GRUNDFOS INSTRUCTIONS
Liftaway B
Installation and operating instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Liftaway B and is the answer not in the manual?

Questions and answers

Related Manuals for Grundfos Liftaway B

Summary of Contents for Grundfos Liftaway B

  • Page 1 GRUNDFOS INSTRUCTIONS Liftaway B Installation and operating instructions...

  • Page 2: Table Of Contents

    English (GB) Installation and operating instructions Original installation and operating instructions This appliance can be CONTENTS used by children aged Page from 8 years and above General information and persons with 1.1 Hazard statements 1.2 Notes reduced physical, Safety instructions sensory or mental Product introduction capabilities or lack of...

  • Page 3: General Information

    1. General information 2. Safety instructions Mounting the pump in the tank 1.1 Hazard statements DANGER The symbols and hazard statements below may appear in Grundfos installation and operating Electric shock instructions, safety instructions and service instructions. Death or serious DANGER...

  • Page 4: Product Introduction

    The Liftaway B 40-1 can also be used for the collection - Switch off the power and pumping of rain water. The variable height of the tank, which is installed...

  • Page 5: Function

    4. Function 7. Dimensions Wastewater from the connected units is discharged into the lifting station. The pump starts and stops by means of the level switch, depending on liquid level in tank. ø42 The wastewater is pumped through the outlet pipe to the main sewer line.

  • Page 6: Installation Of Tank

    8. Installation of tank Note: • Even though a non-return valve is fitted in the pump outlet port, the outlet pipe must be run above the backflow level (i.e. main sewer level). The pipes from this point must be made with pipe sizes of at least 40 mm nominal diameter (DN 40).

  • Page 7: Mounting The Pump In The Tank

    9. Mounting the pump in the tank DANGER Electric shock Death or serious personal injury - The protective earth of the socket outlet must be connected to the protective earth of the pump. Therefore the applied plug must have the same PE connection system as the socket outlet, or a suitable adapter must be applied.
  • Page 8 4. Place the pump at the bottom of the tank and mount fittings between the pump outlet port and the tank outlet. Unilift KP 150 / KP 250 Unilift AP12 5. Lead the electric cable of the pump out through the connection (DN 70) for venting and cable entry. For electrical connection, see the installation and operating instructions for the pump.

  • Page 9: Startup And Venting

    - Wear personal protective equipment. Liftaway B 40-1 with a Unilift KP or AP pump is practically maintenance-free. However, regular checks and cleaning will ensure faultless operation and a long operating life.
  • Page 10 Článku 11(4): Article 11(4): – Čerpací stanice Liftaway B s označením EN 12050-2 na – Liftaway B lifting stations marked with EN 12050-2 on the typovém štítku. nameplate. 3. Zamýšlená použití stavebního výrobku v souladu s příslušnou 3.
  • Page 11 Identifizierung des Bauprodukts erlaubt, wie in Artikel 11 (4) ved hjælp af hvilken byggevaren kan identificeres som krævet i vorgeschrieben. henhold til artikel 11, stk. 4: – Hebeanlagen Liftaway B, auf dem Typenschild mit EN 12050-2 – Liftaway B-beholderanlæg der er mærket med EN 12050-2 på gekennzeichnet. typeskiltet.
  • Page 12 11 artiklan 4 kohdassa con los requisitos establecidos en el Artículo 11(4): edellytetään: – Estaciones elevadoras Liftaway B en cuya placa de – Liftaway B-pumppaamot, joiden arvokilvessä on merkintä características figuren las normas EN 12050-2. EN 12050-2.
  • Page 13 επιτρέπει την ταυτοποίηση του προϊόντος του τομέα των δομικών l'exige l'Article 11(4) : κατασκευών όπως απαιτείται δυνάμει του Άρθρου 11(4): – Stations de relevage Liftaway B marquées EN 12050-2 sur la – Μονάδες ανύψωσης Liftaway B με σήμανση EN 12050-2 στην plaque signalétique.
  • Page 14 építési terméknek a 11. cikk (4) člankom 11(4): bekezdése alapján megkövetelt azonosítását: – Liftaway B podizne postaje označene s EN 12050-2 na – Liftaway B átemelő berendezések EN 12050-2 jelöléssel az natpisnoj pločici. adattáblán.
  • Page 15 11(4): conform artikel 11(4): – Stazioni di sollevamento Liftaway B, marcate con EN 12050-2 – Liftaway B hefstations gemarkeerd met EN 12050-2 op het sulla targa dei dati identificativi.
  • Page 16 11 ust. 4: conformidade com o Artigo 11(4): – Agregaty podnoszące do ścieków Liftaway B, oznaczone na – Estações elevatórias Liftaway B com a indicação EN 12050-2 tabliczce znamionowej kodem EN 12050-2. na chapa de características. 3. Przewidziane przez producenta zamierzone zastosowanie lub 3.
  • Page 17 2. Тип, номер партии, серийный номер или любой другой Članu 11(4): параметр, обеспечивающий идентификацию строительного – Stanice za podizanje Liftaway B na natpisnoj pločici imaju оборудования согласно Статье 11(4): oznaku EN 12050-2. –На фирменной табличке канализационных насосных...
  • Page 18 člen 11(4): 11.4: – Dvižne postaje Liftaway B z oznako EN 12050-2 na tipski – Liftaway B lyftstationer märkta med EN 12050-2 på typskylten. ploščici. 3. Byggproduktens avsedda användning eller användningar i 3.
  • Page 19 2. Gereken şekil inşaat ürününün Madde 11(4)'e göre tanımlanmasına izin veren tip, parti, seri numarası veya başka bir öğe: –Etiketinde EN 12050-2 işareti bulunan Liftaway B atık su transfer istasyonları. 3. Üretici tarafından öngörülen biçimde ilgili uyumlu teknik özelliklere uygun olarak inşaat ürününün amaçlanan kullanımı...
  • Page 20 Argentina China Hong Kong Bombas GRUNDFOS de Argentina S.A. GRUNDFOS Pumps (Shanghai) Co. Ltd. GRUNDFOS Pumps (Hong Kong) Ltd. Ruta Panamericana km. 37.500 Centro 10F The Hub, No. 33 Suhong Road Unit 1, Ground floor Industrial Garin Minhang District Siu Wai Industrial Centre 1619 Garín Pcia.
  • Page 21 Malaysia Serbia Turkey GRUNDFOS Pumps Sdn. Bhd. Grundfos Srbija d.o.o. GRUNDFOS POMPA San. ve Tic. Ltd. 7 Jalan Peguam U1/25 Omladinskih brigada 90b Sti. Glenmarie Industrial Park 11070 Novi Beograd Gebze Organize Sanayi Bölgesi 40150 Shah Alam Phone: +381 11 2258 740...
  • Page 22 96415567 0819 ECM: 1267465 www.grundfos.com...
