Dynojet POWER COMMANDER V Installation Instructions page 4

FIG.D
FIG.E
I14-013 www.powercommander.com
8 Route the PCV wiring harness up to throttle bodies.
It is possible to install the PCV without removing the fuel tank and the airbox,
although removing them may aid in the install.
9 Unplug the stock wiring harness from the rear fuel injector (Fig. D).
10 Plug the pair of PCV leads with YELLOW colored wires in-line of the stock
wiring harness and the rear fuel injector (Fig. E).
11 Route the PCV harness under the throttle bodies to the right side of the bike.
12 Repeat steps 9 & 10 for the front fuel injector using the pair of PCV leads with
the ORANGE colored wires.
13 Reinstall the left and right side panels.
2007-2009 Ducati Multistrada 1100 - PCV - 4
