INTERMEZZO 1.2s
Part# Reference Designator
Resistors
RC0148 R210
RM0001 R207,R208
RM0002 R200,R201,R214,R216,R220,
R225,R228, R229,R230, R233
RM0003 R219, R224
RM0012 R215
RM0024 R203
RM0031 R231
RM0076 R204
RM0078 R209
RM0080 R217,R223
RM0091 R211
RM0260 R232
RM0271 R206
RM0281 R222,R227
RM0315 R212
RM0369 R221,R226
RM0370 R202
RM0402 R234
RP0087 R205,R213
RP0088 R218
Capacitors
CE0003 C203,C204
CF0045 C200,C201,C202
CE0003 C210,C211
CF0045 C204,C205,C206,C207,C208
Miscellanous
JH0074 J200
PCB, Volume Board
RC0273 R237
RP0097 R235
RX0096 R236
RP0106
HS0047
MM0070
MZ0034
MZ0036
RABOS CUP 1.2
C0186
MM0075
DL0014 D200
Electrical Parts List (Cont.)
Qty Description
1 RES, CF 10M 1/4W 5%
2 RES, MF 1K00 1/4W 1%
10 RES, MF 10K0 1/4W 1%
2 RES, MF 15K0 1/4W 1%
1 RES, MF 100R 1/4W 1%
1 RES, MF 2K21 1/4W 1%
1 RES, MF 3K32 1/4W 1%
1 RES, MF 562R 1/4W 1%
1 RES, MF 680R 1/4W 1%
2 RES, MF 825R 1/4W 1%
1 RES, MF 3K65 1/4W 1%
1 RES, MF 1M0 1/4W 1%
1 RES, MF 110K 1/4W 1%
2 RES, MF 6K04 1/4W 1
1 RES, MF 2K67 1/4W 1%
2 RES, MF 340R 1/4W 1%
1 RES, MF 9K31 1/4W 1%
1 RES, MF 11K5 1/4W 1%
2 POT, A10K DUAL 12MM HOR SEL
1 POT, C10K DUAL 12MM HOR SEL
2 CAP, E 2.2UF 50V 20% 105C
3 CAP, F .1UF 63DC 5% 5MMLS
2 CAP, E 2.2UF 50V 20% 105C
5 CAP, F .1UF 63DC 5% 5MMLS
1 CNCTR, HEADER 8PIN LOCKING .1C
1 RES, ZERO OHM 1/4W
1 POT, A10K SINGLE/BRKT D SHAFT
1 RES, MO 2K2 1W 5%
1 POT, KNOB INT 1.2 LEVEL
4 SCREW, #6-32X3/4 PAN PHIL BLK TO MOUNT
VOLUME BOARD TO RABOS BOARD
1 MISC, GASKET Used on RABOS Housing
4 STANDOFF, 3/8 SPACER NYLON
1 STANDOFF, 14MM LED 2PIN
1 INTERMEZZO 1.2 RABOS HOUSING
1 CNCTR, FEM-FEM HARN 8P 18 SHIELD
1 MISC, RUBBER GROMMET RABOS HSG FOR
SEALING RABOS HOUSING
1 LED, 3MM BICOLOR RED/GR
