Specifications - Infinity INTERMEZZO 1.2s Service Manual

INTERMEZZO 1.2s
Frequency Response:
Subwoofer Amplifier Output:
2nd- and 3rd- Order Harmonic Distortion:
Crossover Frequencies:
Dimensions (H x W x D):
Weight:
Infinity continually strives to update and improve existing products, as well as create new ones. The
specifications and construction details in this and related Infinity publications are therefore subject to
change without notice.

Specifications

3
23Hz - 130Hz (±3dB)
30Hz - 130Hz (±1.5dB)
850 watts continuous
(In to 89from 20Hz-100Hz with no
more than 0.1% THD)
2,600 watts peak
<1%
(20Hz - 130Hz, @ 95dB SPL)
50Hz - 130Hz (continuously variable)
24dB/Octave
15-1/4" x 18-1/4" x 13-3/4"
(387mm x 464mm x 349mm)
60 lb (27.3kg)
