Chapter 3: Provisioning
Upload Remote EMU
After uploading the local EMU, its firmware image can be uploaded to the remote EMUs (the use of files is not
required). To upload to a remote EMU:
Step
1 In the Network screen
symbol. For example, Shelf # 27.
2 Type the letter U. The Upload menu is displayed
3 From the Upload menu, select Upload EMU. The Remote Upload EMU dialog is displayed
4 Press Y to upload the remote EMU. The Remote EMU Upload message is displayed
page 3-31).
5 Press any key to return to the Network screen
3-30
Figure 3-27. Boot Loader Prompt
(Figure 3-2 on page 3-4), select a remote shelf. That is, a shelf without the ">"
(Figure 3-2 on page
Figure 3-28. Remote Upload EMU Dialog
Action
(Figure 3-19 on page 3-25).
3-4).
September 25, 2006
(Figure 3-28).
(Figure 3-29 on
LTPE-UM-3159-02
