LM.60i
2.

Technical specifications

Power supply
Mains voltage
Emergency voltage
Mains frequency
Max. current used
Power consumption
Battery
PF input (Power Fail)
Control
Voltage input (Analogue input) ór
I/O-net
Drive
Pulling torque
Holding torque
Pulling capacity
Holding capacity
Min. number rotations
Max. number rotations
Running speed
Min.-max. stroke length (ø 50mm) *
Min.-max. stroke length (ø 65mm) *
Manual operation
Rotary switch
Potmeter input (for manual override on distance) and/or
max. thermostat (if control via I/O-net)
Housing
Plastic housing with screw on lid
Dimensions (l×w×h)
Weight (unpacked)
Ambient climate
Operating temperature range
Storage temperature range
Relative humidity
*) 4 mm cable
A5911664 - GB 100503
2. Technical specs
24 Vac (± 10%)
24 Vdc (± 10%)
50/60Hz
2x12Vdc
close contact
0-10Vdc (10-0Vdc)
max. 60 Nm
max. 50 Nm
210kg (ø 50mm)
175kg (ø 50mm)
1,2 rot/min
12,5-40 cm
16-53 cm
Closed -0- aut. - 0 - open
10kΩ - close, 0kΩ - open,
∞ - no manual override
284x237x182mm
0°C to +40°C (32°F to
-10°C to 50°C (14°F to
< 95%, uncondensed
4
0.8A
20W
Digital
0,8
2,7
IP54
4.7kg
104°F)
112°F)
