Infinity INTERMEZZO 1.2s Service Manual page 25

INTERMEZZO 1.2s
Part# Reference Designator
Miscellaneous
480033
480104
930052
930053
FH0006
FS0027
HS0047
HS0057
HS0060
HS0078
INTERMEZZO 1.2H
INTERMEZZO 1.2P
JC0079
JC0129
JC0179
JC0180
JC0181
JC0182
MZ0042
SR0032
HS0054
HS0088
Electrical Parts List (Cont.)
Qty Description
3 SUB, #18R 4 1/4 187X032/187X032 1PC. IEC
LIVE TO FUSE HOLDER; 1PC. FUSE
HOLDER TO SWITCH; IPC. IEC NEUTRAL TO
SWITCH
1 SUB, #16X2 24 205X032/250X032 SPEAKER
WIRE
1 CUP ENCLOSURE
1 U-BRACKET
1 FUSE, HOLDER PANEL MT
1 FUSE, 6A 250V 1.25X.25 GLASS
12 SCREW, #6-32 3/4 PAN PHIL BLK 4PCS.
USED TO MOUNT LINEAR BOARD; 4 PCS
USED TO MOUNT POOWER SUPPLY; 4 PCS
USED TO SCREW VOLUME BOARD ONTO
RABOS BOARD
3 SCREW, #8-32X1/2 PAN PHIL BLK USED TO
ATTACH U-BRACKET TO ENCLOSURE
14 SCREW, #6-32 X 3/8 PP BLACK 4PCS USED
TO MOUNT EMI PCB IN HOUSING; 4 PCS
USED TO MOUNT EMI HOUSING U-
BRACKET; 6 PCS TO SECURE PANEL TO
ENCLOSURE
2 SCREW, #4 HI-LOW PAN PHIL BLK USED TO
SECURE RABOS BOARD IN HOUSING
1 INTERMEZZO 1.2 MAIN ENCLOSURE
1 INTERMEZZO 1.2 MAIN PANEL
1 CNCTR, 5PIN FEM-FEM HARNESS 7 J401
ON POWER SUPPLY TO J302 ON LINEAR
1 CNCTR, AC IEC SOCKET .250 2PIN
1 CNCTR, 5-PIN FEM-FEM HARNESS
SHIELDED 14 J502 ON EMI TO J102 ON
FEATURE
1 CNCTR, 8-PIN FEM-FEM HARNESS
SHIELDED 18 J104 ON FEATURE TO J200
ON RABOS
1 CNCTR, 8-PIN FEM-FEM HARNESS
SHIELDED 18 J103 ON FEATURE TO J301
ON LINEAR
1 2-CONDUCTOR AC LAMP CORD 8
4X187X032
4 STANDOFF, 3/8 #6-32 NYLON HEX USED TO
MOUNT LINEAR BOARD
1 SWITCH, ROCKER TV5
7 SCREW, #4-1/2 TYPE AB PP BLK 6 PCS.
USED TO SECURE BINDING POSTS TO
PANEL; 1 PC. USED TO SECURE RCA
JACKS TO PANEL
1 SCREW, #8-32X1.3/4 PAN PHIL BL USED TO
MOUNT U BRACKET TO ENCLOSURE
