Infinity INTERMEZZO 1.2s Service Manual page 22

INTERMEZZO 1.2s
Part# Reference Designator
480090
480097
540124 L501
500103 T501
810088
JH0008 J502
KV0001 Z501
MT0023 FO503,F0504
SR0038 SW502
HN0006
HS0009
PCB, Input/Feature Board
Semiconductors
UA0003 U104
UA0009 U101,U102,U103
UF0012 U100
DR0038 D113,D114,D115,D116,D117,D118
DS0001 D100, D101, D102, D103, D104, D105, D106,
D107, D108, D109, D110, D111, D112, D119,
D120, D121,D122, D123, D124
DS0001 D119, D120, D123, D124, D125, D126
QB0017 Q102
QM0035-S Q100,Q101,Q103
DZ0013 Z100
Capacitors
CC0024 C127,C129
CC0072 C125,C130
CC0082 C122, C126
CE0003 C123,C124
CE0098 C118, C119, C131, C132
CE0103 C128
CE0116 C103,C104
CF0128 C108, C110
CF0045 C111,C112
CF0088 C114,C115,C116,C117
CF0092 C120,C121
CF0099 C136
CF0112 C102, C105, C135
CF0125 C107, C109
CE0138 C100,C101
dni C106, C113, C131, C133, C134
Resistors
RC0003 R176
RC0004 R162,R163
RC0006 R153, R154, R155, R156, R157,
R160, R161, R169, R172, R174, R175, R177
RC0037 R159,R164
Electrical Parts List (Cont.)
Qty Description
1 SUB, #18R 9 187X032/1/4STRP
1 SUB, #18B 9 187X032/1/4STRP
1 IND, CHOKE CM
1 XFMR, 60HZ 24V 1.1VA
1 MET, HTSNK 1X2 BRIDGE For D501
1 CNCTR, HEADER 5PIN .100CTR
1 VARISTOR, 275V 100J .6W
2 TERM,FASTON MALE PCMIT 187X032
1 RELAY, SPST TV-5 5AMP 24V
1 NUT, KEP 1/4AF 6-32 ZNP
1 SCREW, 6-32 1/2 100 PHIL ZNP
1 OPAMP, QUAD 14PIN DIL LM324N
3 OPAMP, QUAD 14P DIL TL074/084
1 FOTO, 6PIN 4N35
6 RECT, 1A 400V GENERAL 1N4002
19 RECT, 100mA 75V SIGNAL 1N4148T
6 RECT, 100mA 75V SIGNAL 1N4148T
1 TRANS, NPN 150V 0.6A 2N5551
3 JFET, J111 SELECTED TR ONLY
1 ZENER, 500MW 5.6V 5% 1N5232B
2 CAP, CA 1000PF 100V 10%
2 CAP, CA 100PF 100V 10%
2 CAP, CA .1UF 50V 20%
2 CAP, E 2.2UF 50V 20% 105C
4 CAP, E 22UF 50V 20% 5X11 .2LS
1 CAP, E 100UF 35V 85DEG
2 CAP, E 2.2UF 50V BIPOLAR 6X11
2 CAP, F .033UF 100V 5% 5MMLS
2 CAP, F .1UF 63DC 5% 5MMLS
4 CAP, F .01UF 100V 5% 5MMLS
2 CAP, F 1000P 63V 5% .2LS
1 CAP, F 0.68UF 63V 5% 5MMLS
3 CAP, F 100PF 63V 5% 5MMLS
2 CAP, F .068UF 100V 5% 5MMLS
1 CAP, E 330UF 100V BP 18X35
5 (Do Not Insert)
1 RES, CF 1K0 1/4W 5%
2 RES, CF 1M0 1/4W 5%
12 RES, CF 10K
2 RES, CF 2K0 1/4W 5%
22
1/4W 5%
