Table 3-4. Dsl Circuit Alarms In Order Of Severity; Table 3-3. Dsl Line Unit Status Conditions - ADC WorldDSL EMU-830 User Manual

Chapter 3: Provisioning
State Indicator
Normal –
Not Occupied /
Alarms Disabled D
Not Manageable X
NTU/STU-R N
Both loops *
Alarm Alarm
abbreviation
Priority
1
2
3
4
5
5
6
7
8
3-6

Table 3-3. DSL Line Unit Status Conditions

The circuit has no active alarms. This can be because one or more of the
circuit's alarms are disabled from being reported at the DSL card.
No unit is installed in the slot, or the unit is not recognized.
Alarm reporting has been disabled for this circuit at the EMU-830. This can be
changed using selection 2 from the Main menu.
The DSL card in the slot does not support centralized management by the
EMU-830.
The DSL card in the slot is an NTU/STU-R card. Alarms for a circuit with an
NTU/STU-R card residing in the managed shelf are not reported on this screen.
You can, however, login to the NTU/STU-R card using selection 1 from the Main
menu to view the alarm status.
The indicated alarm involves both loops.
The most severe active alarm in the circuit is shown.

Table 3-4. DSL Circuit Alarms in Order of Severity

Name
PFO Power feed open on both loops
PFO1 Power feed open on loop 1
PFO2 Power feed open on loop 2
PFS Power feed short on both loops
PFS1 Power feed short on loop 1
PFS2 Power feed short on loop 2
LOSW Loss Of Synch Word on both loops
LOSW1 Loss Of Synch Word on loop 1
LOSW2 Loss Of Synch Word on loop 2
LOS Loss of Signal on any G.703 interface
LOC Loss of clock (sourced from External
clock, or Nx64K data port)
LEC Loss of External clock alarm
LDC Loss of Nx64K data port clock alarm
MAL Below margin threshold both loops
MAL1 Below margin threshold on loop 1
MAL2 Below margin threshold on loop 2
LAL Loop Attenuation alarm both loops
LAL1 Loop Attenuation alarm loop 1
LAL2 Loop Attenuation alarm loop 2
ESAL Errored Second alarm both loops
ESAL1 Errored Second alarm on loop 1
ESAL2 Errored Second alarm on loop 2
Description
Description
September 25, 2006
Card Type
HDSL
HDSL
HDSL
G.SHDSL
HDSL
G.SHDSL
HDSL
UTU-91X
WD92xGx
HDSL
G.SHDSL
HDSL
G.SHDSL
HDSL
G.SHDSL
LTPE-UM-3159-02
