Infinity INTERMEZZO 1.2s Service Manual page 26

INTERMEZZO 1.2s
Part# Reference Designator
HS0090
HW0004
HW0040
MM0071
MM0073
MM0074
MZ0003
MZ0043
RP0057
Electrical Parts List (Cont.)
Qty Description
2 SCREW, M3X16MM PAN PHIL BLK TO ALIGN
SR0041
8 WASHER, SPLIT #6 ZNP TO MOUNT
POWER SUPPLY AND LINEAR BOARD
1 WASHER, FLAT #8 NYLON 3/8
MOUNT U BRACKET TO ENCLOSURE
1 MISC, CUP GASKET INTERMEZZO 1.2
1 MISC, RUBBER GROMMET FOR 5PIN FOR
SEALING ENCLOSURE OF THE 5PIN CABLE
HOLE
1 MISC, RUBBER GROMMET 2X8 PIN FOR
SEALING ENCLOSURE OF 2X8 PIN CABLE
4 STANDOFF, 6-32 3/8 ROUND AL 4PC TO
SUPPORT POWER SUPPLY
2 STANDOFF, .12ID .25OD .37L PVC
ALIGN SR0041
1 POT, KNOB CR00-20MB-16H
26
USED TO
TO
