" and "Laser class 3R safety instructions". Follow the instructions they contain. Safely keep these documents for future reference. Fully automatic rotary laser with red or green laser technology. - Page 3 Special product features and functions The rotary laser starts up by rotating and aligning itself automatically. It is set to the required initial position (to within an operating angle of ± 5°) and the automatic system then performs the necessary fine adjustment, with two electronic measurement sensors detecting the X and Y axes.
- Page 4 This is a source of potential characteristic fluctuations: – The optimal operating temperature is 20°C. Outside its operating temperature range of 0 – 40°C Quadrum OneTouch Green is darker. IMPORTANT: Allow the unit enough time to adapt to the ambient temperature before switching the unit on.
-
Page 5: Battery Charging
Battery charging – Charge the device's battery completely prior to use. – Connect the charger to mains power supply and the charging socket (H) of the battery compartment (J). Please only use the charger supplied; using a different charger will invalidate the warranty. The rechargeable battery can also be charged when it is not inserted in the device. - Page 6 Quadrum OneTounch / Quadrum OneTounch Green Prism head / laser beam outlet Battery compartment / battery fastening nut Receiver diodes for remote control (4 x) Charging socket Control panel (ON/OFF button) Battery compartment 5/8" thread (bottom) Rechargeable battery compartment Slot for rechargeable battery / battery compartment Mains unit / charger Electrical contacts...
-
Page 7: Remote Control
Control panel Remote control Quadrum OneTouch auto/man function Positioning button (rotate to the left) auto/man function LED auto/man. function: LED off: automatic alignment Y axis proceed as above LED on: manual alignment auto/man. function: Y axis proceed as below ON/OFF button auto/man. - Page 8 Quadrum OneTounch / Quadrum OneTounch Green Horizontal levelling auto – Horizontal: Position the device on a level surface or on a tripod. – Press the "ON/OFF" switch auto/man function LED OFF: Automatic alignment – The device levels itself automatically to within a range of ±5°. The laser rotates and the tilt, X and Y LEDs flash during the set-up phase.
- Page 9 Slope function > 5° Steeper slopes can be set using the angle plate, which is available as an optional extra (product ref. 080.75). TIP: Allow the device to align itself automatically and set the angle plate to the zero position. Then press the auto/man button to switch the automatic sensor off.
- Page 10 EU. This product is an electric device and must be collected separately for disposal according to the European Directive on waste electrical and electronic equipment. Further safety and supplementary notices at: www.laserliner.com/info...
- Page 11 5. To check the Y axis, repeat steps 3 and 4. If points A2 and A3 are more than 0,75 mm / 10 m apart on either the X or Y axis, the device is in need of adjustment. Contact your authorised dealer or else the UMAREX-LASERLINER Service Department.
-
Page 12: Adjustment Mode
Take the alignment of the rotary laser into account when performing adjustment work. Always adjust all the axes. X axis adjustment Activate adjustment mode: Switch on the Quadrum OneTouch. Press the Y axis plus/minus buttons simultaneously until the X LED flashes rapidly. - Page 13 Quadrum OneTounch / Quadrum OneTounch Green SERVICE Umarex GmbH & Co KG – Laserliner – Möhnestraße 149, 59755 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: +49 2932 638-333 laserliner@umarex.de Umarex GmbH & Co KG Donnerfeld 2 59757 Arnsberg, Germany Tel.: +49 2932 638-300, Fax: -333...
